Advantech MIC-3620 Manuale utente

This document is copyrighted, 2002. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products described

in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any

form or by any means without the prior written permission of the original

manufacturer. Information provided in this manual is intended to be accurate and

reliable. However, the original manufacturer assumes no responsibility for its use,

nor for any infringements upon the rights of third parties which may result from

its use.

Acknowledgments

PC-LabCard is a trademark of Advantech Co., Ltd. IBM and PC are trademarks of

International Business Machines Corporation. MS-DOS, Windows®, Microsoft®

Visual C++ and Visual BASIC are trademarks of Microsoft® Corporation. Intel®

and Pentium®are trademarks of Intel Corporation. Delphi and C++ Builder are

trademarks of Inprise Corporation.

CE notification

The MIC-3620, developed by ADVANTECH CO., LTD., has passed the CE test

for environmental specifications when shielded cables are used for external

wiring. We recommend the use of shielded cables. This kind of cable is available

from Advantech. Please contact your local supplier for ordering information.

On-line Technical Support

For technical support and service, please visit our support website at:

http://www.advantech.com/support

Part No.2003362000 1st Edition

Printed in Taiwan December 2002

Contents

INTRODUCTION..................................................................................................................................................1

1.1 INTRODUCTION...........................................................................................................................................2

1.2 FEATURES.....................................................................................................................................................2

1.3 SPECIFICATIONS..........................................................................................................................................3

HARDWARE CONFIGURATION....................................................................................................................5

2.1 INITIAL INSPECTION...................................................................................................................................6

2.2 HARDWARE INSTALLATION.......................................................................................................................7

2.3 BOARD LAYOUT: DIMENSIONS.................................................................................................................9

PIN ASSIGNMENT & WIRING......................................................................................................................11

3.1 PINASSIGNMENTS.....................................................................................................................................12

REGISTER STRUCTURE & FORMAT......................................................................................................15

4.1 REGISTER STRUCTURE.............................................................................................................................16

Chapter

Introduction

1.1 Introduction

The MIC-3620 is a 3U-sized 8-port High Speed RS-232 PCI Comm.

CompactPCI™ and serial communication card, which complies with PICMG

2.0 R2.1 CompactPCI specifications. The MIC-3620 requires only one CPCI

slot within the computer and provides independent serial channels. All channels

are addressed in a continuous 32 byte I/O block for simplified software access.

It is possible for all channels to share one PCI interrupt. An interrupt status

The MIC-3620 comes standard with 16C954 UARTs containing an optional 128

byte FIFOs. These upgraded FIFOs greatly reduce CPU overhead and are an

ideal choice for heavy multitasking environments.

1.2 Features

• PCI Specification 2.1x compliant

• Speeds up to 921.6 Kbps

• 16C954 UARTs with 128-byte FIFO standard

• Standard Industrial CPCI Board size

• I/O address automatically assigned by PCI Plug-and-Play

• OS supported: Windows 98, Windows NT, Windows2000 and Windows XP

• Interrupt status register for increased performance

• Space reserved for termination resistors

1.3 Specifications

• Bus Interface:CPCI bus specification 2.1x compliant

• IRQ: all ports use the same IRQ assigned by PCI Plug-and-Play

• Data bits:5, 6, 7, 8

• Stop bits: 1, 1.5, 2

• Parity: none, even, odd

• BUS controller: PCI9030

•UART: 2 x 16C954

• Speed (bps): 50 ~ 921.6 K

• Data signals:TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND (for RS-232)

• Power consumption: [email protected](MAX), +3.3V@3A, +12V@1A

• Dimensions:160 mm x 100 mm

• Operating temperature:0’C~ 70’C(referring to IEC68-2-1, 2)

• Operating Humidity: 5 ~ 95% Relative Humidity,

non-condensing (referring to IEC 68-2-1, 2)

• Operating Humidity: 5 ~ 95% Relative Humidity,

non-condensing (referring to IEC 68-2-3)

•Storage Temperature:-20 ~ 80 ’C

Hardware Configuration

Chapter

This chapter gives users a package item checklist, proper instructions about

unpacking and step-by-step procedures for card installation.

2.1 Initial Inspection

In addition to this manual, you should find the following items inside the

shipping package of the MIC-3620:

• CPCI communication interface card MIC-3620

• Advantech Automation Software CD-ROM

• CPCI communication card user's manual

•Wiring cable

Prior shipping, we have carefully inspected the CPCI communication card

series. It should be free of marks and scratches and in perfect working order on

receipt. As you unpack the CPCI communication card series, check for signs of

shipping damage (damaged box, scratches, dents, etc.). If it is damaged or fails

to meet specifications, immediately notify our service department or your local

sales representative. Please also notify the carrier. Retain the shipping carton

and packing materials for inspection by the carrier. Once inspected, we will

make arrangements to repair or replace the unit.

When you handling the CPCI communication card series, remove its protective

packaging by grasping the rear metal panel. Keep the anti-vibration packaging.

Whenever you remove the card from the PC, store it in this package for

protection.

Note:

Discharge your body’s static electric charge by touching the back of the grounded

chassis of the system unit (metal) before handling the board. You should avoid contact

with materials that hold a static charge such as plastic, vinyl and styrofoam. Handle the

board only by its edges to avoid static damage to its integrated circuits. Avoid touching

the exposed circuit connectors. We also recommend that you use a grounded wrist

strap and place the card on a static dissipative mat whenever you work with it.

2.2 Hardware Installation

Note

Make sure you have installed the driver first before you install the card (please refer to

the software installation details in Chapter 3 Driver Setup & Installation).

Once you have doubled check that the DLL driver of the MIC-3620 installation is

complete, you can proceed with the MIC-3620 card installation in your CPCI

computer. Once in doubt, please consult with your computer’s user manual or

related documentation. Please follow the following steps to install the card on

your system.

To install a card:

Step 1: Remove one cover on the unused slot of your CPCI computer slot.

Step 2: Hold the Card Vertically. Be sure that the card is pointing in the correct

direction. The components of the card should be pointing to the right-hand side

and the black handle of the card should be pointing to the lower edge of the

chassis.

Step 3: Hold the lower handle and pull the handle down to unlock it.

Step 4:Insert the MIC-3620 card into the CPCI chassis carefully by sliding the lower

edges of the card into the card guides.

Step 5: Gently push the card into the slot by sliding the card along the card guide until

J1 meetsthe long needle on the backplane.

Note

If your card is correctly positioned and has slid all the way into the chassis, the handle

should match the rectangular holes. If not, remove the card from the card guide and

repeat step 3 again. Do not try to install a card by forcing it into the chassis.

Step 6: Push the card into the right place, secure the card by pushing the handle to lock

it into place.

Note 1

Advantech MIC-3612’s “Hot-Swap”function complies with CPCI Hot Swap

Specification PICMG 2.1 R2.0.

Note 2

Because the card holds “Hot-Swap”, Blue LED on the front plane indicates the status of

the card installation when the system is on. Instep 5, Blue LED will turn on when J1

meets the long needle on the backplane;In step 6, the system will automatically

configure the card,the Blue LED will turn off when the system completes the device

configuration.

If system’s power is turned off, you can install the card step by step without considering

the Blue LED’s state.

To remove a card:

Step 1:Push the handle down to unlock the card, and the CPCI system will

automatically uninstall the card configuration.

Step 2: Once the system finishesthe device configuration, the Blue LED on front

plane will turn on. Now you can slide the card out.

Note

Because the card holds“Hot-Swap”, the above steps will removethe card process

when the system is on. If the system power is off, please do step1 and step2 without

attending Blue LED’s state.
