Advance acoustic Adfinity 17ST Manuale utente

AdnityTM 17ST / 20ST

20D / X20D / X20C / X24D

SERVICE MANUAL

Advance model: 908 7161 020 - 908 7162 020

- 908 7163 020 - 908 7164 020 - 908 7165 020

- 908 7166 020

9096982000(1)2007-02

ENGLISH SERVICE MANUAL

29096982000(1)2007-02 AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D

SERVICE MANUAL ENGLISH

AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D 9096982000(1)2007-02 3

TABLE OF CONTENTS

GENERAL INFORMATION......................................................................................................................................... 5

CONVENTIONS ..................................................................................................................................................... 5

MACHINE LIFTING ................................................................................................................................................ 5

MACHINE TRANSPORTATION ............................................................................................................................. 5

OTHER REFERENCE MANUALS ......................................................................................................................... 5

SAFETY ................................................................................................................................................................. 5

SYMBOLS .............................................................................................................................................................. 5

GENERAL INSTRUCTIONS .................................................................................................................................. 5

TECHNICAL DATA (For AdnityTM 17 ST, 20 ST) ................................................................................................... 7

TECHNICAL DATA (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ......................................................................... 8

MAINTENANCE ..................................................................................................................................................... 9

SCHEDULED MAINTENANCE TABLE ................................................................................................................. 9

MACHINE NOMENCLATURE (For AdnityTM 17 ST, 20 ST)................................................................................ 10

MACHINE NOMENCLATURE (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D)...................................................... 12

SOLUTION/CLEAN WATER SUPPLY SYSTEM ...................................................................................................... 15

SOLUTION/CLEAN WATER TANK AND SUPPLY SYSTEM CLEANING............................................................ 15

SOLUTION FILTER CLEANING (For AdnityTM 17 ST, 20 ST) ............................................................................ 15

SOLUTION FILTER CLEANING (For AdnityTM 20 D) ......................................................................................... 16

SOLENOID VALVE DISASSEMBLY/ASSEMBLY (For AdnityTM 17 ST, 20 ST) ................................................. 16

SOLENOID VALVE DISASSEMBLY/ASSEMBLY (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D)......................... 17

TROUBLESHOOTING ......................................................................................................................................... 17

AXP .......................................................................................................................................................................... 19

CLEAN WATER FILTER CLEANING (For AdnityTM X 20 D, X 20 C, X 24 D)..................................................... 19

DETERGENT TANK CLEANING (For AdnityTM X 20 D, X 20 C, X 24 D) ........................................................... 20

AXP DRAINING (For AdnityTM X 20 D, X 20 C, X 24 D) ..................................................................................... 20

WATER PUMP DISASSEMBLY/ASSEMBLY (For AdnityTM X 20 D, X 20 C, X 24 D)......................................... 21

DETERGENT PUMP AND CHECK VALVE DISASSEMBLY/ASSEMBLY

(For AdnityTM X 20 D, X 20 C, X 24 D) ................................................................................................................ 21

TROUBLESHOOTING ......................................................................................................................................... 23

BRUSHING SYSTEM................................................................................................................................................ 25

BRUSH/PAD CLEANING ..................................................................................................................................... 25

BRUSH/PAD-HOLDER/CYLINDRICAL BRUSH DECK DISASSEMBLY/ASSEMBLY

(For AdnityTM 17 ST, 20 ST) ................................................................................................................................ 25

BRUSH/PAD-HOLDER/CYLINDRICAL BRUSH DECK DISASSEMBLY/ASSEMBLY

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 26

BRUSH MOTOR ELECTRICAL INPUT CHECK (For AdnityTM 17 ST, 20 ST).................................................... 27

BRUSH MOTOR ELECTRICAL INPUT CHECK (For AdnityTM 20 D, X 20 D) .................................................... 28

BRUSH MOTOR ELECTRICAL INPUT CHECK (For AdnityTM X 20 C).............................................................. 30

BRUSH MOTOR ELECTRICAL INPUT CHECK (For AdnityTM X 24 D).............................................................. 31

