A-rival SQALE Manuale utente
User Manual Body Analyser
Thank you for choosing an a-rival product. A good choice.
Just in case that you are facing any problems with your device,please call our support/service hotline +49 (0)511 / 123 83 506,
send us an e-mail to support@first-servicecenter.de or visit us on http://a-rival.de/facebook/
The detailed manual is also available in German on our website: www.a-rival.de
2
Table of Contents
Safety Information ............................................................................................................................................................................................ 4
Your Scale and Its
Environment
.............................................................................................................................................................................................. 6
Efficient Use of Your Scale.......................................................................................................................................................................................................... 6
Overview............................................................................................................................................................................................................ 7
Device Components .................................................................................................................................................................................................................... 7
LCD ............................................................................................................................................................................................................................................. 8
Initial Start-Up ................................................................................................................................................................................................... 9
General Instructions .................................................................................................................................................................................................................... 9
Insert the Batteries ...................................................................................................................................................................................................................... 9
Pair-Up ...................................................................................................................................................................................................................................... 10
Select Measurement Unit .......................................................................................................................................................................................................... 11
Start Measuring............................................................................................................................................................................................... 12
Daily Measurement ................................................................................................................................................................................................................... 12
Data Management ........................................................................................................................................................................................... 13
Data Transmission .................................................................................................................................................................................................................... 13
Troubleshooting ............................................................................................................................................................................................. 14
Error Prompt.............................................................................................................................................................................................................................. 14
When Measuring ....................................................................................................................................................................................................................... 14
When Data Transmitting............................................................................................................................................................................................................ 15
Specifications .................................................................................................................................................................................................16
Technical Data .......................................................................................................................................................................................................................... 16
Appendix ......................................................................................................................................................................................................... 17
Table of Body Fat Level (Unit: %) ............................................................................................................................................................................................. 17
Table of Body Water Level (Unit: %) ......................................................................................................................................................................................... 17
Maintenance .................................................................................................................................................................................................... 18
Guarantee ........................................................................................................................................................................................................ 22
3
Please do read the user manual carefully and thoroughly so as to
ensure
the safe usage of this product, and keep the
manual well
for
further
reference in case you have
problems.
Important info for the disposal of waste
(applicable in the countries of the European Union and other European countries with separate collection systems)
On the device, the packaging or accompanying manuals for the product, the symbol of the crossed out wheeled bin indicates that this
product must not be disposed of with normal household waste!
They also contribute to the proper disposal of the unit to protect the environment and the health of those around you. It
helps protect natural resources, recycling of materials, reduce the consumption of raw materials! Disconnect electrical
waste from other waste and dispose it on with your local, free return system. For recycling information, please contact your
local Civic Office, your household waste disposal service, the shop where you purchased the product or the manufacturer.
Important info for disposal of batteries
(applicable in the countries of the European Union and other European countries with separate battery collection systems)
On the battery, the packaging or accompanying manuals for the product, the symbol of the crossed out wheeled bin indicates that the
batteries in this product should not be disposed of with normal household waste!
The chemical symbols for lead (Pb), mercury (Hg) and Cd below the crossed out wheeled bin indicates that the lead, mercury and cadmium
content of the battery is higher than those laid down in the EC Directive 2006/66 reference values. If batteries are not disposed of properly,
they can cause harm to human health or the environment.
They also contribute to the proper disposal of the battery / batteries to protect the environment and the health of those
around you. It helps protect natural resources, recycling of materials, reduce the consumption of raw materials! Separate
batteries from other waste and dispose of it please them through your local, free battery return system. For recycling
information, please contact your local Civic Office, your household waste disposal service, the shop where you purchased
the product or the manufacturer.
4
Safety Information
Safety and Usage Information
The warning signs and symbols are essential to ensure your correct and safe use of this product and protect you and others from injury.
Please kindly find the meanings of the warning signs and symbols, which you may encounter in the label and user manual, as follows:
Symbol for “FOLLOW INSTRUCTIONS FOR USE Symbol for “NOTE ON IMPORTANT INFORMATION”
The Bluetooth Combination Mark
Symbol for “MANUFACTURER”
Symbol for “MANUFACTURE DATE” Symbol for “COMPLIES WITH EU REQUIREMENTS”
Symbol for “SERIAL NUMBER”
Symbol for “DIRECT CURRENT”
Symbol for “INDOOR USE ONLY“
Symbol for “ENVIRONMENT PROTECTION –Waste
electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice”
5
A-rivals Body Analyzer offers you a seamless way to manage your health. Please be aware that this device is designed for
adults’ self-measuring and self-monitoring body fat level. Any information provided by this device is in no way meant to treat,
cure or prevent any disease or illness from happening. This device should not be used by anyone who is acutely or chronically
ill, suffering from a disease or taking medications that affect your water levels. The accuracy of readings for these patients has
not been verified. Specific medical advice should be obtained from a physician.
