ACU-RITE 01129 Manuale utente

Instruction Manual

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor..... 2

Features & Benets: Display.... 3

Setup .................................... 5

Sensor Setup ......................... 5

Display Setup ........................ 6

Intelli-Time® Clock .................. 7

Set the Time, Date & Units ...... 7

Placement Guidelines ............. 8

Using the Weather Forecaster... 9

Backlight Settings..................10

USB Charging.......................11

Troubleshooting ....................12

Care & Maintenance.............13

Replace Intelli-Time® Battery ..13

Specications........................14

FCC Information ...................14

Customer Support .................15

Warranty..............................15

Alarm Clock Weather Station

model 01129

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this

product. Locate the tab and peel off to remove.

Package Contents

1. Display

2. Outdoor Sensor

3. Power Adapter

4. Instruction Manual

Features & Benets

OUTDOOR SENSOR

1. Integrated Hanger

For easy placement.

2. Wireless Signal Indicator

Flashes when data is being sent to

the display.

3. Battery Compartment

4. A-B-C Switch

ID code that must match display’s

A-B-C switch to ensure units

synchronize.

5. Battery Compartment Cover

PRODUCT REGISTRATION

www.AcuRite.com

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

Features & Benets

FRONT OF DISPLAY

1. Current Outdoor Temperature

Arrow icon indicates the direction

temperature is trending.

2. Outdoor Sensor Signal Strength

3. Outdoor Low Temperature Record

Lowest temperature recorded

since midnight.

4. Outdoor High Temperature Record

Highest temperature recorded

since midnight.

5. Date

6. USB Charger

For compatible smartphones.

7. Icon

Indicates display is in auto-dimming

brightness mode (see page 10).

8. Intelli-Time®Clock

Automatically updates itself for

Daylight Saving Time.

9. Alarm ON/OFF Indicator

10. Learning Mode Icon

Disappears after weather forecast

self-calibration is complete.

11. Current Indoor Humidity

Arrow icon indicates the direction

humidity is trending.

12. Humidity Level Icon

Indicates a high, low or ideal

humidity comfort level.

13. Current Indoor Temperature

Arrow icon indicates the direction

temperature is trending.

14. SNOOZE Button

15. 12 to 24 Hour Weather Forecast

Self-Calibrating Forecasting pulls data

from the outdoor sensor to generate

your personal forecast.

16. Outdoor Sensor Low

Battery Indicator

16 1415

7 8

Features & Benets

DISPLAY BOTTOM

6. A-B-C Switch

ID code that must match the

sensor's A-B-C switch to ensure

units synchronize.

7. Battery Compartment

8. Intelli-Time® Battery

Compartment

9. Battery Compartment Cover

DISPLAY BACK

1. Alarm ON/OFF Switch

2. Button

For setup and backlight

brightness preferences.

3. SET Button

For setup preferences.

4. Button

For setup and backlight

brightness preferences.

5. Plug-in for Power Adapter

SETUP

Sensor Setup

Set the A-B-C Switch

The A-B-C switch is located inside

the battery compartment. It can

be set to A, B or C. However,

you must select the same letter

choices for both the sensor and

the display in order for the units

to synchronize.

Install or Replace Batteries

AcuRite recommends high quality

alkaline or lithium batteries for

the best product performance.

Heavy duty or rechargeable

batteries are not recommended.

The sensor requires lithium

batteries in low temperature

conditions. Cold temperatures

can cause alkaline batteries

to function improperly. Use

lithium batteries in the sensor for

temperatures below -4ºF / -20ºC.

1. Slide off the battery

compartment cover. Take note

of the A-B-C switch setting

inside the battery compartment

for display setup.

2. Insert 2 x AA batteries into

the battery compartment, as

shown. Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

1A-B-C Switch

Set to match

display

2Install Batteries

2 AA batteries

A B C

Display Setup

Set the A-B-C Switch

Locate the A-B-C switch inside

the battery compartment. Set

the A-B-C switch to A, B or C.

You must select the same letter

choices for both the display and

the sensor in order for the units

to synchronize.

Plug in Power Adapter

For the best performance, plug

in the power adapter as the main

power source for this product.

Install or Replace Backup

Batteries (optional)

1. Remove the battery

compartment cover.

2. Insert 2 x AAA alkaline

batteries into the battery

compartment, as shown.

Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

A B C

IMPORTANT: Batteries are a backup power source to preserve records in the event of a

power outage. Power adapter recommended as the primary power source to enjoy the full

functionality of the product.

