ADIC FastStor 22 Manuale utente

Follow the steps in this guide to

quickly get started using your

FastStor 22

Advanced Digital Information Corporation

Corporate Headquarters

11431 Willows Road NE Redmond, WA 98052

Telephone: (425) 881-8004

Fax: (425) 881-2296

ADIC Europe

ZAC des Basses Auges

1, rue Alfred de Vigny

78112 -Fourqueux, FRANCE

Fax: 33 (0)1 30 87 53 01

World-Wide Web: http: //www.adic.com

For Customer Assistance:

In the United States and Canada, call ADIC Technical Assistance Center

(ATAC) at 1-800-827-3822

In Europe, call ADIC Technical Assistance Center

(ATAC) at 00.800.9999.3822

33 (0)1 30 87 53 00Telephone:

Document Number 62-2204-01 rev B

FastStor 22

Quick Start

Guide

FastStor

For summary of common operations

consult the label

inside the FastStor 22 door.

KEYPAD OPERATIONS

Selected Indicators and Controls

DC DC on LCD indicates compression

mode.

WP WP on LCD indicates write-

protected tape.

CT CT on LCD indicates cleaning

tape loaded or drive cleaning

required.

LCD

LEDs

ALARM LED indicates error

condition.

ACTIVITY LED indicates Loader

or Drive activity.

POWER LED indicates Power

is on.

Press MODE to select operations,

or to clear error condition.

Buttons

Press SELECT to execute an

operation or to move to next menu

level.

Press NEXT/PREVIOUS to view

options within a selected mode.

FastStor

TAPE

Your FastStor 22 is now ready to perform

a backup or restore operation via your

Host Computer.

Note:

The SCSI ID of the FastStor

robotics has been factory set to

1 and the drive to 3.

Install SCSI terminator.

Install data cartridges into front storage

slots 1-11.

Connect AC line cord to FastStor 22,

then to AC outlet.

Connect SCSI cable between host

computer and FastStor 22.

Install additional data cartridges in slots

1-11.

Rear Slot Indicator LEDs will Illuminate

indicating cartridge presence.

Verify your backup software.

Press SELECT button, tapes in front

slots will be moved to rear slots 12-22.

Power up your Host Computer.

Press button. is

displayed on LCD.

SELECT SNgL LOAd

Press button until

displayed on LCD.

MODE LOAd SLOT is

Press button,

displayed on LCD.

NEXT bULK LOAd is

Press Power button to power up your

FastStor 22.

POWER

MODE

SELECT

ALARM

ACTIVITY

POWER

ALARM

ACTIVITY

POWER

SELECT

MODE

POWER

MODE

SELECT

ALARM

ACTIVITY

POWER

MODE

SELECT

ALARM

ACTIVITY

POWER
