Advantech PCI-1711 Manuale utente

This documentation and the software included with this product are

copyrighted 1999 by Advantech Co., Ltd. All rights are reserved.

Advantech Co., Ltd. reserves the right to make improvements in the

products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior written

permission of Advantech Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, Advantech

Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties which may result from its use.

Acknowledgments

PC-LabCard is a trademark ofAdvantech Co., Ltd. IBM and PC are

trademarks of International Business Machines Corporation. MS-

DOS,Windows, MicrosoftVisual C++ andVisual BASIC are trade-

marks of Microsoft Corporation. Intel and Pentium are trademarks of

Intel Corporation. Delphi and C++Builder are trademarks of Inprise

Corporation.

CE notification

The PCI-1711/1731, developed byADVANTECH CO., LTD., has

passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of

shielded cables. This kind of cable is available from Advantech.

Please contact your local supplier for ordering information.

On-line Technical Support

For technical support and service, please visit our support website at:

http://support.advantech.com

Part No. 2003171100 1st Edition

Printed inTaiwan October 1999

Contents

1. Introduction .................................................. 1

1.1 Features ...............................................................................1

1.2 Installation Guide ................................................................3

1.3 Software ...............................................................................5

1.4Accessories ..........................................................................5

2. Installation..................................................... 7

2.1 Unpacking ............................................................................7

2.2 Driver Installation ................................................................8

2.3 Hardware Installation..........................................................9

2.4 Device Setup & Configuration ..........................................12

2.5 Device Testing ...................................................................15

3. Signal Connections ...................................19

3.1 Overview ............................................................................19

3.2 I/O Connector.....................................................................19

3.3 Analog Input Connections ................................................ 22

3.4 Analog Output Connections.............................................. 22

3.5 Trigger Source Connections .............................................23

3.6 Field Wiring Considerations .............................................24

4. Software Overview..................................... 25

4.1 Programming Choices ......................................................25

4.2 DLL Driver Programming Roadmap ................................27

5. Calibration................................................... 29

5.1 VR Assignment...................................................................29

5.2 A/D Calibration ..................................................................30

5.3 D/A Calibration ..................................................................30

5.4 Self A/D Calibration...........................................................31

Appendix A

Specifications ................................................. 33

Appendix B

Block Diagram ................................................ 35

Appendix C

C.1 Overview............................................................................37

C.2 I/O Port Address Map ........................................................37

C.3 Channel Number and A/D Data — BASE+0 and

BASE+1..............................................................................42

C.4 Software A/D Trigger — BASE+0 ....................................42

C.5 A/D Channel Range Setting — BASE+2 .........................43

C.6 MUX Control — BASE+4 and BASE+5 ............................44

C.7 Status Register — BASE+6 and BASE+7 .........................45

C.8 Control Register — BASE+6 .............................................46

C.9 Clear Interrupt and FIFO — BASE+8 and BASE+9 .........47

C.10 D/A Output Channel 0 — BASE+10 and BASE+11 .........47

C.11 D/A Output Channel 1 — BASE+12 and BASE+13 .........48

C.12 D/A Reference Control —BASE+14 ................................49

C.13 Digital I/O Registers — BASE+16 and BASE+17............50

C.14 Programmable Timer/Counter Registers BASE+24,

BASE+26,BASE+28 andBASE+30 .................................50

Appendix D

82C54 Counter Function ............................... 51

D.1 The Intel 82C54..................................................................51

D.2 Counter Read/Write and Control Registers.....................51

D.3 Counter Operating Modes ................................................53

D.4 Counter Operations...........................................................55

– 1 –

Chapter 1

PCI-1711/1731 User’s Manual

Advantech Co., Ltd.

www.advantech.com

Chapter

1. Introduction

Thank you for buying the Advantech PCI-1711/1731 PCI card. The

Advantech PCI-1711/1731 is a powerful data acquisition (DAS) card for

the PCI bus. It features a unique circuit design and complete functions

for data acquisition and control. PCI-1711/1731 provides specific

functions for different user requirements:

PCI-1711 12-bitLow-costMultifunctionDAScard

PCI-1731 12-bitLow-costMultifunctionDAScardw/oanalogoutput

The following sections of this chapter will provide further information

about features of the DAS cards, a Quick Start for installation, together

with some brief information on software and accessories for the PCI-

1711/1731card.

