ACU-RITE 00621 Manuale utente

OUTDOOR

911

i iii

FUTURE FORECAST

.,o ... .. -)

♦

♦..,

Ji ,t

=~ ::

... "'

.) ---.

,QI,- • - -- 411,

.IJI- ------ ••J'

- -------·

...,. ............. Joi

PRESSURE HISTORV

'40f.llttl "'00

Ill

Instruction Manual

Weather Forecaster

model 00621

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor..... 2

Features & Benets: Display.... 3

Setup .................................... 4

Sensor Setup ......................... 4

Display Setup ........................ 4

Intelli-Time® Clock .................. 5

Set the Time, Date & Units ...... 5

Placement Guidelines ............. 6

Using the Forecaster............... 7

Troubleshooting ..................... 8

Care & Maintenance.............. 9

Replace Intelli-Time® battery ... 9

Specications........................10

FCC Information ...................10

Customer Support .................11

Warranty..............................11

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Archive:l Products

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this

product. Locate the tab and peel off to remove.

Package Contents

1. Display unit

2. Outdoor sensor

3. Instruction Manual

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

PRODUCT REGISTRATION

to receive 1 year

warranty protection

www.AcuRite.com

►

Features & Benets

1 OUTDOOR SENSOR

1. Integrated Hanger

2 For easy placement.

2. Wireless Signal Indicator

Flashes when data is being sent to the

display unit.

3. Battery Compartment

3 4. Battery Compartment Cover

Features & Benets 3 2 1 12

DISPLAY UNIT

1. 12 to 24 Hour 4

Weather Forecast

Self-Calibrating Forecasting

pulls data from the outdoor 5

sensor to generate your

personal forecast. 6

2. Learning Mode Icon

Disappears after weather

forecast self-calibration is

complete.

3. Sensor Low Battery Indicator

4. Current Outdoor Temperature

5. Outdoor Sensor Signal Strength

6. Moon Phase

7. Pressure History Graph

Tracks and displays the barometric

pressure history.

8. Current Barometric Pressure

BACK OF DISPLAY UNIT

1. "

▲

" Button

For setup preferences and

viewing records.

2. "

▼

" Button

For setup preferences and

viewing records.

3. SET Button

For setup preferences.

4. Fold-out Tabletop Stand

5. Battery Compartment

6. Intelli-Time Battery

Compartment

7. Integrated Hang Hole

For easy placement.

8. Battery Compartment Cover

9. Date

10. Intelli-Time Clock

Automatically updates for Daylight

Saving Time.

11. Current Indoor Temperature

12. Display Low Battery Indicator

1 2 3 4 5 6 7

LITHIUM S -

BATTERIESiP'1ilili1'M

ALKALINE

BATTERIES

(70°C) 158°F I

SETUP

Install or Replace Batteries

AcuRite recommends high quality alkaline batteries for the best product

performance. Heavy duty or rechargeable batteries are not recommended.

The outdoor sensor requires lithium batteries in low temperature conditions.

Cold temperatures can cause alkaline batteries to function improperly. Use

lithium batteries in the outdoor sensor for temperatures below -4ºF / -20ºC.

Outdoor Sensor

1. Slide off the battery compartment

cover.

2. Insert 2 x AA batteries into the

battery compartment, as shown.

Follow the polarity (+/-) diagram in

the battery compartment.

3. Replace the battery cover.

Display Unit

1. Slide off the battery compartment

cover.

2. Insert 2 x AA batteries into the

battery compartment, as shown.

Follow the polarity (+/-) diagram in

the battery compartment.

3. Replace the battery cover.

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE

WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to

be used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of

used batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries

in re, as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT

recharge non-rechargeable batteries. DO NOT short-circuit the supply terminals.

Intelli-Time®Clock

Intelli-Time products are pre-programmed with the correct time and date.

Intelli-Time technology instructs the time and date to set themselves. All you

need to do is select your Time Zone and Daylight Saving Time preferences. The

clock will then automatically set itself and change for Daylight Saving Time.

Set the Time, Date & Units

Press the “SET” button, located on the back of the display unit, to enter SET

MODE. Once in set mode, the preference you are currently setting will blink on

the display.

To adjust the currently selected (ashing) item, press and release the “

” or

“

“ buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “SET” button again to adjust

the next preference. The preference set order is as follows:

TIME ZONE ( PST MST CST EST AST HAST AKST)

DST (Daylight Saving Time ON or OFF)*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

TEMPERATURE SCALE (˚F or ˚C)

BAROMETRIC PRESSURE SCALE (inHg or hPa)

*If you live in an area that observes DST, DST should be set to ON, even if it is

not currently Daylight Saving Time.

You will automatically exit SET MODE if no buttons are pressed for 30 seconds.

Enter setup mode at any time by pressing the “SET” button.

"U'

-IJIJ...,-

( \ u,l,11, li.'3S

· :::;;; /1:r;JI 8

1111

\ I I

--o--

/ I \'

Placement for Maximum Accuracy

AcuRite sensors are sensitive to surrounding environmental conditions. Proper

placement of both the display unit and outdoor sensor are critical to the

accuracy and performance of this product.

