AEG Electrolux FAVORIT 55330VI0 Manuale utente

EN User Manual

Dishwasher

FAVORIT 55330VI0

CONTENTS

1. SAFETY INFORMATION.................................................................................................3

2. SAFETY INSTRUCTIONS................................................................................................ 4

3. PRODUCT DESCRIPTION.............................................................................................. 6

4. CONTROL PANEL...........................................................................................................6

5. PROGRAMMES............................................................................................................... 7

6. SETTINGS........................................................................................................................ 8

7. OPTIONS....................................................................................................................... 10

8. BEFORE FIRST USE.......................................................................................................11

9. DAILY USE......................................................................................................................12

10. HINTS AND TIPS.........................................................................................................14

11. CARE AND CLEANING.............................................................................................. 15

12. TROUBLESHOOTING.................................................................................................17

13. TECHNICAL INFORMATION.....................................................................................18

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable

performance for many years, with innovative technologies that help make life simpler

features you might not find on ordinary appliances. Please spend a few minutes

reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice

www.aeg.com

1. SAFETY INFORMATION

Before the installation and use of the appliance,

carefully read the supplied instructions. The

manufacturer is not responsible if an incorrect

installation and use causes injuries and damages. Always

keep the instructions with the appliance for future

reference.

1.1 General Safety

•This appliance is intended to be used in household

and similar applications such as:

–farm houses; staff kitchen areas in shops, offices

and other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and

maximum) must be between 0.5 (0.05) / 8 (0.8) bar

(Mpa)

•Obey the maximum number of 13 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal

position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

•Do not use water spray and steam to clean the

appliance.

•The ventilation openings in the base (if applicable)

must not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

ENGLISH 3

1.2 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Cleaning and user maintenance shall not be made by

children without supervision.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Obey the installation instruction

supplied with the appliance.

• Make sure that the appliance is

installed below and adjacent to safe

structures.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need

to be replaced, this must be carried

out by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the

E.E.C. Directives.

• Only for UK and Ireland. The

appliance has a 13 amp mains plug. If

it is necessary to change the fuse in

the mains plug, use a 13 amp ASTA

(BS 1362) fuse.

2.3 Water connection

• Make sure not to cause damage to

the water hoses.

• Before you connect the appliance to

new pipes or pipes not used for a

long time, let the water flow until it is

clean.

• The first time you use the appliance,

make sure that there is no leakage.

• The water inlet hose has a safety valve

and a sheath with an inner mains

cable.

www.aeg.com

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately disconnect the mains

plug from the mains socket. Contact

the Authorised Service Centre to

replace the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are

dangerous. Obey the safety

instructions on the detergent

packaging.

• Do not drink and play with the water

in the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent

on the dishes.

• The appliance can release hot steam

if you open the door while a

programme operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Service

• Contact the Authorised Service

Centre to repair the appliance. We

recommend only the use of original

spare parts.

• When you contact the Authorised

Service Centre, ensure that you have

the following information that is

available on the rating plate.

Model :

PNC :

Serial Number :

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

9 8

10 56

1Upper spray arm

2Lower spray arm

3Filters

4Rating plate

5Salt container

6Air vent

7Rinse aid dispenser

8Detergent dispenser

9Cutlery basket

10 Lower basket

11 Upper basket

4. CONTROL PANEL

1 2 93 4 5 6 7 8

1On/off button

2Display

3Delay button

4Programme button (up)

5Programme button (down)

6Multitab button

7TimeSaver button

8Reset button

9Indicators

www.aeg.com6

4.1 Indicators

Indicator Description

Salt indicator. It is always off while the programme operates.

Rinse aid indicator. It is always off while the programme operates.

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme phases Options

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• TimeSaver

• Multitab

• All

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash from 45 °C to 70

°C

• Rinses

• Dry

• Multitab

• Heavy soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• TimeSaver

• Multitab

• Fresh soil

• Crockery and

cutlery

• Wash 60 °C or 65 °C

• Rinses

• Multitab

• All • Prewash

1) With this programme you have the most efficient use of water and energy consumption for crockery

and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It automatically ad-

justs the temperature and the quantity of water, the energy consumption and the programme duration.

3) This programme has a high temperature rinsing phase for better hygiene results. During the rinsing

phase, the temperature stays at 70 °C for at least 10 minutes.

4) With this programme you can wash a load with fresh soil. It gives good washing results in a short time.

5) With this programme you can quickly rinse dishes to prevent remains of food to bond on dishes and

odours to form in the appliance. Do not use detergent with this programme.

ENGLISH 7

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

P1 9.9 0.932 195

P2 7 - 12 0.6 - 1.4 40 - 150

P3 13 - 15 1.3 - 1.5 140 - 160

P4 9 0.9 30

P5 4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the options and the

quantity of dishes can change the values.