2Plug in Power

Adapter

1A-B-C Switch

Set to match

sensor

Install Backup

Batteries (optional)

2 AAA alkaline

batteries

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE

WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not be

used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used

batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in ﬁre,

as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge

non-rechargeable batteries. DO NOT short-circuit the supply terminals.

Intelli-Time®Clock

Intelli-Time products are pre-programmed with the correct time and date.

Intelli-Time technology instructs the time and date to set themselves. All you

need to do is select your Time Zone and Daylight Saving Time preferences. The

clock will then automatically set itself and change for Daylight Saving Time.

Set the Time, Date & Units

Press and HOLD the "SET" button, located on the back of the display until

"SELECT TIME ZONE" appears, to enter SET MODE. Once in SET MODE, the

preference you are currently setting will ash on the display.

To adjust the currently selected (ashing) item, press and release the " " or

" " buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the "SET" button to adjust the next

preference. The preference set order is as follows:

TIME ZONE (PST MST CST EST AST HAT AKT NST)

AUTO DST (ON or OFF)*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

TEMPERATURE UNITS (ºF or ºC)

*If you live in an area that observes Daylight Saving Time, DST should be set

to ON, even if it is not currently Daylight Saving Time.

You will automatically exit SET MODE if no buttons are pressed for 5 seconds.

Enter SET MODE at any time by pressing and holding the "SET" button until

"SELECT TIME ZONE" appears on the display.

Set the Alarm Time

To set the alarm time, press and RELEASE the "SET" button to enter ALARM SET

MODE.

To adjust the currently selected (ashing) item, press and release the " " or

" " buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “SET” button to adjust the next

preference. The preference set order is as follows:

ALARM CLOCK HOUR (Please note AM/PM indicator)

ALARM CLOCK MINUTE

You will automatically exit ALARM SET MODE if no buttons are pressed for

5 seconds. Enter ALARM SET MODE at any time by pressing and RELEASING

the "SET" button.

Enable the alarm by switching the ON/OFF switch (located on the side of the

display) to ON.

Display Placement

Place display in a dry area free of dirt and dust. To help ensure an

accurate indoor temperature measurement, be sure to place the

display away from heat sources or vents.

Outdoor Sensor Placement

Sensor must be placed outside to observe outdoor conditions.

Sensor is water resistant and is designed for general outdoor use,

however, to extend its life place the sensor in an area protected

from direct weather elements.

Hang the sensor using the integrated hang holes or hanger, or by

using string (not included) to hang it from a suitable location, like a

well covered tree branch. The best location is 4 to 8 feet above the

ground with permanent shade and plenty of fresh air to circulate

around the sensor.

Placement for Maximum Accuracy

AcuRite sensors are sensitive to surrounding environmental conditions. Proper

placement of both the display and outdoor sensor are critical to the accuracy

and performance of this product.

Important Placement Guidelines

• To ensure accurate temperature measurement, place units out of direct

sunlight and away from any heat sources or vents.

• Display and outdoor sensor must be within 330 ft (100 m) of each other.

• To maximize wireless range, place units away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

• To prevent wireless interference, place both units at least 3 ft (.9 m) away

from electronic devices (TV, computer, microwave, radio, etc.).

Setup is Complete

The sensor will now synchronize with the display. It may take a few minutes for

synchronization to complete.

TV 3

(100 meters)

(330 feet maximum)

(.9 m)

LEAST

APART

OPERATION

View the complete list of icons at www.AcuRite.com/acurite-icons

Using the Weather Forecaster

Learning Mode

Self-Calibrating Forecasting use a unique algorithm to analyze changes in

pressure over a time period (called Learning Mode) to determine your altitude.

After 14 days, the Learning Mode icon disappears from the display screen. At

this point, the self-calibrated pressure is tuned in to your location and the unit is

ready for superior weather prediction.

Weather Forecast

AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast

of weather conditions for the next 12 to 24 hours by collecting data from

the sensor in your backyard. It generates a forecast with pinpoint accuracy -

personalized for your exact location.

STORM

DEVELOPING

(Flashing)

SNOW

LIKELY LIGHT RAIN

LIKELY PARTLY

CLOUDY SUNNYCLOUDY

Weather Trend

Subtle variations in barometric pressure greatly impact the weather. This

weather forecaster displays an arrow icon under the forecast to indicate the

direction the pressure is trending (FALLING, STEADY, or RISING).