1.1 Features

The Advantech PCI-1711/1731 provides users with the most requested

measurement and control functions as seen below:

q16-channel Single-Ended A/D Input

q12-bit A/D conversion with up to 100 kHz sampling rate

q16-channel Digital Input

q16-channel Digital Output

q2-channelD/A Output (onlyfor PCI-1711)

qProgrammableCounter/Timer

qAutomatic Channel/Gain Scanning

TheAdvantech PCI-1711/1731offers the followingmain features:

Plug-and-Play Function

The Advantech PCI-1711/1731 is a Plug-and-Play device, which fully

complieswith the PCISpecification Rev 2.1. During card installation, all

bus-related configurations such as base I/O address and interrupts are

conveniently taken care of by the Plug-and-Play function. You have

virtually no need to set any jumpers or DIP switches.

Flexible Input Types and Range Settings

The PCI-1711/1731 features an automatic channel/gain scanning

circuit. This circuit design controls multiplexer switching during

sampling. Users can set different gain values for each channel

– 2 –

Chapter 1

PCI-1711/1731 User’s Manual Advantech Co., Ltd.

www.advantech.com

according to their needs for the corresponding range of input voltage.

The gain value settings thus selected is stored in the SRAM. This

flexible design enables multi-channel and high-speed sampling for

high-performance data acquisition (up to 100 KS/s .)

On-boardFIFO(First-In-First-Out) Memory

The PCI-1711/1731 provides an on-board FIFO memory buffer, storing

up 1 to 1K A/D samples. Users can either enable or disable the

interrupt request feature of the FIFO buffer. While the interrupt request

for FIFO is enabled, users are allowed to specify whether an interrupt

request will be sent with each sampling action or only when the FIFO

buffer is half saturated. This useful feature enables a continuous high-

speed data transfer with a more predictable performance on operating

systems.

Optional D/A Output for Cost Savings

The PCI-1711 goes further with 2 analog output channels, while the

PCI-1731 doesn’t. It is for users to differentiate between the PCI-1711

and the PCI-1731 according to what they really need as the best

solution with no extra cost.

16 Digital Inputs and 16 Digital Outputs

The PCI-1711/1731 provides 16 digital input channels and 16 digital

output channels. Users are left with great flexibility to design and

customize their applications according to their specific needs.

On-board Programmable Counter

ThePCI-1711/1731isequipped with a programmable counter, which

can serve as a pacer trigger for A/D conversions. The counter chip is

an 82C54 or its equivalent, which incorporates three 16-bit counters on

a 10 MHz clock. One of the three counters is used as an event counter

for input channels or pulse generation. The other two are cascaded

into a 32-bit timer for pacer triggering.

Note:

✎Pace trigger determines how fast A/D conversion will be done in pacer

trigger mode.

✎For detailed specifications of the PCI-1711/1731, please refer to Appen-

dix A, Specifications.

– 3 –

Chapter 1

PCI-1711/1731 User’s Manual

Advantech Co., Ltd.

www.advantech.com

1.2 Installation Guide

Before you install your PCI-1711/1731 card, please make sure you have

the following necessary components:

qPCI-1711orPCI-1731DAScard

qPCI-1711/1731User’sManual

qDriversoftware Advantech DLL drivers

(included in the companion CD-ROM)

qWiringcable PCL-10168

qWiringboard PCLD-8710,ADAM-3968

qComputer Personal computer or workstation with a

PCI-bus slot (running Windows 95/98/NT)

Some other optional components are also available for enhanced

operation:

qApplicationsoftware ActiveDAQ, GeniDAQ or other third-party

software packages

After you have got the necessary components and maybe some

accessories for enhanced operation of your DAS card, you can then

begin the Installation procedures. Figure 1-1 on the next page pro-

vides a concise flow chart to give users a broad picture of the software

and hardware installation procedures:

– 4 –

Chapter 1

PCI-1711/1731 User’s Manual Advantech Co., Ltd.

www.advantech.com

Install Driver CD-ROM, then power-off PC

Plug-in Hardware and power-on PC

Use configuration utility to configure hardware

Use testing utility to test hardware

Read examples & driver manual

Start to write your application

Fig. 1-1 Installation Flow Chart

– 5 –

Chapter 1

PCI-1711/1731 User’s Manual

Advantech Co., Ltd.

www.advantech.com

1.3 Software

Advantech offers a rich set of DLL drivers, third-party driver support

and application software to help fully exploit the functions of your

PCI-1711/1731card:

lDLLdriver (on thecompanion CD-ROM)

lLabviewdriver

lAdvantech ActiveDAQ

lAdvantech GeniDAQ

For more information on software, please refer to Chapter 4, Software

Overview.

