2 Introduction

Introduction

Thank you for purchasing the Actiontec Home DSL Modem.

This product will introduce a whole new world of high speed

Internet access. With a quick and easy installation process

Actiontec’s Home DSL Modem will have you browsing the

web in no time.

The Actiontec Home DSL Modem will transform your

online experience. The high-speed Internet connection will

allow you to play online multi-player games, download files

faster and get real-time audio and video. Plus, you will be

able to surf the web and chat on the phone at the same time.

You will never miss an important phone call again. Welcome

to the world of high-speed internet access.

HOMEDSLP.FM Page 2 Tuesday, September 19, 2000 9:46 AM

Contacting Actiontec Technical Support 3

Contacting Actiontec Technical Support

Actiontec Electronics prides itself on making high-quality,

durable, high-performance products. If you should need

assistance, the Actiontec Technical Support Department is

available from 7:00 AM to 10:00 PM Pacific Coast Time,

Monday through Friday and 7:00 AM to 7:00 PM Pacific

Coast Time on Saturday and Sunday, to provide professional

support.

New drivers and firmware are released as need arises to

insure maximum compatibility and operation of your new

Actiontec Home DSL Modem. To find out more about this

and other Actiontec products, and to sign up for a free e-mail

newsletter, visit the Actiontec web site at:

http://www.actiontec.com to register your Actiontec Home

DSL Modem.

Actiontec Electronics Phone: 408-752-7714

Technical Support

760 N. Mary Avenue Fax: 408-732-0097

Sunnyvale, CA 94086 BBS: 408-732-0112

E-mail:

[email protected]

HOMEDSLP.FM Page 3 Tuesday, September 19, 2000 9:46 AM

4 Do This First

Do This First

Minimum System Requirements

•One Pentium class computer, 200 Mhz or higher (prefer-

ably 300 Mhz or above) with an available PCI slot,

32MB RAM and a CD-ROM drive

•Microsoft Windows 98 or Microsoft Windows 98 Second

Edition (SE) installed

•Confirmed DSL connectivity qualification to receive

AOL Plus™ service

Package Contents

Make sure the following items came in this package:

•Actiontec Internal PCI Home DSL Modem

•One 6’ telephone (RJ-11) cable

•This User’s Manual and Quick Start Installation Guide

•Four Microfilters

•Installation CD-ROM

•AOL Plus™ CD-ROM

•Warranty Registration Card

HOMEDSLP.FM Page 4 Tuesday, September 19, 2000 9:46 AM

Installing the Home DSL Modem 5

Installing the Home DSL Modem

Before you begin the installation of your Internal PCI Home

DSL Modem,

Step 1 Switch off the computer and all peripheral devices

connected to it.

Step 2 Unplug the computer power cord from the wall out-

let.

Step 3 Remove the computer’s cover. Refer to your com-

puter owner’s manual for instructions.

Step 4 On the back of the DSL card, confirm that the

switch position is set to 3, 4 or to the right.

CAUTION:

Always discharge static electricity before handling your

modem. You may discharge static electricity by touching

a grounded metal structure or by using any commer-

cially available grounding strap.

Make sure the expansion slot type is PCI, which has a

smaller slot to fit the PCI modem card. If you are not

familiar with computers or computer hardware or you

cannot tell the difference between an ISA slot or PCI

slot, obtain the help of someone who has a thorough

understanding of computers. You will severely damage

your computer if you install the modem in the wrong

slot.

Step 5 Remove the screw securing the expansion slot

cover behind one of the computer’s available PCI

expansion slots. Lift the expansion slot cover out as

shown on the next page.

HOMEDSLP.FM Page 5 Tuesday, September 19, 2000 9:46 AM

6 Installing the Home DSL Modem

Note: Make sure the

slot is a PCI slot.

The card will fit

securely in a keyed

PCI slot. PCI slots

aresmallerthanISA

slots. PCI slots are

lightcoloredandISA

slots are dark col-

ored.

Figure 1: Removing the Backplate

The position of the expansion slots in your com-

puter may differ from the illustrations shown in this

user’s manual, depicting the slots in a vertical posi-

tion. Regardless of the position of the expansion

slots, the installation steps remain the same. Please

refer to your computer owner’s manual for more

information about the expansion slot configuration

of your computer.

Step 6 Insert your PCI Home DSL Modem into the avail-

able PCI expansion slot. Then press on the top edge

of the card, straight down until the card’s connec-

tors seat firmly in the PCI slot. Secure it with the

screw removed in Step 4, as shown in the following

diagram.

HOMEDSLP.FM Page 6 Tuesday, September 19, 2000 9:46 AM

Installing the Home DSL Modem 7

Figure 2: Installing the PCI Card

Step 7 Put the cover back on the computer and fasten.

Step 8 Make sure that all power switches are in the OFF

position, then reconnect the power cables to the

computer and its peripherals.

Step 9 Unplug the telephone line cable from the telephone

and connect it to the Line jack as shown below.

Figure 3: Connecting Devices

HOMEDSLP.FM Page 7 Tuesday, September 19, 2000 9:46 AM

8 Installing the Microfilters

Installing the Microfilters

Microfilters are needed for every phone in your household.

Microfilters are installed on telephones to improve voice call

quality when voice and data equipment are using the same

telephone line.

Microfilter Installation for Phones that are Connected to a Computer

Step 1 Plug the microfilter into the Phone jack in the back

of your computer (Figure 4).

Step 2 Plug one end of the telephone cord into the micro-

filter Phone, and the other into the phone itself.

Figure 4: Microfilter Setup With The Computer

Microfilter Installation for All Other Phones

Step 1 Plug the Microfilter into the wall jack. (Figure 5)

Step 2 Plug one end of the telephone cord into the micro-

filter Phone, and the other into the phone itself.

(Figure 5)

Figure 5: Microfilter Setup for All Other Phones

HOMEDSLP.FM Page 8 Tuesday, September 19, 2000 9:46 AM

Installing the Modem Drivers 9

Installing the Modem Drivers

Configuring Windows 98/98SE

Step 1 After you have installed the modem into your

machine, turn on the power and allow the system to

boot normally.

Step 2 Windows 98 will immediately display the Add

New Hardware Wizard and identify the modem as

a “PCI ATM Controller”. Click the Next button.

Step 3 Select the option “Search for the best driver for

your device” and then click the Next button.

HOMEDSLP.FM Page 9 Tuesday, September 19, 2000 9:46 AM

10 Installing the Modem Drivers

Step 4 Put a “check” in the box for CD-ROM drive.

Before advancing to the next screen, insert the CD-

ROM into the computer’s CD-ROM drive. Now

click the Next button once.

Step 5 Windows 98 will find the “TIDSLC32.INF” driver

on the CD-ROM and identify the modem as a

“Actiontec Home DSL Modem”.Click the Next

button.

HOMEDSLP.FM Page 10 Tuesday, September 19, 2000 9:46 AM

Installing the Modem Drivers 11

Step 6 After Windows has finished loading the drivers, it

will announce the end of the installation process.

Click the Finish button once.

HOMEDSLP.FM Page 11 Tuesday, September 19, 2000 9:46 AM