Display Unit Placement

Place the display unit in a dry area free of dirt and dust.

Display unit stands upright for tabletop use or is wall-mountable.

Outdoor Sensor Placement

Sensor must be placed outside to observe outdoor conditions.

Sensor is water resistant and is designed for general outdoor

use, however, to extend its life place the sensor in an area

protected from direct weather elements.

Hang the sensor using the integrated hang holes or hanger, or

by using string (not included) to hang it from a suitable location,

like a well covered tree branch. The best location is 4 to 8 feet

above the ground with permanent shade and plenty of fresh air

to circulate around the sensor.

Important Placement Guidelines

•To ensure accurate temperature measurement, place units out of direct

sunlight and away from any heat sources or vents.

•Display unit and outdoor sensor must be within 165 ft (50 m) of each other.

•To maximize wireless range, place units away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

•To prevent wireless interference, place both units at least 3 ft (.9 m) away

from electronic devices (TV, computer, microwave, radio, etc.).

TV 3

(165 feet maximum)

(.9 m)

LEAST

APART

(50 meters)

Setup is Complete

The sensor will now synchronize with the display unit. It may take a few

minutes for synchronization to complete. Please refer to the troubleshooting

section of this manual if anything appears to be functioning improperly.

C=;» C=;» C=;» C=;» f?--C=;»

c~ :::.>

C~;;;, c~;;;, C:::>

..- --~*... ...~."'

: ---~! ~;>

*~*~·-

ff• g*g,,,g• * * *"' . - - - -

• •

NEW WAXING 1ST WAXING

CRESCENT QUARTER GIBBOUS FULL WANING 3RD WANING

GIBBOUS QUARTER CRESCENT

OPERATION

Using the Weather Forecaster Learning Mode

Self-Calibrating Forecasting uses a unique algorithm to analyze changes in

pressure over a time period (called Learning Mode) to determine your altitude.

After 14 days, the Learning Mode icon disappears from the display screen. At

this point, the self-calibrated pressure is tuned in to your location and the unit is

ready for superior weather prediction.

Weather Forecast

AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast

of weather conditions for the next 12 to 24 hours by collecting data from

the sensor in your backyard. It generates a forecast with pinpoint accuracy -

personalized for your exact location.

RAIN/SNOW

MIX LIKELY

(flashing=stormy)

SNOW

LIKELY

LIGHT RAIN

LIKELY CLOUDY MOSTLY

CLOUDY

View the complete list of icons at www.AcuRite.com/acurite-icons

Moon Phase

Track the phases of the moon, conveyed through simple lunar phase icons.

Barometric Pressure

Subtle variations in barometric pressure greatly impact the weather. This

weather forecaster displays the current pressure in inHg or hPa. The history

chart lets you monitor the change in pressure over time.

High & Low Records

Today’s high and low records are displayed for indoor and outdoor temperature.

Today’s records automatically clear at 12:00am midnight every day.

To view today's LOW records, press the “q” button on the back of the unit. To

manually clear today’s LOW recorded values, press and hold the “q” button

for 2 seconds. Dashes display to conrm you have cleared the LOW records.

To view today's HIGH records, press the “p” button on the back of the unit. To

manually clear today’s HIGH recorded values, press and hold the “p” button

for 2 seconds. Dashes display to conrm you have cleared the HIGH records.

T111I

Troubleshooting

No outdoor sensor

reception

no bars

If the wireless signal indicator shows no bars:

• Relocate the display unit and/or the outdoor sensor.

The units must be within 165 ft (50 m) of each other.

• Make sure both units are placed at least 3 feet (.9

m) away from electronics that may interfere with the

wireless communication (such as TVs, microwaves,

computers, etc).

• Use standard alkaline batteries (or lithium batteries in

sensor when temperature is below -4ºF/-20ºC). Do not

use heavy duty or rechargeable batteries. NOTE: It

may take up to 20 minutes for display unit and sensor

to synchronize after batteries are replaced.

Display screen

not working

• Check that the batteries are installed correctly.

Batteries may need to be replaced.

Outdoor

temperature

is ashing or

showing dashes

Flashing of the outdoor temperature is generally an

indication of wireless interference.

1. Bring both the sensor and display unit indoors and

remove at least one battery from each.

2. Reinstall the battery in the outdoor sensor.

3. Reinstall the battery in the display unit.

4. Let the units sit within a couple feet of each other

for about 20 minutes to gain a strong connection.

Inaccurate forecast

• Weather Forecast icon predicts conditions for the next

12 to 24 hours, not current conditions.

• Has Learning Mode icon disappeared from the

display unit? Learning Mode must complete before

forecast and pressure will be accurate.

• Allow unit to run continuously for 33 days. Battery

removal or resetting the display unit will restart

Learning Mode. After 14 days, forecast should be

fairly accurate, however Learning Mode calibrates for

a total of 33 days.