BRUSH MOTOR CARBON BRUSH CHECK/REPLACEMENT (For AdnityTM 17 ST, 20 ST)............................. 32

BRUSH MOTOR CARBON BRUSH CHECK/REPLACEMENT (For AdnityTM 20 D, X 20 D) ............................. 33

BRUSH MOTOR CARBON BRUSH CHECK/REPLACEMENT (For AdnityTM X 20 C)....................................... 35

BRUSH MOTOR CARBON BRUSH CHECK/REPLACEMENT (For AdnityTM X 24 D)....................................... 36

BRUSH MOTOR DISASSEMBLY/ASSEMBLY (For AdnityTM 17 ST, 20 ST, 20 D, X 20 D)................................ 37

BRUSH MOTOR DISASSEMBLY/ASSEMBLY (For AdnityTM X 20 C)................................................................ 38

BRUSH MOTOR DISASSEMBLY/ASSEMBLY (For AdnityTM X 24 D)................................................................ 39

CHECK/REPLACEMENT/ADJUSTMENT OF DRIVING BELTS FROM MOTORS

TO CYLINDRICAL BRUSHES (For AdnityTM X 20 C) ......................................................................................... 40

BRUSH ENABLING MICROSWITCH ADJUSTMENT/REPLACEMENT

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 41

TROUBLESHOOTING ......................................................................................................................................... 42

ENGLISH SERVICE MANUAL

49096982000(1)2007-02 AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D

RECOVERY WATER SYSTEM ................................................................................................................................. 43

RECOVERY WATER TANK AND VACUUM GRID CLEANING, AND COVER GASKET CHECK ....................... 43

SQUEEGEE CLEANING/CHECK/REPLACEMENT AND SQUEEGEE BLADE REPLACEMENT...................... 44

VACUUM SYSTEM MOTOR FILTER CLEANING ............................................................................................... 45

VACUUM SYSTEM MOTOR ELECTRICAL INPUT CHECK................................................................................ 45

VACUUM SYSTEM MOTOR CARBON BRUSH CHECK/REPLACEMENT ........................................................ 46

VACUUM SYSTEM MOTOR DISASSEMBLY/ASSEMBLY.................................................................................. 17

SQUEEGEE SPRING CHECK/REPLACEMENT (All models, with aluminium squeegee) .................................. 48

TROUBLESHOOTING ......................................................................................................................................... 48

DRIVE SYSTEM........................................................................................................................................................ 49

SPEED POTENTIOMETER ADJUSTMENT/REPLACEMENT (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) .... 49

MAXIMUM SPEED POTENTIOMETER DISASSEMBLY/ASSEMBLY

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 51

DRIVE SYSTEM MOTOR ELECTRICAL INPUT CHECK

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 52

DRIVE SYSTEM MOTOR CARBON BRUSH CHECK AND REPLACEMENT

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 53

DRIVE SYSTEM MOTOR-DIFFERENTIAL DISASSEMBLY/ASSEMBLY

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 54

TROUBLESHOOTING ......................................................................................................................................... 55

DRIVE SYSTEM ELECTRONIC BOARD DIAGNOSTIC TABLE ......................................................................... 56

OTHER SYSTEMS.................................................................................................................................................... 57

SCREW AND NUT TIGHTENING CHECK........................................................................................................... 57

ELECTRICAL SYSTEM ............................................................................................................................................ 59

MACHINE WORKING HOUR CHECK (with optional hour counter) .................................................................... 59

BATTERY CHARGE AND MAINTENANCE (All models) ..................................................................................... 59

BATTERY DISASSEMBLY/ASSEMBLY ............................................................................................................... 59

BATTERY TYPE SETTING (WET OR GEL) (For AdnityTM 17 ST, 20 ST) .......................................................... 60

BATTERY TYPE SETTING (WET OR GEL) (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ................................ 60

FUSE CHECK/REPLACEMENT .......................................................................................................................... 61

BRUSH MOTOR ELECTROMAGNETIC SWITCH DISASSEMBLY/ASSEMBLY ................................................ 62

DRIVE SYSTEM ELECTRONIC BOARD DISASSEMBLY/ASSEMBLY

(For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................................................... 63

