Adesso ATP-400 Manuale utente

Browser Cat

Easy Cat

Smart Cat

Smart Cat Pro

USER’S MANUAL

TABLE OF CONTENTS

1.0 SYSTEM REQUIREMENTS.............................................................................................................1

HARDWARE REQUIREMENTS........................................................................................................1

SOFTWARE REQUIREMENTS.........................................................................................................1

2.0 INSTALLATION INSTRUCTIONS...................................................................................................2

CONNECTING YOUR TOUCHPAD TO THE COMPUTER..............................................................2

INSTALLING YOUR GLIDEPOINT DRIVER SOFTWARE................................................................3

3.0 USING YOUR GLIDEPOINT®TOUCHPAD ..................................................................................3

BASIC FUNCTIONS ..........................................................................................................................3

ADVANCE FUNCTIONS....................................................................................................................4

HORIZONTAL SCROLL.....................................................................................................................4

ZOOMING..........................................................................................................................................5

BACK / FORWARD PAGE CONTROL..............................................................................................5

PRODUCT FEATURES.....................................................................................................................5

4.0 CUSTOMIZING YOUR TOUCHPAD FEATURES...........................................................................6

USING THE GLIDEPOINT® CONTROL CENTER............................................................................6

5.0 CUSTOMER SERVICE....................................................................................................................6

TROUBLESHOOTING.......................................................................................................................6

FREQUENTLY ASKED QUESTIONS ...............................................................................................7

CUSTOMER SERVICE ASSISTANCE..............................................................................................7

6.0 WARRANTY INFORMATION..........................................................................................................8

7.0 FCC REGULATORY NOTICE .........................................................................................................8

1.0 SYSTEM REQUIREMENTS

HARDWARE REQUIREMENTS

The Browser Cat™, Smart Cat Pro™, Smart Cat™and Easy Cat™Touchpads require a

PC-compatible computer. USB versions require a PC-compatible computer with

available USB port.

SOFTWARE REQUIREMENTS

GlidePoint®touchpads operate as a standard mouse on the PC platform and require

no additional software for basic functions.

The GlidePoint®driver software adds additional features and

control to the touchpad. The GlidePoint®driver is only

available for the Windows®operating systems. Look up your

operating system and connection type in the following table to

determine the version of the GlidePoint®driver software you

will need.

The USB version of

the Easy Cat™also

runs on Apple®

Macintosh®computers

with available USB

orts.

USB PS2

Operating

System

Driver

Requirements

For Windows Vista/XP/2000

users:

Touchpad supports most of the

advanced features such as,

Horizontal Scrolling, Zoom

In/Out, Back and Forward

functions

(Glidepoint Touchpad driver

version 3.3 required)

For Windows ME and 98 users:

It is Plug and Play and acts as

a basic mouse functions with

vertical scrolling.

For Windows Vista/XP/2000 users:

Touchpad supports most of the

advanced features such as,

Horizontal Scrolling, Zoom In/Out,

Back and Forward functions

(Glidepoint Touchpad driver

version 3.3 required)

For Windows ME, 98 and NT users:

It is Plug and Play and acts as a

basic mouse functions with

vertical scrolling.

Note:

Driver version 3.3 is available on the CD included with your touchpad. Version 3.3 is

also available for download online at

http://www.adesso.com/drivers/glidepoint.zip

For the additional advanced features of Glidepoint Touchpad for Windows 98 & ME

users, you will need to download the Glidepoint Version 2.6 driver which is

available at:

http://www.adesso.com/drivers/glidepoint2.6.zip

1 of 8

2.0 INSTALLATION INSTRUCTIONS

CONNECTING YOUR TOUCHPAD TO THE COMPUTER

USB

1) Turn your computer on and start Windows.

2) Attach the USB connector to your computer.

3) If you see the “New Hardware Found” dialog box after connecting the touchpad, follow

the prompts (insert your Windows CD if prompted) to install a standard HID compliant

mouse.

4) Test the touchpad; it should operate with your existing drivers.

PS/2

1) Turn the power to your computer off.

2) Attach the PS/2 adapter to your computer

NOTE: Because the PS/2 ports for both touchpad and keyboard may appear identical,

look for an icon or description next to each port on your computer to identify which to

use.

3) Turn your computer on and start Windows. If you see the “New Hardware Found” dialog

box after Windows starts, select CANCEL and continue with the next step.

4) Test the touchpad; it should operate with your existing drivers.

For Macintosh

installation

(

B version only

)

1) Turn your computer on.

2) Attach the USB connector to your computer. Your Macintosh®should detect the touchpad immediately when you

plug it in.

2 of 8

INSTALLING YOUR GLIDEPOINT®DRIVER SOFTWARE

1) Please be sure that your touchpad is properly connected to your PC.

2) Insert the Glidepoint ® 3.3 software CD into your CDROM.

