Adam Equipment SHS Series Manuale utente

AdamEquipment



SHS/SHSaSERIES(EN)

SERIESHS(FR)

SHSSERIE(DE)

SerieSHS(IT)

(P.N.7.00.6.6.0202,RevisionBNovember2012)

SoftwareversionS1.1/SA1.1



ENGLISH: P 1 - 13

FRANÇAIS: P 14 - 27

DEUTSCH: P 28 - 41

ITALIANO: P 42 - 55

EU DECLARATION: P 56



EN

1.0 CONTENTS



1.0 CONTENTS ............................................................................................ 1

2.1 FEATURES .......................................................................................... 2

2.2 TECHNICAL SPECIFICATIONS ......................................................... 3

2.3 SAFETY NOTICE ................................................................................ 4

2.4 KEY AND PANEL DESCRIPTION ....................................................... 5

2.5 DISPLAY INDICATIONS WITH LED ................................................... 6

3.0 OPERATION ........................................................................................... 6

3.1 SAFETY INSTRUCTIONS ................................................................... 6

3.2 BATTERY OPERATION ...................................................................... 7

3.3 BASIC OPERATIONS ......................................................................... 8

3.4 REMOTE CONTROL UNIT ................................................................. 9

3.5 USER PARAMETERS ......................................................................... 9

4.0 CALIBRATION ................................................................................... 10

5.0 PARTS LIST ......................................................................................... 11

WARRANTY INFORMATION ....................................................................... 13

EN

2.0 INTRODUCTION

2.1 FEATURES



TheSHS/SHSaSeriesarearangeofheavy‐dutylowercapacitycranescales

Themainfeaturesinclude:

 EasyOperation&Ruggedconstruction

 15mmbrightredLEDdisplayenablingagoodviewingangle.

 360degreerotarysafetyhookandsupportringdesign

 Overloadsafetyupto150%ofmodelcapacity

 Selectableweighingunitsincludekg,LbsandNewtons(Newtonsnot

availablefor“a”models)

 StandardandPeakHoldfeature

 Internallithiumbatteryfittedasstandard

 AlternativepowerfromAAorNiMHbatteries

 Autopoweroffafter30minutesofnonuse

 8.4Vdc800mabatterycharger

 StrongABSplastichousing

 Infraredremotecontrol



EN

2.2 TECHNICALSPECIFICATIONS



ModelNo Capacity Division ModelNo Capacity Division

SHS50 50kg 0.01kg SHS 100a 100lb/50kg 0.02lb/0.01kg

SHS150 150kg 0.02kg SHS 300a 300lb/150kg 0.05lb/0.02kg

SHS300 300kg 0.05kg SHS 600a 600lb/300kg 0.1lb/0.05kg



EN

2.3 SAFETYNOTICE



ThelimitstatedbelowistheUltimateOverloadLimitsofthescales.

Adam Equipment Co. Ltd. Its directors, owners and affiliated companies and

organisationscannotbeheldliableforanyresultingdamageorinjurysustainedasa

resultofthemachinesbeingusedinexcessoftheirstatedcapacities or ultimate

overloadlimits.



ModelNo. SHS50/SHS100a SHS150/SHS300a SHS300/SHS600a

Max

capacity  50kg/100lb 150kg/300lb 300kg/600lb

Overload

capacity 100kg/200lb 300kg/600lb 450kg/900lb

NOTICE:

Donotusethescalesifanypartsarebentorlooseorshowsignsofdamageorwear.

Refertotheusermanual.

EN

2.4 KEYANDPANELDESCRIPTION



[ON/OFF] Thepowerswitchislocatedontherearhousing.Usethiskeyto

turnthescaleONandOFF.

[Zero] Pressthe[Zero] keytoreturnthereadingtozero.

[Unit]

Pressthe[Unit] keytochangetheweighingunitbeingdisplayed

between Kg, Lbs and Newtons (Newtons not available for “a”

models)

[Hold]

Use this key to activate standard Hold. When pressed the Hold

LEDwilllightatthetopleftsideofthedisplayandthereadingon

the display will lock and flash. Press the [Hold] key again to

cancelthe[Hold]function.

*WhenPeakholdisselectedfromtheparametersectionthe

pressoftheHoldkeywillactivatePeakHold.TheHoldLEDwill

flash and the display will also flash and lock showing the

maximumweightregisteredofasingleweighingprocess.