FUNCTION ELECTRONIC BOARD DISASSEMBLY/ASSEMBLY....................................................................... 64

TROUBLESHOOTING ......................................................................................................................................... 64

COMPONENT LAYOUT (For AdnityTM 17 ST, 20 ST)......................................................................................... 65

WIRING DIAGRAM (For AdnityTM 17 ST, 20 ST) ................................................................................................ 66

COMPONENT LAYOUT (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ............................................................... 67

WIRING DIAGRAM (For AdnityTM 20 D, X 20 D, X 20 C, X 24 D) ...................................................................... 68

SERVICE MANUAL ENGLISH

AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D 9096982000(1)2007-02 5

GENERAL INFORMATION

CONVENTIONS

Forward, backward, front, rear, left or right are intended with reference to the operator’s position, that is to say in driving position

with the hands on the handlebar.

MACHINE LIFTING

WARNING!

Do not work under the lifted machine without supporting it with safety stands.

MACHINE TRANSPORTATION

WARNING!

Before transporting the machine, make sure that:

All covers are closed.

The ignition key is removed.

The machine is securely fastened to the means of transport.

–

OTHER REFERENCE MANUALS

The following manuals are available at Nilsk-Advance Literature Service Department:

AdnityTM 17 ST - 20 ST: User Manual - Form Number 9096912000

AdnityTM 17 ST - 20 ST: Spare Parts List - Form Number 9096913000

AdnityTM 20 D - X 20 D - X 20 C - X 24 D: User Manual - Form Number 9096910000

AdnityTM 20 D - X 20 D - X 20 C - X 24 D: Spare Parts List - Form Number 9096911000

SAFETY

The following symbols indicate potentially dangerous situations. Always read this information carefully and take all necessary

precautions to safeguard people and property.

SYMBOLS

DANGER!

It indicates a dangerous situation with risk of death for the operator.

WARNING!

It indicates a potential risk of injury for people or damage to objects.

CAUTION!

It indicates a caution related to important or useful functions.

Pay careful attention to the paragraphs marked by this symbol.

NOTE

It indicates a remark related to important or useful functions.

CONSULTATION

It indicates the necessity to refer to the User Manual before performing any procedure.

GENERAL INSTRUCTIONS

Specic warnings and cautions to inform about potential damages to people and machine are shown below.

DANGER!

This machine must be used by properly trained and authorised personnel only. Children or disabled

people cannot use this machine.

Do not wear jewels when working near electrical components.

Do not work under the lifted machine without supporting it with safety stands.

Do not operate the machine near toxic, dangerous, ammable and/or explosive powders, liquids or

vapours.

Disconnect the batteries before performing any maintenance/repair procedure.

Keep the battery far from sparks, ames and incandescent material. During the normal operation

explosive gases are released.

Battery charging produces highly explosive hydrogen gas. Keep the tanks lifted during battery charging

and perform this operation in well-ventilated areas and away from bare ames.

–

ENGLISH SERVICE MANUAL

69096982000(1)2007-02 AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D

GENERAL INFORMATION

WARNING!

Always protect the machine against the sun, rain and bad weather, both under operation and inactivity condition.

Store the machine indoors.

Do not allow to be used as a toy. Close attention is necessary when used near children.

Use only as shown in this Manual. Only Nilsk-Advance recommended accessories must be used.

Take all necessary precautions to prevent hair, jewels and loose clothes from being caught by the machine

moving parts.

Do not leave the machine unattended without being sure that it cannot move independently.

Do not use the machine on slopes with a gradient exceeding the specications.

Do not use the machine in particularly dusty areas.

While using this machine, take care not to cause damage to people or objects.

Do not bump into shelves or scaffoldings, especially where there is a risk of falling objects.

Do not put any can containing uids on the machine.

The machine working temperature must be between +32°F and +104°F (0°C and +40°C).

The machine storage temperature must be between +32°F and +104°F (0°C and +40°C).

The humidity must be between 30% and 95%.

Do not use the machine as a means of transport.

Do not use the machine on slopes with an inclination higher than 2%.

In case of re, use a powder re extinguisher, not a water one.

