FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

User Manual

FES-7611

Fanless Embedded Controller

Intel Celeron M ULV

Processor

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

This operation manual is meant to assist both Embedded Computer manufacturers and end

users in installing and setting up the system. The information contained in this document is subject

to change without any notice.

This manual is copyrighted inAugust, 2008. You may not reproduce or transmit in any form

or by any means, electronic, or mechanical, including photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property of their re-

spective owners.

CE NOTICE

This is a classAproduct. In a domestic environment this product may cause radio

interfernce in which case the user may be required to take adequate measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a ClassAdigital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual, may cause harmful inter-

ference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be requiredto correct the interfer-

ence at his own expense.

You are cautioned that any change or modifications to the equipment not expressly approve by the

party responsible for compliance could void your authority to operate such equipment.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

Contents

Chapter 1 Introduction

1.1AboutThisManual............................................................................2

1.2CaseIllustration................................................................................3

1.3SystemSpecification.......................................................................4-6

1.4SafetyPrecautions...........................................................................6

Chapter 2 Hardware Configuration

2.1Jumpers &Connector QuickReferenceTable............................8

2.2ComponantLocations....................................................................9

2.3HowtoSettheJumpers...............................................................10-11

2.4COMPortConnector......................................................................12

2.5RS232/422/485(COM2)Selection...............................................13

2.6Keyboard/MouseConnector........................................................14

2.7HardDiskDriveLEDConnector..................................................14

2.8PowerLEDConnector..................................................................14

2.9VGACRTConnector.....................................................................15

2.10HardDiskDriveConnector.........................................................16

2.11UniversalSerialBusConnector..................................................17

2.12LANConnector.............................................................................17

2.13ClearCMOSDataSelection.....................................................18

2.14PowerRequirementSelection...................................................19

2.15ATPowerConnector..................................................................19

2.16Reset/NMIWatchdogSelection...............................................20

2.17SoundConnector........................................................................21

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

2.18LANLED.................................................................................21

Chapter 3 Software Utilities

3.1Introduction.................................................................................23

3.2VGADriverUtility.......................................................................24

3.3FlashBIOSUpdate...................................................................25-26

3.4LANDriverUtility........................................................................27

3.5SoundDriverUtility....................................................................28

3.6IntelChipsetSoftwareInstallationutility...................................29

3.7SoundDriverUtility....................................................................30

3.8WatchdogTimerConfiguration.................................................31-32

Chapter 4 Award BIOS Setup

4.1Introduction.................................................................................34

4.2EnteringSetup...........................................................................35

4.3TheStandardCMOSFeatures................................................36-40

4.4TheAdvancedBIOSFeatures.................................................41-42

4.5AdvancedChipsetFeatures....................................................43-45

4.6IntegratedPeripherals..............................................................46-49

4.7PowerManagementSetup......................................................50

4.8PNP/PCIConfiguration...........................................................51-52

4.9PCHealthStatus.......................................................................53

4.10FrequencyControl..................................................................54

4.11LoadFail-SafeDefaults.........................................................55

4.12LoadOptimizedDefaults.......................................................55

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

4.13PasswordSetting.................................................................56

4.14Save&ExitSetup................................................................57

4.15ExitWithoutSaving..............................................................58

Appendix A Programming The Watchdog Timer

A.1ExplodedDiagram forAllTypeof RackMountHolder.......60

A.2Exploded DiagramforSystem HeatSink............................61

A.3ExplodedDiagram for3.5”HardDisk Drive........................62

A.4ExplodedDiagramfor 2.5” Hard DiskDriverHolder...........63

A.5ExplodedDiagram forHardDiskDrive Holder....................64

A.6ExplodedDiagramforDCtoDCPower...............................65

A.7ExplodedDiagramfor LEDIndicator....................................66

A.8Exploded DiagramforSystemI/OPorts...............................67

A.9ExplodedDiagramforPC104...............................................68

A.10Exploded Diagramfor Motherboard...................................68

A.11ExplodedDiagramforInstallingDDRRAM........................68

A.12ExplodedDiagramfor Removing Hard DiskDrive...........68

Appendix B Technical Summary

B.1BlockDiagram........................................................................72

B.2InterruptMap...........................................................................73

B.3RTC&CMOSRAMMap........................................................74

B.4Timer&DMAChannelsMap..................................................75

B.5I/OMemoryMap.....................................................................76

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

Introduction

CHAPTER

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

1-1. ABOUT THIS MANUAL

Thankyouforpurchasing our FES-7611 Intel® Pentium® M/ Celeron®MEmbeddedPC.FES-7611

provides faster processing speed, greater expandability and can handle more task than before. This

manualisdesigned toassistyouhow to installandset up thesystem.It contains fourchapters.Theuser

canapplythis manualforconfigurationaccording tothefollowingchapters :

Chapter 1 Introduction

Thischapterintroduces you tothebackground of thismanual,andthe specificationforthissystem. Final

partofthischapterwill indicate you how to avoid damaging this Embedded Card.

Chapter 2 Hardware Configuration

Thischapteroutlinesthecomponent locationandtheir functions.Inthe endofthis chapter,youwill learn

howtoset jumper andhowtoconfigure this cardtomeetyour own needs.

Chapter 3 Software Utilities

Thischaptercontainshelpfulinformationfor properinstallationsoftheVGAutility,LAN utility, soundutility,

andBIOSupdate. Italso describes the Watchdog timer configuration.

Chapter 4 Award BIOS Setup

Thischapterindicates youhowtoset uptheBIOSconfigurations.

AppendixASystemAssembly

ThisAppendixintroducesyouthe explodeddiagramofthe system.

Appendix B Technical Summary

Thissectiongives youtheinformationabout theTechnicalmaps.

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

1-2 Case Illustration

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

1-3. SYSTEM SPECIFICATION

z CPU :

Intel® Pentium® M/ Celeron® M processor

Available at 600MHz/ 1.0 GHz System bus frequency at 400MHz

Auto detect voltage regulator

z SYSTEM CHIPSET :

Intel®852GME/855GME Chipset

z MEMORY :

Supports up to 1 GB DDR SDRAM.

One200-pinDDRSO-DIMMsocketson board

z CACHE :

Built-inCPU

z REAL-TIME CLOCK / CALENDAR :

256-byte battery backed CMOS RAM.

Hardware implementation to indicate century rollover

z BIOS :

Phoenix-AwardBIOS™ for plug & play function

Memory size with 4 MB, with VGA BIOS

z KEYBOARD/MOUSE CONNECTOR :

PS/2 keyboard and mouse port by using one externalY cable

z UNIVERSAL SERIAL BUS :

SupportstwoUSB2.0ports.

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com

FES7611

Fanless Embedded Controller comes with

Intel Celeron M ULV 1.0GHz Processor

z DISPLAY :

Builtin Intel852GM,support CRT.

z IDE INTERFACE :

OneIDEportssupport up to two IDEdevices.SupportsUDMA33/66/100.

z LAN INTERFACE :

Intel®82562ET10/100Base-T

z SOUND:

AC '97 Codec. ReatelALC202A.

FullyCompliantAC '97AnalogI/OComponent

z SERIAL PORT :

Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte

FIFOs.COM1forRS232;COM2for RS232/422/485.

z HARDWARE MONITORING FUNCTION :

MonitorVoltage, CPUTemperatureand Cooling Fan.

z LED INDICATOR :

Power LED, HDD LED.

z DMA CONTROLLER :

82C37 x 2

z DMA CHANNELS :

Indice

Altri manuali Acnodes Controllori

Acnodes

Acnodes RM6380 Manuale utente

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
