Abocom WUG2650 Manuale utente

802.11g Wireless LAN

USB Adapter

The WUG2650 is an 802.11g USB2.0 wireless LAN adapter. The

WUG2650 features the very latest in advanced wireless chip technology,

which is designed on the basis of IEEE 802.11g standard that offers a data rate up to 54Mbps in the 2.4GHz frequency.

Plus, the WUG2650 is backwards compliant with 802.11b wireless equipment, making it the most economic and

convenient wireless adapter that you can ever find for your wireless application. The high-speed wireless network card

plugs into your notebook or desktop PC and accesses to the LAN or peer-to-peer networking easily without wires or cables.

Whether you’re at your desk or in the boardroom, it allows you to share printers, files, and other network resources.

The USB adapter is designed for a USB type A port of a laptop or desktop computer for creating a wireless workstation.

FEATURES

 Compliant with IEEE802.11g standard for 2.4GHz Wireless LAN

 USB 2.0 compliant

 USB Plug & Play

 Interoperable with existing network infrastructure

 Secure information transmission

 Freedom to roam while staying connected

 Compatible with specialty wireless products and services

 Up to 54 Mbps data rate

 Antenna is built in the card with LEDs indication

 Low power consumption

 Easy to install and configure

♦

SPECIFICATIONS

General:

LED Indicator Act/Link: Green

Power Requirement ♦

♦

Operating Voltage: 5V DC

TX consumption: 250 mA (Max)

RX consumption: 150 mA (Max)

Physical specification ♦

♦

Weight: 25 g

Dimension: 98(L) x 30(W) x 14(H) mm

Supported OS ♦

♦

Windows 2000

Windows XP

Windows ME

Windows 98SE

Environment Specification ♦

♦

Operating Temperature: -5 ~ 45℃ambient temperature

Storage Temperature: -20~70℃ambient temperature

Operating humidity: 80% maximum (non-condensing)

Storage humidity: 80% maximum (non-condensing)

EMI Certification ♦

♦

FCC Part 15 in US

EN300328 and EN300826 (EN301489-17) in Europe

DGT and BSMI in Taiwan

Wireless:

Standard IEEE 802.11g

Host Interface USB 2.0

Antenna Chip Antenna

Frequency Range 2.412GHz ~ 2.4835GHz

Number of Selectable Channels

USA, Canada: 11 channels

Japan: 14 channels

Europe: 13 channels

Modulation Technique Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)

Orthogonal frequency division multiplexing (OFDM)

Security 0/64/128 bit WEP

WPA

Media Access Protocol CSMA/CA (Collision Avoidance) with ACK

Output power 11g: 13.5 dBm

11b: 16.5 dBm

Data Rate 802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)

802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)

Throughput 20.3 Mbps @ 54Mbps

5.4 Mbps @ 11Mbps

Outdoor Distance

183M @54Mbps(FER<10%)

225M @11Mbps (PER<8%)

Sensitivity

-70dBm @54Mbps

-82dBm @11Mbps