5.2 Information for test

institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection

mode and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of

the acoustic signal for end of

programme.

• The deactivation of the rinse aid

dispenser when you want to use the

Multitab option without rinse aid.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the display shows the

programme number P1.

When you activate the appliance, usually

it is in programme selection mode.

However, if this does not happen, you

can set the programme selection mode

in the following way:

Press and hold Reset until the appliance

is in programme selection mode.

6.2 The water softener

The water softener removes minerals

from the water supply, which would have

a detrimental effect on the washing

results and on the appliance.

www.aeg.com

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water

in your area. It is important to set the

right level of the water softener to assure

good washing results.

Water hardness

German de-

grees (°dH)

French degrees

(°fH)

mmol/l Clarke de-

grees

Water softener lev-

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start

to flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press again and again to change

the setting.

4. Press the on/off button to confirm

the setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

Use of rinse aid and multi-

tablets

When you activate the option Multitab,

the rinse aid dispenser continues to

release rinse aid. However you can

deactivate the rinse aid dispenser. In this

case the drying results may not be

satisfactory.

With the rinse aid dispenser deactivated,

the rinse aid indicator is always off.

ENGLISH 9

How to deactivate the rinse

aid dispenser

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start

to flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting.

– = rinse aid dispenser

activated.

– = rinse aid dispenser

deactivated.

3. Press to change the setting.

4. Press the on/off button to confirm

the setting.

6.4 Acoustic signals

Acoustic signals sound when a

malfunction of the appliance occurs. It is

not possible to deactivate these acoustic

signals.

There is also an acoustic signal that

sounds when the programme is

completed. By default this acoustic

signal is deactivated but it is possible to

activate it.

How to activate the acoustic

signal for the end of

programme

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start

to flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting:

– = Acoustic signal off.

– = Acoustic signal on.

3. Press to change the setting.

4. Press the on/off button to confirm

the setting.

7. OPTIONS

Desired options must be

activated every time before

you start a programme.

It is not possible to activate

or deactivate options while a

programme is running.

Not all options are

compatible with each other.

If you have selected non

compatible options, the

appliance will automatically

deactivate one or more of

them. Only the indicators of

the options still active will

stay on.

7.1 Multitab

Activate this option when you use multi-

tablets that integrate the salt, rinse aid

and detergent functions. They can also

contain other cleaning or rinsing agents.

This option deactivates the release of

salt. The salt indicator does not come on.

With the use of this option the

programme duration is prolonged to

increase the cleaning and drying results

with the use of multi-tablets.

Multitab is not a permanent option and

must be selected at every cycle.

How to activate Multitab

Press .

The related indicator comes on.

www.aeg.com

Indice

Altri manuali AEG Electrolux Lavastoviglie

AEG Electrolux

AEG Electrolux FAVORIT 88010 VIL Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 60761 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT55322VI0 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 75011 VIL Manuale utente

AEG Electrolux

AEG Electrolux OKO FAVORIT 54200 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 89020 I Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 88070 VIL Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 86410 I Manuale utente

AEG Electrolux

AEG Electrolux ESF 655W Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 88070 Vi Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 88015 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 64860 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 80872 Manuale utente

AEG Electrolux

AEG Electrolux Built-In Dishwasher Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 89020 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 60650 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 88015 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT OPTIMA AA Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 99001 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 35085 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 35020 VI Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 80870 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 50877 Manuale utente

AEG Electrolux

AEG Electrolux FAVORIT 60850 vi Manuale utente

Manuali Lavastoviglie popolari di altre marche

Electrolux

Electrolux ESI5211LOX Manuale utente

KitchenAid

KitchenAid KUDB230B Manuale utente

Brandt

Brandt BDJ424DB Manuale utente

Asko

Asko DSD767UXXL.AU Manuale utente

Beko

Beko DFN26210W Manuale utente

NEFF

NEFF S153ITX00E Scheda tecnica

Midea

Midea SV 4.45 wi Manuale utente

LG LDF7932 Manuale utente

Gorenje

Gorenje GV63214 Manuale utente

Hotpoint

Hotpoint HDA1100ZWH Manuale di servizio

Blomberg

Blomberg LDFN2240W Manuale utente

AEG

AEG FFB83836PM Manuale utente

Cylinda

Cylinda DM3220RFD Manuale utente

Atag

Atag DW8214MB Manuale utente

GE GLD8000 Series Manuale utente

Siemens

Siemens SN23HI02KE Scheda tecnica

Omega

Omega ODW717X Manuale utente

BORETTI

BORETTI BVW-683 Manuale utente
