AE Adam CBX Series Manuale utente

AdamEquipment

CBX Balance

Test Equipment Depot - 800.517.8431 - 5 Commonwealth Ave, Woburn MA 01801 - TestEquipmentDepot.com

CONTENTS

P.N. 7006615803 – Revision A, May 2020

1.0 INTRODUCTION ................................................................. 1

2.0 KEY OPERATIONS

............................................................. 2

3.0 CALIBRATION

..................................................................... 3

4.0 MODEL SPECIFICATIONS

................................................. 3

WARRANTY INFORMATION ....................................................... 4

1.0 INTRODUCTION

Each CBX balance comes with internal rechargeable lithium battery and USB charging

lead. There is a choice of three capacities, each with four weighing units including grams,

pounds, ounces and Newtons, selectable by a Mode/Units key. The bright backlit display

enables operation in any degree of light, and the 304 grade stainless steel top pan offers

protection against most materials and liquids. With easy calibration through the keypad

the CBX ensures correct and accurate weighing at all times.

Always position the balance on a steady and level surface before use. Use the levelling

feet and bubble indicator to adjust the balance to level.

The display “-----” indicates that the balance has been overloaded or damaged.

The battery indicator symbol showing just one bar indicates that the battery needs

charging.

Plug the USB cable into the back of the balance and connect to a USB power source.

2.0 KEY OPERATIONS

Power on/off key.

Short press of this key turns on or off the backlight, press and hold the key

down to allow weighing units selection – g, N, oz or lbs.

Tare / Zero key is used remove the weight of an empty container or to zero

the balance.

In weighing mode, press and hold the counting key to enter the counting

function. The display will show PC with “10” flashing, press the mode/unit

key to change the sample size, available options are 10,20, 50, 100 & 200

After selecting the sample size, put the number of items to be counted that

equal the sample size on the top pan, press the counting key to confirm

The item weight is now stored in the balance, short pressing of the counting

key selects the counting function / returns to normal weighing.

Test Equipment Depot - 800.517.8431 - 5 Commonwealth Ave, Woburn MA 01801 - TestEquipmentDepot.com

3.0 CALIBRATION

To calibrate the balance follow the instructions below:

1. Turn on the scale and zero it.

2. Press and keys about 5 seconds, it displays raw analogue to digital

counts.

3. Press one time, scale display CALL→[xxxx]，xxxx is the calibration weight

required.

4. Put the weight on the scale according to scale display value. Scale will

automatically calibrate,when the calibration is finished, the scale back to normal

weighing.

4.0 MODEL SPECIFICATIONS

Model CBX 1201 CB 3001 CB 6000

Maximum Capacity 1200g 3000g 6000g

Readability 0.1g 0.5g 1g

Units of Measure grams, Newtons, lbs and oz

Operating Temperature 0 - 40 degrees C

Power Supply 3.7V1.5Ah lithium battery

Calibration Mass 1000g 3000g 6000g

Display 5 x 18mm/0.71 inches high digits

Pan Size 148 x 148mm/5.8 x 5.8 inches square

Overall Dimensions (w x d x h)

155 mm x 225mm x 60mm

6.1 in x 8.9 in x 2.4 in

Net Weight 572 g / 1.26 lbs

WARRANTY INFORMATION

AdamEquipmentoffersLimitedWarranty(partsandlabour)forthecomponentsfaileddueto

defectsinmaterialsorworkmanship.Warrantystartsfromthedateofdelivery.

Duringthewarrantyperiod,shouldanyrepairsbenecessary,thepurchasermustinformits

supplierorAdamEquipmentCompany.ThecompanyoritsauthorisedTechnicianreservesthe

righttorepairorreplacethecomponentsatanyofitsworkshopsdependingontheseverityof

theproblems.However,anyfreightinvolvedinsendingthefaultyunitsorpartstotheservice

centreshouldbebornebythepurchaser.

Thewarrantywillceasetooperateiftheequipmentisnotreturnedintheoriginalpackaging

andwithcorrectdocumentationforaclaimtobeprocessed.Allclaimsareatthesolediscretion

ofAdamEquipment.

