3M CP45B Manuale utente
projector
Shoot and Share
user
manual
English
Table of Contents
Getting Started................................................................ 1
Product Overview ................................................................................. 1
Package Content .................................................................................. 2
Charging the Battery............................................................................. 3
Reading LED indicators........................................................................ 3
Inserting a Memory Card (optional) ...................................................... 4
Power Camcorder Projector ON/OFF................................................... 4
Set Language ....................................................................................... 4
Sensitivity Calibration ........................................................................... 5
Keypad Sensitivity ................................................................................ 5
Menu Navigation................................................................................... 6
Understanding Status Icons.................................................................. 6
Basic Operations............................................................ 7
Recording a Video Clip......................................................................... 7
Taking a Still Picture ............................................................................. 7
Projecting Pictures/Videos.................................................................... 8
Connecting Camcorder Projector to Media Devices............................. 11
Advanced Operations .................................................... 13
Menu Setting Items............................................................................... 13
Battery Life Indicator............................................................................. 15
Converting Video Files................................................... 16
Specications ................................................................. 17
Troubleshooting ............................................................. 19
Limited Warranty ........................................................... 20
If the time arises to throw away your product, please
recycle all the components possible.
Batteries and rechargeable batteries are not to be
disposed in your domestic waste! Please recycle
them at your local recycling point.
Together we can help to protect the environment.
Thank You For Choosing 3M
This product has been produced in accordance with 3M quality and safety standards to
provide smooth and trouble-free use in the years to come. For optimum performance,
please follow the operating instructions carefully.
Important Notice
All statements, technical information, and recommendations related to 3M’s products are
based on information believed to be reliable, but the accuracy or completeness is not
guaranteed. Before using this product, you must evaluate it and determine if it is suitable for
your intended application. You assume all risks and liability associated with such use. Any
statements related to the product which are not contained in 3M’s current publications, or any
contrary statements contained on your purchase order shall have no force or effect unless
expressly set forth in a written agreement signed by an authorized ofcer of 3M.
Technical Support Contact
Trademarks and Copyrights
3M is a trademark of 3M Company.
VGA and XGA are trademarks of International Business Machines Corporation.
S-VGA is a registered trademark of the Video Electronics Standards Association.
No publication or commercial use may be made of this material without the express written
permission of 3M.
FCC Compliance Statement:
This device complies with Part 15 of the FCC Rules. Operation is subjected
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference in residential
installations. This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause interference to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Move the equipment away from the receiver.
-Plug the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/television technician for additional suggestions.
You are cautioned that any change or modications to the equipment not expressly approved
by the party responsible for compliance could void Your authority to operate such equipment.
English
Care and Safety Information:
Please read, understand, and follow all safety information contained in these
instructions prior to the use of this Camcorder Projector. Retain these instruc-
tions for future reference.
INTENDED USE
The 3M™ Camcorder Projector CP45 is designed to operate in a normal ofce
and home environment.
• 5°C ~ 35°C (41°F ~ 95°F)
• 10 ~ 80% RH (without condensation)
• 0 ~ 1829 m (0 ~ 6000 feet) above sea level
The ambient operating environment should be free of airborne smoke, grease,
oil and other contaminants that can affect the operation or performance of the
Camcorder Projector. Use of this product in adverse conditions will void the
product warranty.
EXPLANATION OF SIGNAL WORDS AND SYMBOLS
WARNING:
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury and/or
property damage.
CAUTION:
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury and/or
property damage.
Warning: Hazardous Voltage
WARNING
To reduce the risk associated with hazardous voltage:
• Do not modify this product in any way. Use only 3M approved replacement
components.
• Do not attempt to service this Camcorder Projector. There are no user
serviceable parts. Service to be performed only by a 3M-authorized service
provider using 3M-approved system components.
• Do not use the wall power supply in a wet environment.
• Do not use with a damaged wall power supply. Replace damaged part prior
to use.
WARNING
To reduce the risk associated with re and explosion:
• Do not immerse the Camcorder Projector in any liquid or allow it to get wet.
• Use only 3M approved power supply provided.
• Do not dispose of the Camcorder Projector by incineration or re.
• Do not operate this Camcorder Projector in any environment above 35°C
(95°F).
• Do not expose or store Camcorder Projector in direct sunlight, or excessive
heat (>60°C or 140°F) moist or caustic environments.
To reduce the risks associated with driver distraction in a moving motor
vehicle:
• Do not use this Camcorder Projector in a moving motor vehicle.
To reduce the risk associated with re and explosion, battery leakage or
overheating:
• Do not immerse the Camcorder Projector in water or allow it to get wet.
• Use only the 3M specied wall charger.
