ACV N2 CONDENS Istruzioni per il montaggio

N 2 Condens : 664Y5000 • C

21.8 kW

N2 Condens

INSTALLATION, OPERATING AND

MAINTENANCE INSTRUCTIONS

2N 2 Condens : 664Y5000 • C

TABLE OF CONTENTS

GENERAL RECOMMENDATIONS .................................................................................. 4

USER GUIDE................................................................................................................................. 5

APPLIANCE DESCRIPTION................................................................................................. 6

TECHNICAL CHARACTERISTICS ................................................................................... 8

Electrical characteristics ..............................................................................................................8

Dimensional characteristics........................................................................................................9

Combustion characteristics......................................................................................................11

Hydraulic characteristics .......................................................................................................... 12

Characteristics of flue connection........................................................................................ 13

Operating limits.......................................................................................................................... 14

INSTALLATION .......................................................................................................................15

Contents included in delivery................................................................................................ 15

How to move the boiler........................................................................................................... 16

Tools required for installation ............................................................................................... 17

Installation instructions............................................................................................................. 17

Recommendations for preventing corrosion and scaling............................................. 19

Boiler preparation...................................................................................................................... 21

Fitting the burner .......................................................................................................................23

Electrical connection ................................................................................................................. 24

Flue connection...........................................................................................................................25

Hydraulic connections ..............................................................................................................26

Connection to a hot water tank.............................................................................................27

Fuel oil connection.....................................................................................................................28

N 2 Condens : 664Y5000 • C

TABLE OF CONTENTS

COMMISSIONING..................................................................................................................29

Commissioning safety instructions.......................................................................................29

Tools required for commissioning........................................................................................29

Checks before bringing into service....................................................................................29

Preliminary filling of the heating system ............................................................................30

Starting the boiler ......................................................................................................................30

Full flush of the heating system .............................................................................................30

MAINTENANCE.......................................................................................................................31

Safety instructions for maintenance..................................................................................... 31

Regular check............................................................................................................................... 31

Cleaning the combustion assembly ..................................................................................... 32

Inspection of safety devices ................................................................................................... 33

Draining of the boiler................................................................................................................ 33

Commissioning after maintenance ....................................................................................... 33

DECLARATION OF CONFORMITY - CE ...................................................................34

ROYAL DECREE DECLARATION OF CONFORMITY 17/07/2009 - BE .....35

4N 2 Condens : 664Y5000 • C

GENERAL RECOMMENDATIONS

These instructions contain important information necessary for the installation,

commissioning and maintenance of the boiler.

These instructions must be given to the user who should keep them in a safe place after

carefully reading them.

Important safety recommendations

It is strictly prohibited to modify the inside of the appliance in any way, without

the manufacturer's prior written agreement.

The appliance must be installed by a qualified engineer, in accordance with the local

regulations in force.

The installation must comply with the instructions contained in this manual as well

as the local regulations governing installations.

Failure to comply with the instructions of this manual may lead to personal injury

or a risk of environmental pollution.

The manufacturer does not accept any liability for any damage caused as a result

of incorrect installation or in the event of using appliances or accessories that are not

specified by the manufacturer.

Important recommendations for the correct operation of the appliance

In order to ensure the appliance operates correctly, it is important to have it serviced

each year by an approved contractor/installer.

If there is a problem please contact your installer for advice.

Faulty parts must only be replaced with genuine parts.

We accept no liability in the event of damage caused by failure to comply with the

instructions appearing in this technical manual.

1 2 3 4

5 6

N 2 Condens : 664Y5000 • C

USER'S GUIDE

1. Boiler on/off switch

2. Summer/winter switch (is used to turn the heating circulator on and off).

3. Safety warning indicator (lights up when the temperature of the flue gas or water of the

primary system is too high).

4. Thermo-pressure gauge (displays the boiler temperature and the pressure within the

primary system).

5. Manual reset safety thermostat (enables the boiler to be reset after overheating of the

primary water system).

6. Thermostat control (allows the boiler temperature to be set between 60°C for the minimum

position and 90°C for the maximum position).

Important recommendations for the correct operation of the appliance

If the boiler switches frequently to safety, contact your installer.

If your boiler is connected to a Domestic Hot Water (DHW) heating tank, make sure

that the temperature of the heating thermostat is higher than that of the DHW

thermostat in order to guarantee optimal operating conditions.

8 7 6 5

6N 2 Condens : 664Y5000 • C

The N2 Condens condensing fuel oil boiler is a heat generator that enables the water for the

central heating and DHW heater to be reheated (if the latter is connected to the boiler).

Key

1. Condenser

2. Flue outlet

3. Vent for measuring flue gas temperatures

4. Turbulators (6 parts)

5. Blue flame oil burner

6. Burner chamber plate with insulation brick

7. Boiler body

8. Thermal insulation

APPLIANCE DESCRIPTION

14 16

10 12

N 2 Condens : 664Y5000 • C

APPLIANCE DESCRIPTION

9. Minimum thermostat

10. Heating flow

11. Heating return

12. Removable panels

13. Condensate trap

14. Condensate exhaust hose

15. Electrical connection socket of the boiler

16. Connection socket of flue gas safety thermostat (optional)

17. Drain valve

L1 PEN

1211

2 3

T2T1

L1 PE

Bk G

Y/Gr

BR R

Y/Gr

G V Gr B

Y/Gr

8N 2 Condens : 664Y5000 • C

TECHNICAL CHARACTERISTICS

ELECTRICAL CHARACTERISTICS

Main electrical characteristics N2 Condens

Nominal voltage V~ 230

Nominal frequency Hz 50

Nominal intensity A 6

Wiring diagram

Key

1. On/Off switch

2. Minimum thermostat 45°C

3. Summer/winter switch

4. Safety thermostat

5. Burner

6. Safety warning indicator

7. Room thermostat (optional)

8. Installation heating pump (not provided)

9. Control thermostat of the boiler

10. Flue gas safety thermostat for flue pipe

(optional)

B : Blue

Bk : Black

Br : Brown

G : Grey

Gr : Green

R : Red

V : Violet

Y : Yellow

Y/Gr : Yellow/Green

760 mm

355 mm

650 mm

50 mm

235 mm

80 mm

105 mm

86 mm

N 2 Condens : 664Y5000 • C

TECHNICAL CHARACTERISTICS

DIMENSIONAL CHARACTERISTICS

Boiler dimensions N2 Condens

A= Width mm 470

B= Height mm 840

C= Depth mm 925

Volume of the combustion chamber dm342.3

Combustion chamber

Height mm 295

Width mm 330

Depth mm 435

Empty weight kg 155

910

10 N 2 Condens : 664Y5000 • C

TECHNICAL CHARACTERISTICS

Overall dimensions of boiler N2 Condens

Recommended Minimum

A (mm) 800 650

B (mm) 1000 900

C (mm) 600 400

D (mm) 150 100

The two lateral rear panels allow access to the components inside the boiler from the left or right hand side.