Thiswarrantydoesnotcoverequipmentwheredefectsorpoorperformanceisduetomisuse,

accidental damage, exposure to radioactive or corrosive materials, negligence, faulty

installation, unauthorized modifications or attempted repair orfailuretoobservethe

requirementsandrecommendationsasgiveninthisUserManual.Additionallyrechargeable

batteries(wheresupplied)arenotcoveredunderwarranty.

Repairs carried out under the warranty does not extend the warranty period. Components

removedduringthewarrantyrepairsbecomethecompanyproperty.

Thestatutoryrightofthepurchaserisnotaffectedbythiswarranty.Thetermsofthiswarranty

isgovernedbytheUKlaw.ForcompletedetailsonWarrantyInformation,seethetermsand

conditionsofsaleavailableonourweb‐site.

WEEE2012/19/EU

Thisdevicemaynotbedisposedofindomesticwaste.Thisalsoappliestocountriesoutsidethe

EU,pertheirspecific requirements.Disposal ofbatteries(if fitted)mustconformtolocallaws

andrestrictions.

Cetappareilnepeutêtreéliminéaveclesdéchetsménagers.L’éliminationdelabatteriedoitêtre

effectuéeconformémentauxloisetrestrictionslocales.

DiesesGerätnichtmitdemHausmüllentsorgt.

Dispositivonopuedeserdesechadojuntoconlosresiduosdomésticos

Dispositivononpuòesseresmaltitoneirifiutidomestici.

FCC/ICCLASSADIGITALDEVICEEMCVERIFICATIONSTATEMENT

NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigital

device,pursuanttoPart15oftheFCCrulesandCanadianICES‐003/NMB‐003regulation.These

limits are designed to provide reasonable protection against harmful interference when the

equipmentisoperatedina commercialenvironment. Thisequipmentgenerates,usesandcan

radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstruction

manual,maycauseharmfulinterferencetoradiocommunications.Operationof thisequipment

inaresidentialarea islikely tocauseharmfulinterference inwhichcasetheuserwillberequired

tocorrecttheinterferenceathisownexpense.

CALIFORNIAPROPOSITION65‐MANDATORYSTATEMENT

WARNING:Thisproductincludesasealedlead‐acidbatterywhichcontainschemicalsknownto

theStateofCaliforniatocausecancerandbirthdefectsorotherreproductiveharm.

AdamEquipmentproductshavebeentestedwith,andarealwayssuppliedwith

mains power adaptors which meet all legal requirements for the intended

country or region of operation, including electrical safety, interference and

energy efficiency. As we often update adaptor products to meet changing

legislationit isnotpossibletorefertotheexact modelinthismanual.Please

contactusifyouneedspecificationsorsafetyinformationfor yourparticular

item.Donotattempttoconnectoruseanadaptornotsuppliedbyus.

ADAMEQUIPMENTisanISO9001:2015certifiedglobalcompanywithmorethan40years’experienceinthe

productionandsaleofelectronicweighingequipment.

AdamproductsarepredominantlydesignedfortheLaboratory,Educational,HealthandFitness,Retailand

IndustrialSegments.Theproductrangecanbedescribedasfollows:

‐AnalyticalandPrecisionLaboratoryBalances

‐CompactandPortableBalances

‐HighCapacityBalances

‐Moistureanalysers/balances

‐MechanicalScales

‐CountingScales

‐DigitalWeighing/Check‐weighingScales

‐HighperformancePlatformScales

‐Cranescales

‐MechanicalandDigitalElectronicHealthandFitnessScales

‐RetailScalesforPricecomputing

ForacompletelistingofallAdamproductsvisitourwebsiteat

www.adamequipment.com

©CopyrightbyAdamEquipmentCo.Allrightsreserved.Nopartofthispublicationmaybereprintedortranslatedin

anyformorbyanymeanswithoutthepriorpermissionofAdamEquipment.

Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the

equipmentwithoutnotice.

Allinformationcontainedwithinthispublicationistothebestofourknowledgetimely,completeandaccuratewhen

issued.However,wearenotresponsibleformisinterpretationswhichmayresultfromthereadingofthismaterial.

ThelatestversionofthispublicationcanbefoundonourWebsite.

www.adamequipment.com