Inaccurate

temperature

• Make sure both the display unit and sensor are

placed out of direct sunlight and away from any heat

sources or vents (see page 6).

If your AcuRite product does not operate properly after trying

the troubleshooting steps, visit www.AcuRite.com or call

(877) 221-1252 for assistance.

WARNING: THIS PRODUCTCONTAINS A BUTTON-CELL BATTERY.IF SWALLOWED, IT~

COULDCAUSESEVEREINJURY ORDEATHIN JUST 2 HOURS.

SEEK MEDICAL ATTENTION IMMEDIATELY IF INGESTED.

POISON

Care & Maintenance

Display Unit Care

Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep

away from dust, dirt and moisture. Clean ventilation ports regularly with a

gentle puff of air.

Outdoor Sensor Care

Clean with a soft damp cloth. Do not use caustic cleaners or abrasives.

Replace Intelli-Time Battery

Intelli-Time technology is

coin-cell battery that stores

the time and date settings.

The battery has a shelf life of

several years. To replace the

Intelli-Time battery:

1. Locate the coin cell battery

compartment door on

the back of the display

unit, inside the battery

compartment. Unscrew and

remove the compartment

cover.

CR2032

Install battery with “+” positive

terminal facing OUT.

2. Insert 1 x CR2032 coin cell battery into the battery compartment, as

shown. Install battery with “+” positive terminal facing OUT.

3. Screw in the battery cover.

Specications

TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC

Indoor: 32ºF to 122ºF; 0ºC to 50ºC

WIRELESS RANGE 165 ft / 50 m depending on home construction materials

OPERATING FREQUENCY 433 MHz

POWER Display: 2 x AA alkaline batteries

Sensor: 2 x AA akaline or lithium batteries

DATA REPORTING 30 second updates

FCC Information

This device complies with part 15 of FCC rules. Operation is subject to the following two conditions:

1- This device may NOT cause harmful interference, and

2- This device must accept any interference received, including interference that may cause undesired operation.

WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, There is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modications to this equipment.

Such modications could void the user authority to operate the equipment.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation of the device.

Indice

Altri manuali ACU-RITE Stazione meteorologica

ACU-RITE

ACU-RITE 01021 Manuale utente

ACU-RITE

ACU-RITE 00821SBDI Manuale utente

ACU-RITE

ACU-RITE Forecaster 00823 Manuale utente

ACU-RITE

ACU-RITE 06021 Manuale utente

ACU-RITE

ACU-RITE 01123 Manuale utente

ACU-RITE

ACU-RITE 2035 Manuale utente

ACU-RITE

ACU-RITE 02064CAUDI Manuale utente

ACU-RITE

ACU-RITE 02045W Manuale utente

ACU-RITE

ACU-RITE 01607BPDI Manuale utente

ACU-RITE

ACU-RITE 02001 Manuale utente

ACU-RITE

ACU-RITE 00821SBDI Manuale utente

ACU-RITE

ACU-RITE 02050CAUDI Manuale utente

ACU-RITE

ACU-RITE 75107 Manuale utente

ACU-RITE

ACU-RITE Iris 06101M Manuale utente

ACU-RITE

ACU-RITE 01540M Manuale utente

ACU-RITE

ACU-RITE 01022 Manuale utente

ACU-RITE

ACU-RITE Iris 06014 Manuale utente

ACU-RITE

ACU-RITE 02099 Manuale utente

ACU-RITE

ACU-RITE 06022 Manuale utente

ACU-RITE

ACU-RITE 02030RM Manuale utente

ACU-RITE

ACU-RITE 250 Manuale utente

ACU-RITE

ACU-RITE 02027 Manuale utente

ACU-RITE

ACU-RITE 1525 Manuale utente

ACU-RITE

ACU-RITE 75321A1 Manuale utente

Manuali Stazione meteorologica popolari di altre marche

Auriol

Auriol AHFL 433 A1 Manuale utente

NexSens

NexSens G2-HYDROMET Manuale utente

Hyundai

Hyundai WS 2202 Manuale utente

IROX

IROX HBVR761 UV-X Manuale utente

La Crosse Technology

La Crosse Technology C86371 Manuale utente

ADE

ADE WS 1711 Manuale utente

Auriol

Auriol z29592 Manuale utente

Auriol

Auriol 296289 Manuale utente

Hyundai

Hyundai WS 2266 Manuale utente

La Crosse Technology

La Crosse Technology WS-2210 Manuale utente

La Crosse Technology

La Crosse Technology WS-811561 Manuale utente

Ventus

Ventus W177 Manuale utente

National Geographic

National Geographic VA Colour RC Manuale utente

Renkforce

Renkforce 1208067 Manuale utente

Levenhuk

Levenhuk Discovery Report WA40 Manuale utente

Instant Transmission

Instant Transmission MA 10410 Manuale utente

Lutron Electronics

Lutron Electronics PHB-318 Manuale utente

WAREMA

WAREMA EWFS Weather station eco Manuale utente