Users who intend to program directly at the registers of the DAS

device can have register-level programming as an option. Since

usually recommended only for experienced programmers. For more

information, please refer to Appendix C, Register Structure and

Format.

1.4 Accessories

Advantech offers a complete set of accessory products to support the

PCI-1711/1731 cards. These accessories include:

Wiring Cable

qPCL-10168 The PCL-10168 shielded cable is specially designed

for PCI-1711/1731 cards to provide high resistance to noise. To

achieve a better signal quality, the signal wires are twisted in such a

way as to form a “twisted-pair cable”, reducing crosstalk and noise

from other signal sources. Furthermore, its analog and digital lines

are separately sheathed and shielded to neutralize EMI/EMC

problems.

Wiring Boards

qADAM-3968 TheADAM-3968 is a 68-pin SCSI wiring terminal

modulefor DIN-rail mounting. Thisterminal module can be readily

connected to the Advantech PC-Lab cards and allow easy yet

reliable access to individual pin connections for the PCI-1711/1731

card.

– 6 –

Chapter 1

PCI-1711/1731 User’s Manual Advantech Co., Ltd.

www.advantech.com

qPCLD-8710 ThePCLD-8710 is a DIN-rail mounting screw-

terminal board to be used with any of the PC-LabCards which have

68-pinSCSI connectors. The PCLD-8710features the following

functions:

l2 additional 20-pin flat-cable connectors for digital input and

output

lReserved space on the board to meet future needs for signal-

conditioning circuits (low-pass filter, voltage attenuator and

current shunt)

lIndustrial-grade screw-clamp terminal blocks for heavy-duty and

reliable connections.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Advantech Scheda PCI

Advantech

Advantech ARK-5261 Manuale di installazione e funzionamento

Advantech

Advantech PCI-1680U Manuale utente

Advantech

Advantech PCI-1671UP Manuale di installazione e funzionamento

Advantech

Advantech MIO-5393 Manuale utente

Advantech

Advantech PCM-24R1TP-BE Manuale di installazione e funzionamento

Advantech

Advantech DVP-7014HE Manuale utente

Advantech

Advantech PCIE-1730H-AE Manuale utente

Advantech

Advantech PCA-6008VG Manuale utente

Advantech

Advantech PCIE-1753 Manuale utente

Advantech

Advantech PCI-1718 Series Manuale utente

Advantech

Advantech PCA-5610 Manuale di installazione e funzionamento

Advantech

Advantech PCI-1711U Series Manuale utente

Advantech

Advantech PCI-1761 Manuale utente

Advantech

Advantech PCI-1730U Manuale di installazione e funzionamento

Advantech

Advantech PCI-1753 Manuale utente

Advantech

Advantech PCI-1723 Manuale utente

Advantech

Advantech PCI-1710U-DE Manuale utente

Advantech

Advantech PCA-5650 Manuale di installazione e funzionamento

Advantech

Advantech PCI-1721 Manuale utente

Advantech

Advantech PCI-COMM Series Manuale utente

Advantech

Advantech PCI-1723 Manuale di installazione e funzionamento

Advantech

Advantech PCI-1755 Manuale utente

Advantech

Advantech ECU-P1706 Manuale di installazione e funzionamento

Advantech

Advantech DVP-7010BE Manuale utente

Manuali Scheda PCI popolari di altre marche

ERMA

ERMA SSI 1417 Manuale utente

SIIG

SIIG CyberSerial Dual PCI Istruzioni per il montaggio

Moxa Technologies

Moxa Technologies CP-102E Manuale utente

I-Bus

I-Bus IBC2602 Manuale utente

Exsys

Exsys EX-60102 Manuale utente

Chelsio Communications

Chelsio Communications T5 Series Manuale utente

Conrad Electronic

Conrad Electronic 97 46 71 Manuale utente

Micro Innovations

Micro Innovations USB650A Manuale utente

KTI Networks

KTI Networks KF-310 Manuale utente

Asus

Asus SpaceLink WL230 Manuale utente

SIIG

SIIG SC2475 Manuale utente

TRENDnet

TRENDnet TEW-703PI Manuale utente

Belkin

Belkin F5D7000F Manuale utente

Pericom

Pericom PI7C7100 Manuale utente

ADLINK Technology

ADLINK Technology cPCI-3548 Manuale utente

Digium

Digium TE200 Series Manuale utente

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuale utente

Western Digital

Western Digital FireWire PCI Adapter Manuale utente
