ADTRAN TSU LT Manuale utente

TSU LT P/N 1203060L1

For more detailed documentation, visit us online at www.adtran.com

Quick Start Guide

NETWORK CONNECTION PINOUT

Pin Name Description

1 R1 RXDATA Receive data from the Network - Ring

2 T1 RXDATA Receive data from the Network - Tip

3, 6, 7, 8 UNUSED n/a

4 R TXDATA Transmit data towards the Network - Ring

5 T TXDATA Transmit data towards the Network - Tip

INSTALLATION INFORMATION

• An eight-position modular jack (labeled NETWORK) connects to the T1

network circuit. The pinout is shown below, right, on this Quick Start

Guide. See Chapter 2 of the TSU LT User Manual (P/N 612003060L1-1A)

for more information.

• The rear panel contains a single V.35 interface for connecting to DTE

equipment. The pinout for this interface is provided on the back of this

Quick Start Guide.

• When shipped from the factory, the TSU LT is uninitialized and set to

factory default conditions. When first powered up, the unit automatically

executes self-tests, followed by an initialization sequence.

• The TSU LT can be configured and controlled using the local front panel

of the unit, by a direct or remote serial connection via the control port, or

by ADTRAN’s PC-based management software package,

T-Watch PRO®. A limited menu tree is provided on the back of this sheet.

For more detailed menu information, refer to Appendix A of the TSU LT

User Manual.

• The product CD contains additional information such as the TSU LT User

Manual, FAQs, Data Sheets, Applications, and White Papers.

REAR PANEL DESCRIPTIONS

Network Connector Connects to T1 circuit

Test Interface Bantam jacks for monitoring and testing

a T1 circuit

Control Chain-In/Chain-Out Connects to a VT100 terminal

V.35 Connector High-speed DTE interface

115 VAC Connection Power cord connection for a reliably

grounded 115 VAC, 60 Hz power source

(power cord ships with unit).

NETWORK TEST JACKS

CONTROL

CHAIN IN

IN OUT MON

CHAIN OUT

V.35 Nx56/64 115VAC 60HZ .15A

TSU LT P/N 1203060L1

Quick Start Guide

MENU TREE - OVERVIEW

1) NI PERF RPRTS

1) STATUS 2) CURR ERR/ALM

3) ERR/ALM HIST

1) NETWORK (NI)

2) CONFIG 2) UNIT

MAIN MENU 3) PORT

1) SOFTWARE REV

2) REINIT UNIT

3) UTIL 3) ADDRESS

4) SET PASSCODE

5) KEYPAD

6) FACT RESTORE

1) NETWORK TESTS

4) TEST 2) RUN SELF–TEST

3) PORT TESTS

V.35 CONNECTOR PINOUT

Pin CCITT Description

A 101 Protective ground (PG)

B 102 Signal ground (SG)

C 105 Request to send (RTS) from DTE

D 106 Clear to send (CTS) to DTE

E 107 Data set ready (DSR) to DTE

F 109 Received line signal detector (DCD) to DTE

H — Data terminal ready (DTR) from DTE

J — Ring indicator (RI)

L — Local loopback (LL)

N — Remote loopback (RL)

R 104 Received data (RD-A) to DTE

T 104 Received data (RD-B) to DTE

V 115 RX clock (RC-A) to DTE

X 115 RX clock (RC-B) to DTE

P 103 Transmitted data (TD-A) from DTE

S 103 Transmitted data (TD-B) from DTE

Y 114 TX clock (TC-A)

AA 114 TX clock (TC-B)

U 113 External TX clock (ETC-A) from DTE

W 113 External TX clock (ETC-B) from DTE

NN&K — Test mode (TM) to DTE

COMPLIANCE

Double pole/neutral fusing.

The socket-outlet shall be installed near the equipment and shall be easily

accessible.