Do not tamper with the machine safety guards and follow the ordinary maintenance instructions scrupulously.

Do not allow any object to enter into the openings. Do not use the machine if the openings are clogged. Always

keep the openings free from dust, hairs and any other foreign material which could reduce the air ow.

Do not remove or modify the plates afxed to the machine.

If the machine is used according to the instructions, the vibrations are not dangerous. The machine vibration level

is less than 2.5 m/s2 (98/37/EEC-EN 1033/1995).

This machine cannot be used on roads or public streets.

Pay attention during machine transportation when temperature is below freezing point. The water in the recovery

tank or in the hoses could freeze and seriously damage the machine.

Use brushes and pads supplied with the machine and those specied in the User Manual. Using other brushes or

pads could reduce safety.

If parts must be replaced, require ORIGINAL spare parts from a Dealer or Authorised Retailer.

Carefully read all the instructions before performing any maintenance/repair procedure.

Do not wash the machine with direct or pressurised water jets, or with corrosive substances.

The machine must be disposed of properly, because of the presence of toxic-harmful materials (batteries, etc.),

which are subject to standards that require disposal in special centres (see the User Manual).

Do not pull or carry the machine by the battery charger cable and never use the battery charger cable as a handle.

Do not close a door on the battery charger cable, or pull the battery charger cable around sharp edges or corners.

Do not run the machine on the battery charger cable.

Keep the battery charger cable away from heated surfaces.

Do not charge the batteries if the battery charger cable or the plug are damaged. If the machine is not working as

it should, has been damaged, left outdoors or dropped into water, return it to the Service Center.

Before using the battery charger, ensure that frequency and voltage values, indicated on the machine serial

number plate, match the electrical mains voltage.

Do not smoke while charging the batteries.

To reduce the risk of re, electric shock, or injury, do not leave the machine unattended when it is plugged in.

Before performing any maintenance procedure, disconnect the battery charger cable from the electrical mains.

–

SERVICE MANUAL ENGLISH

AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D 9096982000(1)2007-02 7

GENERAL INFORMATION

TECHNICAL DATA (For AdnityTM 17 ST - 20 ST)

Model AdnityTM 17 ST

(1 brush/pad-holder)

AdnityTM 20 ST

(1 brush/pad-holder)

Machine height 41.6 in (1,058.5 mm)

Solution/clean water tank capacity 10.5 gal (40 litres)

Recovery water tank capacity 10.5 gal (40 litres)

Front wheel diameter 7.8 in (200 mm)

Front wheel specic pressure on the ground * 174 lbf/in2(1.2 N/mm2)

Rear wheel specic pressure on the ground * 435 lbf/in2 (3 N/mm2)

Rear wheel diameter 3.9 in (100 mm)

Vacuum system motor power 0.44 hp (330 W)

Gradeability 2%

Sound pressure level at workstation 65.8 dB(A)

Standard batteries WET (2 x 12V) 24V 105 Ah

Battery compartment size (width x length x height) 13.8 x 13.8 x 11.8 in (350 x 350 x 300 mm)

Vacuum system circuit capacity 41.5 in H2O (1,055 mm H2O)

Cleaning width 18.0 in (450 mm) 21.0 in (530 mm)

Squeegee width 30.0 in (760 mm)

Machine maximum length 46.8 in (1,190 mm) 48.3 in (1,228 mm)

Machine width without squeegee 20.1 in (512 mm) 21.2 in (540.8 mm)

Brush diameter 18.0 in (450 mm) 21.0 in (530 mm)

Weight without batteries and with empty tanks 194.0 lb (88 kg)

Maximum weight with batteries and full tanks 479.6 lb (218 kg)

Brush motor power 0.65 hp (480 W)

Brush speed 153 rpm

Brush/pad-holder pressure 42.0 lb (19.0 kg) 45.1 lb (20.5 kg)

(*) Machine set-up:

max size battery

max size brush deck / squeegee

solution tank full

optionals installed

weight veried on each wheel

print area veried on concrete for each wheel

result expressed as max. value for front and max value for rear wheels

•

ENGLISH SERVICE MANUAL

89096982000(1)2007-02 AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D

GENERAL INFORMATION

TECHNICAL DATA (For AdnityTM 20 D - X 20 D - X 20 C - X 24 D)

