Abtus AV546-W2 Manuale utente
LCD/LED Display
Wall Mount
ABtUS SINGAPORE PTE LTD www.abtussingapore.com
WARNING
1) Do not over tighten screws during installation. Over tightening can cause damage to the
screws and greatly reduce their ability to support the weight of the display.
2). Ensure that the mounting screws are anchored to the center of studs. Use of
an “edge to edge” stude finder is highly recommended.
Model:
V2021.05.04
AV546-W2
SPECIFICATION
** For detail, updated Command Code and Application Software, please visit and download from
www.abtussingapore.com
DIMENSIONOVERVIEW
* Specifications are subject to changes without notice.
Model NameAV546-W2
LCD/LED SIZESuitable for 26” to 63”
GROSS DIMENSION485 x 200 x 30 (mm)
GROSS WEIGHT 2 kg
MAX.VESA400 x 400 mm
DISTANCE FROM WALL 20 mm
LOAD CAPACITY50 Kgs
COLOUR OPTIONBlack
User Operation Guide
INSTALLATIONPACKAGING CONTENT
Item
ITV Board 2 sets
Item
J Wall Board 1 set
* Specifications are subject to changes without notice.
** For detail, updated Command Code and Application Software, please visit and download from
www.abtussingapore.com
