Abus TV8493 Manuale utente
2
1. Content of delivery
1 camera wall mount bracket
1 hinge element
1 housing base part
1 housing upper part
1 sunshield
1 installation material
1 installation manual
2. Installation oft the outdoor housing
The installation of the housing. The cable length
starting from the outside of the wall should be
mininimum 1,5 meter.
The installation should be performed by
qualified personnel.
2.1. Installallation of the wall mount bracket
2.1.1. Please use the bracket as drill hole
template.
2.1.2. Then drill the holes for the camera
bracket mounting screws.
2.1.3. Route the cables through the bracket
and use the cable ties for strain relief.
2.1.4. Now fix the bracket on the wall using the
screws.
3
2.2. Installation of the hinge element
2.2.1. Please route the cables through the
hinge element.
2.2.2. Put the hinge element into the bracket
with routed cables and fix the element
from downside using the fixing screw.
2.3. Installation of the base part
2.3.1. For the next steps please remove the
upper part from the base part of the
housing.
2.3.2. Remove the screw nut from the cable
gland on the base part.
2.3.3. Route the cables through screw nut and
cable gland.
2.3.4. Connect the cables on the inside of the
base part of the housing.
2.3.5. Fix the screw nut back on the cable
gland.
4
2.4. Connections
TV 8493
1: Connection for tamper switch
2: Connection 230VAC supply
3: Connection BNC Video
4: Connection 230VDC camera
Note:For video and supply cable please use a
combined cable (diameter max. 7 mm, min. 5 mm).
Only one round cable should be used for one cable
gland.
2.4.1. TV 8494 / TV8495
1: Connection for tamper switch (TV8494)
2: Connection for 230VAC supply
3: Connection BNC Video
4: Connection 12VDC camera plug / 2-wire
PE
-
+
camera
12V
2
1
3
4
5
2.5. Adjustment of camera position
2.5.1. Please remove the screws from the
camera tray on the inside of the base
partl.
2.5.2. Put the camera on the camera tray.
2.5.3. Fix the camera on the tray using a
screw.
2.5.4. Use the long holes to adjust the camera
position.
2.5.5. Fix the camera tray using the fixing
screws.
2.6. Installation of the upper part
2.6.1. Put the upper part back the to the base
part.
2.6.2. Screw back the ground cable to the
upper part on the marked position.
2.6.3. Screw back the ground cable to the
base part on the marked position.
2.7. Installation of the sunshield
2.7.1. Put the sunshield on top of the upper
part of the housing in alignment with the
back part of the housing.
2.7.2.Fix the sunshield using the fixing
screws.
6
3. Technical data
230 VAC connection
Main fuse: T3.15A
Integrated heating
Protection class IP67 (TV8493, TV8494)
Protection class IP54 (TV8495)
Inside routed cables
Operation temperature: -20 to +50°C
Weight: 2,56 kg without bracket
3,39 kg with bracket
Max. load: 0.4 kg
Max. dimensions (base-/upper part):
L/W/H (mm): 410/154/123
Max. dimension (bracket):
L/W/H (mm): 270/110/160
Max. dimension (camera):
L/W/H (mm): 215/80/64
TV8493: 230VAC connection, 230VAC
heating
TV8494: 230VAC connection, 230VAC
heating, pre-installed 12VDC / 800 mA
Netzteil
TV8495: 230 VAC connection, pre-installed
3,5 A PSU, 12 VDC heating, 12 VDC fan