Model

AdnityTM

20 D

(1 brush/pad-

holder)

AdnityTM

X 20 D

(1 brush/pad-

holder)

AdnityTM

X 20 C

(2 cylindrical

brushes)

AdnityTM

X 24 D

(2 brushes/pad-

holders)

Machine height 42.8 in (1,088 mm)

Solution/clean water tank capacity 15.3 gal (58 litres)

Recovery water tank capacity 16.0 gal (60 litres)

Front wheel diameter 9.8 in (250 mm)

Front wheel specic pressure on the ground * 174 lbf/in2(1.2 N/mm2)

Rear wheel specic pressure on the ground * 667 lbf/in2 (4.6 N/mm2)

Rear wheel diameter 3.9 in (100 mm)

Vacuum system motor power 0.44 hp (330 W)

Drive system motor power 0.27 hp (200 W)

Drive speed (variable) 0 to 3.5 MPH (0 to 5.6 km/h)

Gradeability 2%

Sound pressure level at workstation 65.8 dB(A)

Standard batteries WET (2 x 12V) 24V 130 Ah

Battery compartment size (width x length x height) 13.8 x 13.8 x 11.8 in (350 x 350 x 300 mm)

Vacuum system circuit capacity 41.5 in H2O (1,055 mm H2O)

Technical data for machines with brush/pad-holder deck

Model

AdnityTM

20 D

(1 brush/pad-holder)

AdnityTM

X 20 D

(1 brush/pad-holder)

AdnityTM

X 24 D

(2 brushes/pad-

holders)

Cleaning width 21.0 in (530 mm) 24.0 in (610 mm)

Squeegee width 30.0 in (760 mm) 32.0 in (810 mm)

Machine maximum length 52.1 in (1,323 mm) 51.6 in (1,311 mm)

Machine width without squeegee 21.3 in (541 mm) 25.4 in (646 mm)

Brush diameter 21.0 in (530 mm) 12.0 in (305 mm)

Weight without batteries and with empty tanks 225.0 lb (102 kg)

Maximum weight with batteries and full tanks 551.1 lb (250 kg)

Brush motor power 0.64 hp (480 W) 0.47 hp (350 W)

Brush speed 153 rpm 230 rpm

Brush/pad-holder pressure with extra-pressure

function turned off 45.2 lb (20.5 kg)

Brush/pad-holder pressure with extra-pressure

function turned on 61.3 lb (27.8 kg)

(*) Machine set-up:

max size battery

max size brush deck / squeegee

solution tank full

optionals installed

weight veried on each wheel

print area veried on concrete for each wheel

result expressed as max. value for front and max value for rear wheels

•

SERVICE MANUAL ENGLISH

AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D 9096982000(1)2007-02 9

GENERAL INFORMATION

Technical data for machines with cylindrical brush deck

Model

AdnityTM

X 20 C

(2 cylindrical brushes)

Cleaning width 20.0 in (510 mm)

Squeegee width 30.0 in (760 mm)

Machine maximum length 49.3 in (1,253 mm)

Machine width without squeegee 22.7 in (575.5 mm)

Cylindrical brush size (diameter x length) 4.3 x 20.0 in (110 x 485 mm)

Weight without batteries and with empty tanks 247.0 lb (112 kg)

Maximum weight with batteries and full tanks 573.2 lb (260 kg)

Brush motor power 0.54 hp (400 W)

Cylindrical brush rotation speed 570 rpm

Cylindrical brush pressure 58.4 lb (26.5 kg)

MAINTENANCE

The lifespan of the machine and its maximum operating safety are ensured by correct and regular maintenance

WARNING!

Read carefully the instructions in the Safety chapter before performing any maintenance procedure.

The following tables provides the scheduled maintenance. The intervals shown may vary according to particular working

conditions, which are to be dened by the person in charge of the maintenance.

For instructions on maintenance procedures, see the following paragraphs.