• Do not use the Camcorder Projector if it gives off an odor, or generates
excessive heat.
• Keep away from exposed ames if the Camcorder Projector leaks liquid or
emits an odor.
• Flush the eyes with water and seek medical attention if the Camcorder
Projector leaks liquid and the battery electrolyte gets in the eyes.
To reduce the risks associated with choking:
• Keep the Camcorder Projector, the microSD card and other small parts away
from young children.
CAUTION
To reduce the risk associated with environmental contamination:
• Dispose of all system components in accordance with applicable government
regulations.
To reduce the risks associated with bright LED ash light:
• Do not stare directly into the projector lens.
To reduce the risks associated with tripping and falling:
• Position the charging cord and data cables so that they can not be tripped over.
To reduce the risks associated with hearing loss:
• Be sure to read earphone manufacturer’s instructions with respect to volume
level.
• User is responsible to set a safe volume level.
English
Usage Notice:
Do:
• Turn off the power switch and unplug the power adapter before cleaning the
Camcorder Projector.
• Use a soft dry cloth with mild detergent to clean the display housing.
• Unplug the power adapter if the Camcorder Projector will not be used for a
long period of time.
• Operate the Camcorder Projector when the ambient room temperature is
within 5 ~ 35°C.
• Operate the Camcorder Projector when the Relative Humidity is 5°C ~ 35°C
(41°F ~ 95°F)
,
80% (Max.), non-condensing.
Do not:
• Use abrasive cleaners, waxes or solvents to clean the unit.
• Operate the Camcorder Projector under the following conditions:
►In extremely hot, cold or humid environments.
►In areas susceptible to excessive dust and dirt.
► Near any appliance generating a strong magnetic eld.
►In direct sunlight.
1
English
Getting Started
Product Overview
Focus wheel
Micro SD card slot#
IR receiver*
Power switch (ON / OFF)
Tripod socket†
Projection
lens
Power/Charging
LED Indicator
AV input / Headphone output
Down arrow
(Zoom out)
Left arrow
(Folder)
Right arrow (LED ash light)
Menu button
(Keypad lock)
Up arrow (Zoom in)
Return / Exit button
OK / Enter button
Camera button Record button
Projection button
Camcorder
lens
DC In/USB connector
LED ash light
Speaker
Mic
#microSD card not included
* Remote control not included
† Tripod not included
HDMI out
2
Package Content
Camcorder Projector User Manual AV cable
(RCA female to mini jack)
AC power adapter Interchangeable Plugs USB cable
CD which includes:
(a) User Manual
(b) ArcSoft Media Converter
Software
3
English
1Connect one end of the supplied AC adapter to the USB
port of the Camcorder Projector and the other end to a
wall outlet.
OR
Connect one end of the supplied USB cable to the USB
port of the Camcorder Projector and the other end to
a powered PC. Note: The Camcorder Projector power
switch must be Off to charge the battery.
2The Power LED turns orange and the charging starts.
3When the Power LED turns green, the battery is fully charged.
Charging Method Charging time
Camcorder Projector power switch Off,
connected to AC adapter
4 hours approximately
Camcorder Projector power switch Off,
connected to computer with USB cable
7 hours approximately
Camcorder Projector power switch On with AC
adapter or USB cable connected
no charging
Reading LED indicators
LED Indicator Description
Solid Orange Camcorder Projector is charging
Solid Green When AC power adapter is connected and the Camcorder
Projector is in standby mode. Also indicates a fully charged
battery
Solid Blue Camcorder Projector is ON
Blinking Blue Camcorder Projector is performing le transfer
Charging the Battery
4
1Power on the Camcorder Projector.
2Press the Menu button ( ), and then press the Left/Right ( / ) arrows to
navigate to Setting Screen ( ).
3Press the Up/Down ( / ) arrows to navigate to the Language item, and then
Press the OK button to conrm.
4Use the Up/Down ( / ) arrows to select a language.
5Press the OK button to conrm the setting.
Set Language
Power ON - Slide power switch to the “ON” position.
Power OFF - Slide power switch to the “OFF” position.
Inserting a Memory Card (optional)
1Open the Micro SD card cover.
2Gently insert the card as indicated (contacts facing
upward) until the card reaches the end of the slot.
3When the card is fully inserted, the icon ( ) will
appear on screen.
Note: The Micro SD card is spring loaded. To remove
the card, gently push inward to release the card and
then slide it outward to remove it from the Camcorder
Projector.
4Replace the Micro SD card cover.
5CP45 can only recognize one drive at a time when connecting to PC. If you like
the PC to recognize internal memory drive, you will have to remove microSD card
from device.
Power Camcorder Projector ON/OFF
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali 3M Videocamera