The scale is equipped with data transmission function. It may emit electromagnetic energy so as to perform its intended
function. Nearby portable and mobile RF communications equipment can affect the performance of the scale.
Portable and mobile RF communications equipment can affect the measuring accuracy of the scale.
Be aware that misuse of electrical equipments can cause electric shock, burns, fire and other hazards.
Warning that the scale should not be used adjacent to or stacked with other equipment.
WARNING: No modifications of this equipment is allowed.
During using the Analyzer, the patient will contact with the surface and the electrode of the Analyzer. The device doesn’t need to
be calibrated in two years lifetime.
This device is contraindicated for any female subject who may be suspected of, or is pregnant. Besides provided inaccurate
readings, the affects of this device on the fetus are unknown.
This device is contraindicated for any person who is connected to a wearable or implantable electronic device or instrument
such as a pacemaker or defibrillator.
CAUTION
6
INDICATIONS FOR USE
The a-rivals Body Analyzer measures weight and use bio-electrical impedance analysis (BIA) technology to estimate body fat, total body
water percentage, bone mass, and muscle mass in generally healthy adults 18 years of age or older.
It is intended for use in the domestic setting only and not for diagnostic and / or therapeutic purposes.
Your Scale and Its
Environment
To ensure your safety as well as the service life of your scale, please avoid using the scale under the following circumstances:
Concurrent use of this device and implantable medical electronic instruments, e.g. Cardiac Pacemaker
Concurrent use of this device and wearable medical electronic instruments, e.g. electrocardiograph
Concurrent use of this device and other medical electronic instruments for life support, e.g. mechanical heart
Slippery floor such as tile floor
Jumping onto the platform immediately after bath or with wet hands
Near a cell phone or microwave oven
Avoid storage in the following locations:
Where there is water
Where the device may be exposed to extreme temperatures, humidity, moisture, direct sunlight, dust, or salt air
Where there is risk of shock or drop
Where you store chemicals or full of corrosive gases
Where in reach of the infants or children
Efficient Use of Your Scale
To ensure the accuracy of measurement, please follow below instructions when you start measurement.
Place the scale on a flat, hard surface. Soft surface such as carpet will affect the performance of the scale.
Step onto the platform with bare feet. Stand still and keep full contact with the electrodes until the measurement is complete.
Start measurement at least two hours after Getting up or Dinning.
Avoid measurement immediately after strenuous exercise, sauna or bath, drinking, and dinning.
Always start measurement in the same time slot and on the same scale located on the same flat, hard surface.
7
Overview
Device Components
Display
UNIT Button
Electrode Electrode
Battery Compartment
Note: Your weight is displayed directly on the scale. For the display of muscle mass, bone mass, water percentage and body fat percentage
you need the a-rival app. You can downloadthe App from the App Store or Google Play for free.
The a-rival App requires min. iPhone 4S/iOS 6.0 and above. If you use an Android device you need Bluetooth Smart support and min.
Android 4.3.
8
LCD
st Stone
Successful Bluetooth Connection
lb Pound
Data transmitting / pending to transmit
to App.
kg Kilogram
Low Battery
9
Initial Start-Up
General Instructions
A-rivals Glass Body Analyzer applies BIA (Bio-impedance Analysis) technology. A small amount of weak current flows through the human
body so as to detect the bio-impedance and estimate body fat. The electrical current is small and may not be felt.
This BIA technology is safe, non-invasive, toxic-free and harmless. It also possesses the characteristics of simple operation and abundant
information.
The current mentioned above is less than 1mA. However, please be aware that anyone with a wearable or implantable medical electronic
instrument, such as a pacemaker, must avoid using this device.
The intended use of this device is for adult’s indoor use only.
Insert the Batteries
Open the battery door in the back of the scale.
Insert the batteries (4 x 1.5V AAA) into the battery compartment
according to the polarity indications marked inside the
compartment.
* The digits “8888” will be shown on the LCD.
Close the battery door and wait until the digits “0.0kg” are shown on
the LCD.
When the symbol appears, the device will power off. Then you shall replace with a new set of batteries. Please replace all four batteries at
the same time. Do NOT mix the old batteries with the new one.
Worn batteries are hazardous waste. Do NOT dispose of them together with the household garbage. Please refer to the local ordinances and
recycling instructions regarding disposal of the worn batteries.
CAUTION
10
Pair-Up
Turn on Bluetooth and the App.
Press and hold “UNIT” button in the back of the scale to start pair-up.
Symbol and Symbol will be shown on the LCD alternatively,
indicating pair-up is proceeding.
If SUCCEED, symbol will be shown on the LCD.
If FAIL, symbol “E1” will be shown on the LCD.
