EN User Manual
Chest Freezer
AHB526D1LW
AHB526E1LW
CONTENTS
1. SAFETY INFORMATION......................................................................................2
2. SAFETY INSTRUCTIONS.................................................................................... 4
3. INSTALLATION.....................................................................................................6
4. GENERAL OVERVIEW.........................................................................................9
5. CONTROL PANEL..............................................................................................10
6. BEFORE FIRST USE..........................................................................................11
7. DAILY USE......................................................................................................... 11
8. HINTS AND TIPS................................................................................................12
9. CARE AND CLEANING...................................................................................... 13
10. TROUBLESHOOTING......................................................................................15
11. NOISES.............................................................................................................18
12. TECHNICAL DATA........................................................................................... 18
13. INFORMATION FOR TEST INSTITUTES........................................................ 18
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
www.aeg.com2
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of
it appropriately.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments;
–By clients in hotels, motels, bed and breakfast and
other residential type environments.
•To avoid contamination of food respect the following
instructions:
–do not open the door for long periods;
–clean regularly surfaces that can come in contact
with food and accessible drainage systems;
ENGLISH 3
•WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•When the appliance is empty for long period, switch it
off, defrost, clean, dry and leave the door open to
prevent mould from developing within the appliance.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate
around the appliance.
• At first installation wait at least 4
hours before connecting the appliance
to the power supply. This is to allow
the oil to flow back in the compressor.
• Before carrying out any operations on
the appliance, remove the plug from
the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
www.aeg.com4
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
WARNING!
When positioning the
appliance, ensure the supply
cord is not trapped or
damaged.
WARNING!
Do not use multi-plug
adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to
the electrical components (e.g. mains
plug, mains cable, compressor).
Contact the Authorised Service
Centre or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric
shock or fire.
The appliance contains flammable
gas, isobutane (R600a), a natural gas
with a high level of environmental
compatibility. Be careful not to cause
damage to the refrigerant circuit
containing isobutane.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create
pressure on the drink container.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from
the freezer compartment if your hands
are wet or damp.
• Do not freeze again food that has
been thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact
material before putting it in the freezer
compartment.
2.4 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
ENGLISH 5
2.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets.
Please note that some of these spare
parts are only available to
professional repairers, and that not all
spare parts are relevant for all
models.
• Door gaskets will be available for 10
years after the model has been
discontinued.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
www.aeg.com6
3.1 Dimensions
H1 H2
85°
W2 D2
D1
H3
W1
Overall dimensions1)
H1 mm 845
W1 mm 960
D1 mm 700
1) the width, height and depth of the appliance
without the handle and feet
Space required in use1)
H2 mm 945
W2 mm 1160
D2 mm 850
1) the height, width and depth of the appliance in‐
cluding the handle, plus the space necessary for
free circulation of the cooling air
Overall space required in use1)
H3 mm 1532
W2 mm 1160
Overall space required in use1)
D2 mm 850
1) the height, width and depth of the appliance in‐
cluding the handle, plus the space necessary for
free circulation of the cooling air, plus the space
necessary to allow door opening to the minimum
angle permitting removal of all internal equipment
3.2 Location
The appliance should be installed well
away from any sources of heat, such as
radiators, boilers, direct sunlight, etc.
• Place the appliance in a horizontal
position on a solid surface.
• Make sure that the appliance stands
level.
• To achieve the best performance, do
not place the appliance below
overhanging wall units.
• Make sure the air can circulate freely
around the appliance.
If, due to different installation, proper
ventilation requirements are not
respected, the appliance will function
correctly but energy consumption
might increase slightly.
ENGLISH 7
It must be possible to
disconnect the appliance
from the mains power
supply. The plug must
therefore be easily
accessible after installation.
3.3 Positioning
This appliance is not intended to be used
as a built-in appliance.
This appliance should be installed in a
dry, well ventilated indoor position. The
ambient humidity should not exceed
75%.