SCHEDULED MAINTENANCE TABLE

Procedure

Daily, after

machine

use

Weekly Every six

months Yearly

Battery charging

Squeegee cleaning

Brush/pad cleaning

Tank and vacuum grid with oat cleaning, and cover gasket check

Squeegee blade check and replacement

Solution/clean water lter cleaning

Battery (WET) uid level check

Vacuum system motor lter cleaning

Screw and nut tightening check (1)

Brush/pad-holder motor carbon brush check or replacement

Vacuum system motor carbon brush check or replacement

Drive system motor carbon brush check or replacement

(For AdnityTM 20 D - X 20 D - X 20 C - X 24 D)

(1): And after the rst 8 working hours.

ENGLISH SERVICE MANUAL

10 9096982000(1)2007-02 AdnityTM 17 ST, 20 ST, 20 D, X 20 D, X 20 C, X 24 D

GENERAL INFORMATION

MACHINE NOMENCLATURE (For AnityTM 17 ST - 20 ST)

Throughout this Manual you will nd numbers in brackets – for example: (2). These numbers refer to the components indicated

in these two nomenclature pages. Refer to these pages whenever you need to identify a component mentioned in the text.

Portare la macchina su un pavimento pianeggiante.

Control panel

Handlebar

Battery charger data inspection window

Battery charger cable

Battery charger cable holder

Water removable ller hose (optional)

Squeegee lifting/lowering lever

Deck lifting/lowering pedal

11a. Pedal position when deck is lifted

11b. Pedal position when deck is lowered

Battery connector (red). This connector also works as

EMERGENCY switch, to stop immediately all functions.

Rear steering wheels

Front wheels on xed axle

Squeegee vacuum hose

Recovery water drain hose

Solution/clean water drain and level check hose

Brush/pad-holder deck

Brush/pad-holder with pad

Solution/clean water tank

Recovery water tank

Recovery water tank cover

Can holder

Document retainer (optional)

Squeegee

Squeegee mounting handwheels

Squeegee balance adjusting handwheel

Machine straight forward movement adjusting handwheel

Machine forward speed adjustment handwheel

30a. Recovery water tank cover (opened to be cleaned)

30b. Recovery water tank cover (completely opened)

Tank cover gasket

Cover movable retaining plate

Cover xed retaining plate

Serial number plate/technical data/conformity certication

Plug for squeegee vacuum hose cleaning

Vacuum grid with automatic shut-off oat

Solution ller neck

Foam lter

Compensation hole

Recovery water tank (lifted)

Tank lifting handle

Lifted tank tie rod

Vacuum system motor cover

Vacuum system motor sound-deadening lter

Batteries

Battery caps

Solution lter

Solution/clean water tap

Solenoid valve

Battery connection diagram

Brush/pad-holder and vacuum system switch

Brush/pad-holder and vacuum system switch warning

light

Vacuum system switch

Vacuum system switch warning light

Hour counter (optional)

Battery charge indicator

81a. Charged battery warning light (green)

81b. Semi-discharged battery warning light (yellow)

81c. Discharged battery warning light (red)

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

22.

23.

24.

25.

26.

27.

28.

29.

31.

32.

33.

34.

35.

36.

37.

38.

39.

40.

41.

42.

43.

44.

52.

53.

54.

55.

56.

58.

71.

72.

73.

74.

79.

81.

Washing water ow control switches

82a. Flow increase switch

82b. Flow decrease switch

82c. Washing water ow indicator

Electronic battery charger

Lead (WET) or gel (GEL) battery selector

Green warning light (ON: the battery charger is on and

batteries are charged)

Yellow warning light (ON: the battery charger is on and

batteries are semi-discharged)

Red warning light (ON: the battery charger is on and it is

charging the batteries)

82.

90.

91.

92.

93.

94.

Altri manuali per Adfinity 17ST

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Advance acoustic Macchina per pavimenti

Advance acoustic

Advance acoustic 9084802010 Manuale utente

Advance acoustic

Advance acoustic SW5500 Manuale utente

Advance acoustic

Advance acoustic Micromatic 14 E Manuale utente

Advance acoustic
