Bluetooth RS232 Adapter enables any RS232 devices with

Bluetooth capability and eliminates RS232 cable connections.

This unit can be configured as a Bluetooth Piconet or as a

point-to-point RS232 cable replacement set. It is an ideal

wireless link solution for industrial, medical and commercial

applications which require freedom from cable connections. It

supports SPP as a Master or a Slave.

BT5701Sv2

Bluetooth RS232 Adapter

Application Scenario

Features and Benefits

No Driver Required for Non-Windows Based Communication (Client) Devices

Configurable as an RS232 Cable Replacement Set

Supports Class 1 Output Power Up to 100 m Operation Range

Bluetooth SIG 1.2 Compliant

Profile Supported: Serial Port Profile as a Master or as a Slave

Baud Rate Supported: 1200 bps ~ 1843200 bps

Configurable for Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow

Control, BD Address, Device Name, Control Flag, PIN Code, Watchdog Timeout,

Supervision Timeout, and Peer BD Address (only used in Master)

Bluetooth RS232 adapter

enables any RS232 devices with Bluetooth capability and eliminates RS232 cable connections.

Example of RS232 Cable Replacement application Example of RS232 Piconet application

RS232 devices

Bluetooth enabled PC or PDA with

RS232 application program

Internet account

registration printer

Hotspot wireless

router

Class I

BCR01

Bluetooth RS232 Wireless Cable Solution

BT5701Sv2

Bluetooth RS232 Adapter

Bluetooth RS232 Adapter Class I

Specifications

Model No. BT5701S v2

Standard Bluetooth SIG 1.2

Bluetooth Profile Serial Port Profile (SPP) only

Baud Rate 1200 bps ~ 1843200 bps

Configurable Parameters Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow Control,

COM Port, Device Name, Control Flag, PIN Code,

Master or Slave,

Watchdog Timeout,

Supervision Timeout,

BD Address

Interface RS232 DB9M connector plus DB9F-DB9F null modem adapter

Frequency Band 2.400~2.4835 GHz unlicensed ISM band

Spectrum FHSS (Frequency Hopping Spread Spectrum)

Modulation GFSK

Output Power 13 dBm (typical)

Receiving Sensitivity -82 dBm (typical)

Power Class Class 1

Antenna Internal embedded

Range Up to 100 m (open-air)

LED Indicators Power & Connection Activities LED

Power Power provided by 7.5 V / 300 mA AC-DC power adapter

Dimensions 78.6 x 41.2 x 32.8 mm (3.20 x 1.68 x 1.34 in.) (L x W x H)

Weight 32 g (1.1 oz)

Operating / Storage

Temperature 0oC ~ 55oC (32oF ~ 131oF)/-20

oC ~ 80oC (-4oF ~ 176oF)

Specifications change without prior notice.

Physical

Dimensions &

Environment

Specifications

921 Corporate Way, Fremont, CA 94539

Tel: +1-510-490-8024, Fax: +1-510-623-7268

E-mail: [email protected], http://www.actisys.com

All trademarks, logos, organization & company names, and product model names are owned

by the respective organizations or companies.