This appliance is intended to be used at
ambient temperature ranging from 10°C
to 43°C. The correct operation of the
appliance can only be guaranteed within
the specified temperature range.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer
service or to the nearest
Authorised Service Centre.
3.4 Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the
E.E.C. Directives.
3.5 Handle installation guide
1. Take out the handle base and 4
screws from the plastic bag.
2. Place the handle in position
according to the picture. Use Phillips
screwdriver to fix the handle base to
the lid.
3. Take out the handle cover from the
plastic bag. Press it to the front side
of the handle base. Make sure that
the fasteners of the handle cover are
aligned with the assembly holes of
the handle base.
Open and close the lid several times to
make sure the handle is properly
fastened.
www.aeg.com8
4. GENERAL OVERVIEW
4.1 Description of the
appliance
1
5
2
3
4
1Handle
2Basket
3Control panel
4Outer drain plug
5Wheels
ENGLISH 9
5. CONTROL PANEL
5.1 Control panel
12 3 4
1Temperature indicator
2Temperature set button -
3Temperature set button +
4SUPER button
5.2 Switching ON/OFF
1. To switch on the appliance insert the
plug into the mains socket.
2. If the indicators are off, press "+" and
"SUPER" at the same time for 3
seconds to switch on the appliance.
3. To switch off the appliance, press "+"
and "SUPER" for 3 seconds.
5.3 Temperature regulation
The temperature can be regulated
between -14°C and -22°C. We suggest
setting the internal temperature to
approximately -18°C, which guarantees
proper freezing and conservation of the
frozen foods.
To set the temperature:
Press "+" or "-" button to set the desired
temperature.
The exact setting should be chosen
keeping in mind that the temperature
inside the appliance depends on:
• room temperature
• how often the lid is opened
• the quantity of food stored
• the location of the appliance.
If the appliance is used in an ambient
temperature between +10°C and -15°C,
the thermostat should be set to the
coldest temperature (-22°C) to allow the
compressor to work properly.
5.4 SUPER function
The SUPER function accelerates the
freezing of fresh food and, at the same
time, protects already stored foodstuffs
from undesired warming.
1. To activate the function press
SUPER button.
"SF" message will flash on the display for
5 seconds and the function will be
activated.
2. To stop the SUPER function, press
SUPER button again.
The SUPER function stops automatically
after 52 hours and the temperature goes
back to the previous setting.
5.5 Lock mode
To lock/unlock the buttons press "+" and
"-" at the same time for 3 seconds.
The control panel locks
automatically after 30
seconds of inactivity.
5.6 High temperature alarm
When the temperature is continuously
higher than -8°C, an audible alarm will
sound and the "HT" symbol will appear
on the display.
To disable the alarm set a lower
temperature in the appliance. Refer to
"Control panel/Temperature regulation".
www.aeg.com10
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali AEG Congelatore
AEG
AEG ABE81816NS Manuale utente
AEG
AEG SCB614F1LS Manuale utente
AEG
AEG ABE68821LS Manuale utente
AEG
AEG AGE72216NM Manuale utente
AEG
AEG ARCTIS Manuale utente
AEG
AEG A72710GNX1 Manuale utente
AEG
AEG A92970GNM0 Manuale utente
AEG
AEG OKO ARCTIS 1242IU Manuale utente
AEG
AEG ARCTIS Manuale utente
AEG
AEG A72700GNW0 Manuale utente
AEG
AEG OKO_ARCTIS 3192 GA Manuale utente
AEG
AEG A81000TNW0 Manuale utente
AEG
AEG SKE81811DC Manuale utente
AEG
AEG SCE81911TS Manuale utente
AEG
AEG SCE81826ZC Manuale utente
AEG
AEG AGB62226NW Manuale utente
AEG
AEG SANTO C 8 16 41-4i Manuale utente
AEG
AEG RCS632EXMM Manuale utente
AEG
AEG 2170-4 Manuale utente
AEG
AEG AGB728E5NX Manuale utente
