ADT Pulse®Interactive Solutions

iCamera-1000-ADT Indoor

Low-Light Camera

Installation Guide

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Table of Contents

WELCOME ..................................................................................................................... 1

Overview .......................................................................................................................1

iCamera-1000-ADT Features ...................................................................................1

Package Contents .......................................................................................................2

Physical Details –iCamera-1000-ADT....................................................................3

Front Panel ............................................................................................................3

Rear Panel..............................................................................................................4

Configuring and Installing the iCamera-1000-ADT .............................................5

Adding the iCamera-1000-ADT to your ADT Pulse Wireless Network ...........6

iCamera Wall Mounting Instructions ................................................................... 11

PIR Video Motion Detection................................................................................... 14

Enabling Motion Detection via the ADT Security System ....................... 15

APPENDIX A SPECIFICATIONS ............................................................................. 17

Regulatory Approvals .............................................................................................. 17

CE Approvals...................................................................................................... 18

License information available at www.ADT.com or by calling 800.ADT.ASAP.

CA ACO7155, 974443; PPO17232; FL EF0001121; LA F1639, F1407,

F1640; MA 172C; NY 12000305615; PA 090797;

MS 15019511

logo, 800 ADT.ASAP and the product/service names listed in this document are

marks and/or registered marks. Unauthorized use is strictly prohibited.

P/N: 956YFF0001

Document Version: 1.2

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Welcome

This installation guide provides step-by-step instructions for configuring

and installing your iCamera-1000-ADT Indoor Low-Light camera to your

ADT Pulse®wireless network. (Permanent mounting instructions for the

iCamera are also included.)

Overview

The iCamera-1000-ADT monitors your home or business in a low light or dark

environment. The iCamera can be used as either a wired or wireless camera

using Wi-Fi connectivity that easily installs to your ADT Pulse wireless network.

iCamera-1000-ADT Features

Requires only a power source and a connection to the gateway

Dust and Water Resistant

12 infrared LEDs allow you to view images in a dark or low light setting

Can be used as a wired or wireless device

Diagonal View Angle of 60 degrees

VGA (640x480)

View images in color

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Package Contents

1. The iCamera-1000-ADT Indoor Low-Light Camera

2. Stand

3. Y-Cable

4. PoE Cable

5. 12V Power Adapter

6. Assembly Back Plate with three screws (packaged separately)

7. Wall Mount Plate

8. Two Mounting Screws

9. Installation Guide

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Physical Details –iCamera-1000-ADT

Front Panel

Figure 1: Front Panel

1. Light Sensor

Detects lighting conditions.

2. IR LEDs

The LEDs help you see clearly at night or in a dark

environment.

3. Day Camera Lens

The Day Camera Lens is used in a bright environment.

4. Night Camera

Lens

The Night Camera Lens is used in a dark environment.

5. Power/Wi-Fi

On (Green) - Power on.

Off - Power off.

Blinking - Data is being transmitted or received.

Blinking Slow - Weak strength of Wi-Fi signal. (1/2 Hz,

SNR < 15 dB.)

Blinking Medium - Strength of Wi-Fi signal is normal.

(1/2 Hz, SNR < 15 dB.)

Blinking Fast - Good strength of Wi-Fi signal. (1/2 Hz,

SNR < 15 dB.)

6. Network LED

On (Green) - Power on.

Off - No Active connection on the LAN port, or not

associated with Wireless AP.

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Rear Panel

Figure 2: Rear Panel

1. LAN Port

Use in conjunction with the supplied LAN cable to

connect your iCamera to the ADT Pulse Gateway.

2. Stand Mount

The stand mount connects the stand to the iCamera.

3. Reset Button

The reset button has two (2) functions:

Reboot. When the reset button is quickly pressed

then released, the iCamera reboots.

Clear All Data. To Clear All Data and restore the

factory default settings:

1. Power On.

2. Press and hold the Reset Button for eight

seconds.

When you release the Reset button, the iCamera is

reset to the factory default settings.

IMPORTANT

THE RESET BUTTON WILL RESET THE iCAMERA

COMMUNICATION CONFIGURATION SETTINGS AND

SHOULD ONLY BE USED UNDER THE DIRECTION OF

ADT SUPPORT.

NOTE

The default Wireless settings are:

Mode: Infrastructure

SSID: ANY

Wireless Security: Disabled

Domain: USA

Channel No.: Auto

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Configuring and Installing the iCamera-1000-ADT

The following instructions provide details of configuring and installing the

iCamera-1000-ADT Indoor Low-Light Camera to your ADT Pulse network.

Initial setup is done only one time to configure the iCamera’s wireless settings to

the ADT Pulse Gateway.

Figure 3: Initial Setup

1. Connect the LAN Cable to the iCamera

a. Connect the LAN Cable to the LAN Port located on the back of the

iCamera.

b. Place the other end of the LAN Cable into the LAN Port of the Y-Cable.

2. Connecting the Y-Cable to the Gateway

c. Connect the Y-Cable (with Ethernet) into the Device LAN port of the

gateway.

3. Connecting the Power Source

d. Connect the Y-Cable power adapter into the power source. Once

connected, plug the power source into an electrical outlet.

IMPORTANT

DO NOT USE ANY POWER ADAPTER OTHER THAN THE

ONE SPECIFIED. DOING SO MAY DAMAGE THE

DEVICE.

NOTE

During start up, the Power LED displays for approximately 10 to 15

seconds. When installation is complete, the Power LED should

remain ON as well as the Network LEDs.

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

Adding the iCamera-1000-ADT to your ADT Pulse

Wireless Network

1. Open your web browser. In the address bar, type:

https://Portal.ADTPulse.com.

2. Type your Username and Password, and then click the Sign In button.

3. Click the System tab, and then click the Manage Devices button.

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

4. In the Manage Devices Assistant, click Cameras.

5. Click the picture of the iCamera or select it from the drop-down list, and then

click the Continue button.

ADT Pulse®Interactive Solutions iCamera-1000-ADT Indoor Low-Light Camera

Installation Guide

6. Assign the iCamera a unique name (this is usually based on the location of

the iCamera) in the space provided, and then type the iCamera’s MAC ID or

Server Name.

7. Click the Continue button.

8. Connect the camera to the Device Port of the gateway using the Ethernet

cable (attached to the Y-Cable.)