Humidity Level Icon

The Humidity Level Icon easily conveys a low, high or ideal indoor humidity

level for your home and health:

Learn more at http://www.acurite.com/humidity-health

LOW Humidity Level

Humidity is

low relative to

temperature.

Makes for a

DRY environment.

OK Humidity Level

Humidity is

OK relative to

temperature.

Makes for an

IDEAL environment.

HIGH Humidity Level

Humidity is

high relative to

temperature.

Makes for a HUMID

environment.

LOW

HIGH

Alarm Clock SNOOZE

The alarm clock will sound, increasing in volume over a 2 minute period. When

the alarm is sounding, press the "SNOOZE" button to activate the SNOOZE

function for 10 minutes. The SNOOZE function can be activated up to 10 times.

Backlight Settings

This alarm clock's color display features 6 different lighting settings: 100%

(High), 70%, 50% (Medium), 30%, 10% and 5% (Low) brightness.

When the display is powered with the power adapter, the backlight remains

on at 100% brightness by default. Press the "SNOOZE" button at any time to

momentarily light the display at 100% brightness. After 5 seconds, the display

will return to the user-selected brightness setting.

Manually adjust the backlight brightness by pressing and releasing the " "

or " " buttons when not in SET MODE or ALARM SET MODE. Press the

" " button a sixth time to enter "AUTO DIM" mode. " " will appear to the

left of the clock.

AUTO DIM MODE: Automatically adjusts display brightness based on time of day.

7:00 a.m. - 9:00 p.m. = 100% brightness

9:01 p.m. - 6:59 a.m.= 5% brightness

Indice

Altri manuali ACU-RITE Stazione meteorologica

ACU-RITE

ACU-RITE 01536 Manuale utente

ACU-RITE

ACU-RITE 01097 Manuale utente

ACU-RITE

ACU-RITE OO592W Manuale utente

ACU-RITE

ACU-RITE 01021 Manuale utente

ACU-RITE

ACU-RITE 00777 Manuale utente

ACU-RITE

ACU-RITE 502 Manuale utente

ACU-RITE

ACU-RITE 02099 Manuale utente

ACU-RITE

ACU-RITE 00594W Manuale utente

ACU-RITE

ACU-RITE 01181 Manuale utente

ACU-RITE

ACU-RITE 309 Manuale utente

ACU-RITE

ACU-RITE 00875 Manuale utente

ACU-RITE

ACU-RITE 06004 Manuale utente

ACU-RITE

ACU-RITE 1502RX Manuale utente

ACU-RITE

ACU-RITE 00806SBDI Manuale utente

ACU-RITE

ACU-RITE 00593W Manuale utente

ACU-RITE

ACU-RITE 06035RM Manuale utente

ACU-RITE

ACU-RITE 13230 Manuale utente

ACU-RITE

ACU-RITE 4409999 Manuale utente

ACU-RITE

ACU-RITE 00251W Manuale utente

ACU-RITE

ACU-RITE 00275RM Manuale utente

ACU-RITE

ACU-RITE 01193 Manuale utente

ACU-RITE

ACU-RITE 2008 Manuale utente

ACU-RITE

ACU-RITE WIRELESS WEATHER STATION Manuale utente

ACU-RITE

ACU-RITE 01525 Manuale utente

Manuali Stazione meteorologica popolari di altre marche

Auriol

Auriol AHFL 433 A1 Manuale utente

NexSens

NexSens G2-HYDROMET Manuale utente

Hyundai

Hyundai WS 2202 Manuale utente

IROX

IROX HBVR761 UV-X Manuale utente

La Crosse Technology

La Crosse Technology C86371 Manuale utente

ADE

ADE WS 1711 Manuale utente

Auriol

Auriol z29592 Manuale utente

Auriol

Auriol 296289 Manuale utente

Hyundai

Hyundai WS 2266 Manuale utente

La Crosse Technology

La Crosse Technology WS-2210 Manuale utente

La Crosse Technology

La Crosse Technology WS-811561 Manuale utente

Ventus

Ventus W177 Manuale utente

National Geographic

National Geographic VA Colour RC Manuale utente

Renkforce

Renkforce 1208067 Manuale utente

Levenhuk

Levenhuk Discovery Report WA40 Manuale utente

Instant Transmission

Instant Transmission MA 10410 Manuale utente

Lutron Electronics

Lutron Electronics PHB-318 Manuale utente

WAREMA

WAREMA EWFS Weather station eco Manuale utente