3) If the Auto Run feature does not launch the Windows Installer, select RUN from the START menu

and type D:\setup (where d is the drive letter of your CD-ROM)

4) The setup wizard will now appear advising you that “The installer will now guide you through the

installation process of your Glidepoint® Software”.

Single Click on next to continue

5) Read the end user license agreement and click on button to accept the terms of agreement.

Single click on next to continue.

6) Choose your type of installation. If you’re using a PS/2 touchpad, select “install driver for a ps/2

touchpad. If you’re using a USB touchpad select, “install driver for a USB touchpad”.

Single click on next to continue.

7) Installer will automatically install you’re the program files directory. If you don’t wish to change this,

single click on next to continue.

8) Confirm installation by single clicking on next.

Glidepoint® will now begin to install on your PC. This may take a few moments. Once Glidepoint is

installed, you will be notified and single click on close to exit the installation.

9) Open the GlidePoint® Control Center and adjust the touchpad settings to suit your needs. (For more

information on customizing your touchpad, refer to “How can I customize my touchpad” on page 6)

Upon installation, the touchpad allows you to tap, right-tap, drag and highlight

without the use of an Adesso driver. The Glide Extend virtual edge extender and the

wheel mouse scrolling feature are also available.

To use additional custom options, advanced Horizontal scroll, zoom In, zoom out,

Back and forward capabilities you must install the Adesso Glidepoint®driver software

contained on your Adesso GlidePoint®software CD or available by download from

http://www.adesso.com/drivers/glidepoint.zip

3.0 USING YOUR GLIDEPOINT®TOUCHPAD

BASIC FUNCTIONS

Unlike the mouse or trackball, Glidepoint®touchpad

requires little arm and wrist motion and no finger

pressure. Like all pointing devices, you may take a

short time to become familiar with the operation of

your touchpad. Yet you will soon find that using your

finger is a more natural and intuitive way to control

your computer. Simply glide your finger across the

surface of the pad to move the cursor and tap your

finger to “click”. It’s easy!

3 of 8

•To click, lightly and quickly tap the surface of

the pad once. Or, press the left button once.

•To double-click, tap twice on the pad or click

the left button twice. Remember, the touchpad

responds to a very light, crisp tap.

•To right-click for sub-menus, tap the tap zone in the upper right corner of the

touchpad or click the right button once.

•To drag, draw, or highlight, double-tap

rapidly and hold your finger down on the

second tap, then glide to move. You may

also hold the left button as you glide your

finger.

Right-click and scroll

features require third

party software on

Macintosh®systems (see

side note below).

•GlideExtend®. To drag further than the pad surface, lift and reposition your

finger after reaching the textured edge. GlideExtend®will virtually eliminate the

edge of the pad while you drag. In other words, if you are dragging an item and

you reach the textured edge, GlideExtend®will hold the drag function active for

three seconds while you reposition and complete the drag.

To shut off GlideExtend®earlier than three seconds, simply

tap or click a button.

•Vertical Scroll, place your finger down the right edge of

the touchpad and glide up or down.

ADVANCE FUNCTIONS

Your Adesso touchpad represents the latest in

“capacitive touch” technology. All products are

designed to give you the highest level of

performance and include advanced features not

available from the standard mouse. (For more

information on customizing your touchpad, refer to

“How can I customize my touchpad” on page 6.)

For Macintosh®, right-click submenu

access and wheel-mouse scrolling require

the installation of third party software named

*USB Overdrive. If interested in these

features, you may download the latest

version at www.usboverdrive.com.

*Adesso does not support USB overdrive and is

not responsible for any problems related to or

caused by the software. Contact USB Overdrive

for technical assistance and support regarding the

software.

HORIZONTAL SCROLL

Horizontal Scrolling will allow you to move around

in a scrollable document from left to right for fast

browsing.

4 of 8

ZOOMING

This allows you to increase or decrease the view size of your document in most

Microsoft®Windows®applications.

BACK / FORWARD PAGE CONTROL

You can use Adesso’s back/forward feature to activate the back and forward

controls of various applications such as Microsoft®Internet Explorer®and Netscape

Navigator®.

PRODUCT FEATURES

The following table summarizes the features available in your product.

Features Browser Cat™Easy Cat™Smart Cat™Smart CatPRO™

Standard size touchpad X X

Extra-large size touchpad X X

Middle mouse button X X

Vertical scroll X X X X

Left / Right mouse buttons X X X X

Taps X X X X

Taps & Drag X X X X

Horizontal scroll X X X X

Zoom control X X X X

Back / Forward page control X X X X

Touchpad rotation X X X X

Tapping control X X X X

Cursor movement control X X X X

Number of mechanical buttons 2 2 3 3

Number of programmable touchpad

zones 1 1 1 1

Number of programmable hot

buttons 0 0 0 4

Please Note: Features within the shaded area require the use of the Adesso driver software.