Pressthe[Hold]keyagaintocancelthe[Hold]function.



EN

2.5 DISPLAYINDICATIONSWITHLED

KglbN WeighingunitIndicator

LowbatteryIndicator

Hold HoldIndicator

Stab StableIndicator

3.0 OPERATION

3.1 SAFETYINSTRUCTIONS

ReadthismanualcarefullybeforeyouoperatetheSHSCraneScale.

 UnpacktheCraneScalecarefullyfromthepackaging.

 Attachittoyourhoistorequivalentexistingequipmentsecurelyatthe

groundleveltothesupportringintheuprightposition.Makesurethat

theequipmenttowhichthescaleisattachedisinpropercondition.The

operatorshouldbetrainedforitssafeoperation.

 Carryoutregularvisualinspectionforanydamageorwearandtearon

parts.Thesplitpinsinparticularatthehookandeyebolts,aswellasthe

innerwallofthehookandalljointsshouldbecheckedregularly.Ifany

damageorwearhastakenplace,stopusingthescaleandreplacethe

parts.

 Doallinspectionandmaintenanceworkwhenthescaleisnotinuse.

 Donotexposethescaletoextremetemperatures.Theoperating

temperaturerangeis0°Cto40°C.

 Securethesampletobeweighedinthehookofthescale.Ensurethat

the sprung Safety Lever returns to its resting position which prevents

thesamplefromslippingoutofthehook.

 DonotexceedthemaximumcapacityoftheScale.

EN

 Cleanandprotectyourscaleafteruse.

OverloadWarning

Please do not add any item that exceeds the maximum capacity ofthescale.

Whenthedisplayshows”- - - - - ”removetheitemtoavoiddamagetotheload

cellandscale.



3.2 BATTERYOPERATION



 The lithium battery will operate continuously for 20 hours before

requiringrecharging.Thescalewillalertyouthatthebatteryislowon

chargewhentheIndicatorLEDabovethebatterysymbollightsup.

 Tochargethebattery,unclipthebatterycoverontherearofthescale

andinserttheconnectorintothesocketasmarked.Plugthecharger

intothemainspowersupplyandwaituntiltheLEDonthecharger

showsgreen.Thebatteryisnowfullycharged.

 Chargingtimeforacompletelydischargedbatteryisapproximately16

hours. A full battery pack is recommended to keep the scale

continuouslyoperational.

 Onlyusethechargerassuppliedwiththeunit.

 TheswitchinsidethebatterycovermustbeinpositionAtomakeuse

ofthelithiumbattery.

 IfusingAAorNiMHbatteriestheswitchmustbeinpositionB

 Thescalewillautomaticallypowerdownafter30minutesofnonuseto

furtherprotectthebattery.

 Toreplacethelithiumbatterypackpleasecontactyourdealer



EN

3.3 BASICOPERATIONS

Poweronandoff

Pressthe[ON/OFF]buttontoturnthescaleonoroff.Thedisplayonthescale

willshowthemodelcapacitythencountdownfrom9to0beforedisplayingzero

weight.



Zerothescale

Pressthe[Zero]keysothatthedisplayshowszero.



ChangetheweighingUnit

Pressthe[Unit]keytochangetheweighingunit



StandardHold(setting1)

When the reading may not be perfectly stable or you cannot viewareading

easilyyoucanpressthe[Hold]keytolockit.Thereadingwillbelockedandalso

flashatthepointyoupressthe[Hold]buttonenablingyoutoviewitwhenyou

can.TheHoldLEDwillalsolightupandonceyouhavenotedthereadingapress

ofthe[Hold]keywillreturnthescaletothenormalweighingmode.



PeakHold(setting0)

PeakHoldisthehighestweightreadingregisteredbythescalewhenaweighing

takesplace.Pressthe[Hold]keywhenthedisplayisatzeroandtheHoldLED

willflashwhichdenotesPeakHoldhasbeenactivated.Whenweight/force is

appliedtothescalethedisplaywillalsoflashandlockthehighest recorded

weightofthatweighingprocess.ThisvalueandtheHoldLEDwillremainflashing

onthedisplayuntilthe[Hold]keyispressedagainatwhichpointthescalewill

returntonormalweighingmodedisplayingthecurrentweightonthescale.

Press[Hold]againtoperformanotherPeakHoldweighingatanytime.
