Aspire 3600/5500 Series

Service Guide

PRINTED IN TAIWAN

Service guide files and updates are available

on the ACER/CSD web; for more information,

please refer to http://csd.acer.com.tw

Revision History

Please refer to the table below for the updates made on Aspire 3600/5500 service guide.

Date Chapter Updates

2006/7/25 Chapter 2 Add removing BIOS password SOP.

III

transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in

any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without

the prior written permission of Acer Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular

purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the

programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its

dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential

damages resulting from any defect in the software.

Acer is a registered trademark of Acer Corporation.

Intel is a registered trademark of Intel Corporation.

Pentium and Pentium II/III are trademarks of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks of their respective holders.

Conventions

The following conventions are used in this manual:

SCREEN MESSAGES Denotes actual messages that appear

on screen.

NOTE Gives bits and pieces of additional

information related to the current

topic.

WARNING Alerts you to any damage that might

result from doing or not doing specific

actions.

CAUTION Gives precautionary measures to

avoid possible hardware or software

problems.

IMPORTANT Reminds you to do specific actions

relevant to the accomplishment of

procedures.

Preface

Before using this information and the product it supports, please read the following general information.

1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION

decided for Acer's "global" product offering. To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.

add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered

in this generic service guide. In such cases, please contact your regional offices or the responsible

personnel/channel to provide you with further technical details.

2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information

available on your regional web or channel. If, for whatever reason, a part number change is made, it will

not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer

office may have a DIFFERENT part number code to those given in the FRU list of this printed Service

Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and

service of customer machines.

Chapter 1 1

Features

Below is a brief summary of the computer’s many feature:

Platform and memroy

Aspire 5500

Intel®CentrinoTM Mobile Technology, featuring:

tIntel®Pentium®M Processor 730/740/750/760/770 (2 MB L2 cache, 1.60/1.73/1.86/2/2.13 GHz, 533

MHz FSB)

tIntel®Pentium®M Processor 725 (2MB L2 cache, 1.6 GHz, 400 MHz FSB)

tIntel®915GM/PM Express chipset

tWireless solution: integrated Intel®PRO/Wireless 2200BG network connection (dual-band 802.11b/g)

Wi-Fi®CERTIFIEDTM solution, supporting Acer SignalUp wireless technology

Aspire 3600

tIntel®Pentium®M Processor 725 (2MB L2 cache, 1.6 GHz, 400 MHz FSB)

tIntel®Celeron®M Processor 350/360/370 (1 MB L2 cache, 1.30/1.40/1.50 GHz, 400 MHz FSB)

tIntel®910GML Express chipset

tWireless solution: integrated Intel®PRO/Wireless 2200BG network connection (dual-band 802.11b/g)

Wi-Fi®CERTIFIEDTM solution, supporting Acer SignalUp wireless technology

TIntel®915GM/PM (for Aspire 5500)/Intel®910GML (for Aspire 3600)+Intel ICH6-M (Mobile Intel

82801FB)

T256/512 MB of DDR2 400/533 MHz memory, upgradeable to 2 GB using two soDIMM modules

(dual-channel support)

Display

T14.1 WXGA color TFT LCD, 1280 x 800 resolution; 16:10 viewing ratio, supporting simultaneous

multi-window viewing on dual displays via Acer GridVista 16.7 million colors

TIntel®915GM/PM (Aspire 5500)/Intel®910GML(Aspire 3600) integrated 3D graphics, featuring

Intel Graphics Media Accelerator 900 and up to 128 MB of VRAM, supporting Microsoft®DirectX®

9.0 and dual independent display

TATI MOBILITYTM RADEONTM X700 with 64 MB or higher of dedicated VRAM, supporting ATI

POWERPLAYTM 5.0, PCI ExpressTM, Microsoft®DirectX®9.0 and DualView (Aspire 3600 only)

TMPEG-2/DVD hardware-assisted capability

TS-video/TV-out (NTSC/PAL) support (Aspire 5500 only)

Storage subsystem

T40/60/80 GB ATA/100 hard disk drive

TOptical drive options:

tDVD-Dual slot loading type double layer (Aspire 5500)

System Specifications

Chapter 1

2Chapter 1

tDVD-Dual double layer (Aspire 3600)

tDVD/CD-RW combo

T5-in-1 card reader (MS/MS PRO/MMC/SD/xD-Picture Card

Input devices

TAcer FineTouchTM keyboard

T84/85-key keyboard

TTouchpad with 4-way integrated scroll button

TFour easy-launch buttons

TTwo front-access LED-buttons: WLAN and Bluetooth®

Audio

TAudio system with two built-in speakers

TMS-Sound compatible

Communication

TModem: 56K ITU V.90/V.92 modem with PTT approval; wake-on ring ready

TLAN: 10/100/ (TravelMate 3210) or gigabit Ethernet (TravelMate 2400); wake-on ring ready

TWLAN: integrated 802.11b/g Wi-Fi®CERTIFIEDTM solution (TravelMate 2400), or Intel®PRO/

Wireless 2200BG network connection (dual-band 802.11b/g) Wi-Fi®CERTIFIEDTM solution

(TravelMate 3210)

TAcer SignalUp wireless technology support

TWPAN: integrated Bluetooth®

Human-centric design and ergonomics

TRugged, yet extremely portable design

TStylish appearance

TFull-size keyboard with four programmable launch keys

TErgonomically-centered touchpad pointing device

TAcer FineTouch keyboard with a 5-degree curve

TInternet 4-way scroll button

I/O Ports

TThree USB 2.0 ports

T5-in-1 card reader (MS/MS-PRO/MMC/SD/XD)

TPC Card slot (one Type II)

TIEEE 1394 port (Aspire 5500 only)

TFast infrared (FIR) port (Aspire 5500 only)

TExternal display (VGA) port

TS-video/TV-out (NTSC/PAL) port (Aspire 5500 only)

THeadphones/speaker/line-out port

TMicrophone/line-in jack

TEthernet (RJ-45) port

TModem (RJ-11) port

Chapter 1 3

TDC-in jack for AC adaptor

4Chapter 1

System Block Diagram

Intel Pentium-M/

Celeron-M CPU

Micro FC- PGA

Mobile Intel 915PM/ GM

and 910GML Express

Chipset (Alviso)

DDR II SODIMM 1

DDR II SODIMM 2

Daughter Card (M26P)

PCI-Express x16

CRT & TV- Out Conn.

LVDS Conn.

Mobile Intel 82801FB

ICH6-M

USB Conn. x3

USB Conn. x1

for BlueTooth

Audio Codec

MDC Conn.

Amplifier

RJ-11

Speaker

Conn.

Jack x2

SAT A C on n.

PAT A C on n.

1394

Con tr ol l er

TSB34AB21A

PCMCIA &

CardRead er

Controller

ENE CB712

BroadCOM

LAN

BCM4401KFB

/ BCM5788M

Min i-PCI

So cket

RJ45

PCMCIA

Slot

4-in-1

CradReader

Slot

1394 Conn.

4-Pins

ENE KB910Q

(EC + KBC)

Super I/O

SMsC L PC 47 N21 7

Internal K/B

BIOS

Touch-Pad Conn.

Thermal Sensor

Clock Generator

Power ON/ OFF

Circuit

DC/ DC Interface

Circuit

Power DC/DC

Circuit

RTC Circuit

Power-OK Circuit