Touchpad buttons and tap zones can be programmed to launch applications, open

files or execute specific Windows®functions. A tap zone and mechanical buttons are

available on all touchpad models. The Smart Cat Pro has four additional

programmable buttons (labeled A through D) on the touchpad surface.

Your Adesso touchpad represents the latest in “capacitive touch” technology. All

products are designed to give you the highest level of performance and include

advanced features not available from the standard mouse. (Glidepoint®touchpads

driver required!)

5 of 8

4.0 CUSTOMIZING YOUR TOUCHPAD FEATURES

USING THE GLIDEPOINT®CONTROL CENTER

Your GlidePoint®touchpad settings, such as speed or button assignments, may be

customized through the GlidePoint®Control Center. The GlidePoint®Control Center is

only available if you have installed the GlidePoint®driver software (see “Installing your

GlidePoint

driver software” pg. 3.)

The GlidePoint®Control Center can be accessed through the start menu by going to:

Start > (All) Programs >GlidePoint > Glidepoint®Control Center

or you can access it through the Control Panel as displayed below. (Refer to your

Microsoft documentation for information on accessing Control Panel for your version of

Windows)

( Please Note: These instructions only apply for Windows Vista, XP and 2000.)

5.0 CUSTOMER SERVICE

To customize settings on a Macintosh®for your CyberCat™, go to the

pple menu >Control Panel > Mouse.

TROUBLESHOOTING

Your GlidePoint®touchpad should work immediately when connected to your

computer. If you have trouble:

•Check all connections to be sure they are secured to the correct ports and then

restart the computer.

•Check Questions and Answers at http://www.adesso.com/touchpad_faq.htm

•Check the following list of frequently asked questions to see if your questions can

be easily answered.

•Should you need additional help, call Adesso’s toll-free technical support at

1-800-467-1195. Support hours are Monday through Friday 9:00 am – 5:30 pm

PST.

6 of 8

FREQUENTLY ASKED QUESTIONS

What if I have trouble tapping or dragging on the touchpad?

If you have difficulties clicking or using highlight operations by tapping on the

touchpad’s surface:

•A light, quick tap will work best. The touchpad does not require pressure, and

hard taps may actually slow your typing.

What if using the touchpad is causing discomfort in my hand or wrist?

If you experience discomfort while using your touchpad:

•Try to relax your hand while pointing and tapping. Arching or flexing your hand

over the touchpad will cause unnecessary strain.

•Your touchpad responds to the lightest touch, so you can use your index finger,

your middle finger, or even your thumb to point and tap. If you find it

uncomfortable to reach toward the device on your desktop, hold it in your other

hand or on your lap.

How can I customize my touchpad settings?

The GlidePoint®Control Center is complete with

context sensitive help.

•You must install the GlidePoint®software

driver in order to customize your touchpad

features. (Refer to “Installing your

GlidePoint

driver” on page 3)

•To access the GlidePoint®Control Center go

to: Start > (All) Programs > GlidePoint®>

Glidepoint®Control Center.

•Once inside the GlidePoint®Control Center

you will click on the appropriate tab that

matches the features you want to customize.

•Click on the help button on any tab to get

information on customizing those features.

CUSTOMER SERVICE ASSISTANCE

To learn more about operating your GlidePoint®touchpad or if you need further

assistance, contact Adesso at:

•Web site: www.adesso.com

•E-mail address: [email protected] (please use a return e-mail address)

•Support line: 800-467-1195 Monday through Friday 9:00 am – 5:30 pm PST.

•Fax line: 909-839-2930

•

7 of 8

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Adesso Accessori per computer

Adesso

Adesso NuScan 510 Manuale utente

Manuali Accessori per computer popolari di altre marche

Motorola

Motorola ATRIX Manuale utente

HP USB Media Docking Station Manuale utente

Cherry

Cherry B.UNLIMITED 3.0 Manuale utente

Logitech

Logitech IO2 Manuale utente

ARM

ARM DSTREAM-ST Manuale utente

Bartec

Bartec TC 7 Series Manuale utente

Philips

Philips SPC3540 Manuale utente

Logitech

Logitech mk220 Manuale utente

SilverStone

SilverStone LC02 Manuale utente

Flexispot

Flexispot ML2B Manuale utente

Hamlet

Hamlet UNIVERSAL COVER 101 KBT2 Manuale utente

Adam Equipment

Adam Equipment RS-485 Manuale utente

Vivo

Vivo MOUNT-KB05-4DW Manuale utente

Kvaser

Kvaser Memorator Professional Manuale utente

DRC

DRC D-Imaging Manuale utente

Sven

Sven Base 305 сombo Manuale utente

Hama

Hama 108310 Manuale utente

SpeechWare

SpeechWare FlexyMike FMK03 Manuale utente
