AEG L 73484 NFL Manuale utente
EN User Manual
Washing Machine L 73484 NFL
CONTENTS
1. SAFETY INFORMATION.................................................................................................3
2. SAFETY INSTRUCTIONS................................................................................................ 4
3. PRODUCT DESCRIPTION.............................................................................................. 5
4. CONTROL PANEL...........................................................................................................7
5. PROGRAMMES .............................................................................................................. 8
6. CONSUMPTION VALUES.............................................................................................12
7. SETTINGS...................................................................................................................... 13
8. OPTIONS....................................................................................................................... 14
9. BEFORE FIRST USE.......................................................................................................15
10. DAILY USE................................................................................................................... 15
11. HINTS AND TIPS.........................................................................................................18
12. CARE AND CLEANING.............................................................................................. 20
13. TROUBLESHOOTING.................................................................................................24
14. TECHNICAL DATA..................................................................................................... 26
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler
features you might not find on ordinary appliances. Please spend a few minutes
reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com
2
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and damages. Always
keep the instructions with the appliance for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Obey the maximum load volume of 8 kg (refer to the
“Programme chart” chapter).
•The operating water pressure (minimum and
maximum) must be between 0,5 bar (0,05 MPa) and 8
bar (0,8 MPa).
•The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
ENGLISH 3
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
•Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•If a tumble dryer is stacked on the top of the washing
machine, make sure to use the correct stacking kit
approved by AEG (see more details in chapter
"Accessories - Stacking kit").
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts. When you
move the appliance again you must
block the drum.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C or where it is exposed to the
weather.
• Make sure that the floor where you
install the appliance is flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
• Do not install the appliance where the
appliance door can not be fully
opened.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Only for UK and Ireland: The
appliance has a 13 amp mains plug. If
it is necessary to change the fuse in
the mains plug, use a 13 amp ASTA
(BS 1362) fuse.
www.aeg.com
4
• This appliance complies with the
E.E.C. Directives.
2.3 Water connection
• Make sure not to cause damage to
the water hoses.
• Before you connect the appliance to
new pipes or pipes not used for a
long time, let the water flow until it is
clean.
• The first time you use the appliance,
make sure that there is no leakage.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Use this appliance in a household
only.
• Obey the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that you remove all metal
objects from the laundry.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1 2 3
5
6
7
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for the appliance level
ENGLISH 5
3.2 Available from your
authorized dealer
Only appropriate
accessories approved by
AEG ensure the safety
standards of the appliance. If
unapproved parts are used,
any claims will be
invalidated.
Fixing plate kit (4055171146)
Available from your authorized dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
Stacking kit
Available from your authorized vendor.
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit
manufactured and approved by AEG.
The compatible stacking kits are:
• SKP11/STA9 - If the tumble dryer
depth is 54 cm or 60 cm.
• STA8 - If the tumble dryer depth is 54
cm.
The stacking kit can be used only with
the appliances specified in the leaflet
provided with the accessory.
Read carefully the instructions supplied
with the appliance and with the
accessory.
WARNING!
Do not put the tumble dryer
under the washing machine.
www.aeg.com6
4. CONTROL PANEL
4.1 Control panel description
Ontkreuk
Opfrissen
Katoen
Eco
1 2 3
45678910
1On/Off button (Aan/Uit)
2Programme knob
3Display
4Start Pause button (Start/Pauze)
5Delay start button (Startuitstel)
6Time save button (Tijd Besparen)
7Extra rinse button (Extra Spoelen)
8Stain button (Vlekken)
9Spin reduction button (TPM)
10 Temperature button (Temp.°C)
4.2 Display
A B C D
A
Temperature area:
Temperature indicator
Cold water indicator.
ENGLISH 7
B
Spin area:
Spin speed indicator
No Spin indicator1)
Rinse Hold indicator
1) Only available for Spin/Drain programme.
C
Display indicators:
Washing phase
Rinses phase
Spin phase
Child safety lock
Door locked
You cannot open the appliance door when the symbol is on.
You can open the door only when the symbol goes off.
Delay start
D
Time area:
Programme duration
Delay start
Alarm codes
Message of error
Programme is completed
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature
range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
Washing programmes
www.aeg.com8
Programme
Temperature
range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
Katoen
95°C - Cold
8 kg
1400 rpm
White cotton and coloured cotton. Normal soil
and light soil.
Katoen + Voor-
was
95°C - Cold
8 kg
1400 rpm
White cotton and coloured cotton. Heavy soil and
normal soil.
Extra Stil
95°C - Cold
8 kg White and coloured cotton. Normal soil and light
soil. The programme eliminates all spinning phase
to perform a silent cycle. The cycle stops with water
in the tub.
Synthetica
60°C - Cold
3 kg
1200 rpm
Synthetic items or mixed fabric items. Normal soil.
Synthetica +
Voorwas
60°C - Cold
3 kg
1200 rpm
Synthetic items or mixed fabric items. Heavy soil
and normal soil.
Strijkvrij
60°C - Cold
3 kg
1000 rpm
Synthetic items to be gentle washed. Normal and
light soil.1)
Fijne Was
40°C - Cold
3 kg
1200 rpm
Delicate fabrics as acrylics, viscose, polyester
items. Normal soil.
Wol/Zijde
40°C - Cold
2 kg
1200 rpm
Machine washable wool, hand washable wool and
delicate fabrics with «hand washing» care symbol.2)
Centr./Pompen3)
8 kg
1400 rpm
To spin the laundry and to drain the water in the
drum. All fabrics.
Spoelen
8 kg
1400 rpm
To rinse and spin the laundry. All fabrics.
Jeans
60°C - Cold
8 kg
1200 rpm
Items in denim and jersey. Also for dark coloured
items.
ENGLISH 9
Programme
Temperature
range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
Kort Intensief
60°C - 40°C
5 kg
1200 rpm
Quick washing programme for white/fast colour
cottons and mixed fabrics with light soil level.
20 Min. - 3 kg
40°C - 30°C
3 kg
1200 rpm
Cottons and synthetics items with light soil level
or worn only once.
Katoen Eco4)
60°C - 40°C
8 kg
1400 rpm
White cotton and colour-fast cotton. Normal soil.
The energy consumption decreases and the time of
the washing programme is extended.
Steam programmes5)
Steam can be used for dried, washed or worn once laundry. These programmes can
reduce creases and odours and make your laundry more soft.
Do not use any detergent. If necessary, remove stains by washing or using localized
stain removal.
Steam programmes do not perform any hygienic cycle.
Do not set a Steam programme with these types of items:
• items where it is not specified on the care label as being suitable for tumble drying.
• all items with plastic, metal, wooden parts or alike.
Stoom Opfrissen
40°C
1.5 kg Steam programme for cotton and synthetic items.
This cycle removes odours from the laundry.6)
www.aeg.com10
Indice
Altri manuali AEG Rondella
AEG
AEG LTR8E363C Manuale utente
AEG
AEG L 88489 FL Manuale utente
AEG
AEG LTR75STEAM Manuale utente
AEG
AEG L7FEE842S Manuale utente
AEG
AEG L7FBE84W Manuale utente
AEG
AEG L7FEE942V Manuale utente
AEG
AEG L 60260 TL1 Manuale utente
AEG
AEG OKO LAVAMAT 610 electronic Manuale utente
AEG
AEG LFA5I82WRE Manuale utente
AEG
AEG U03001 lavamat 981 Manuale utente
AEG
AEG LAVAMAT 86741 Manuale operativo
AEG
AEG L7FEE965R Manuale utente
AEG
AEG Lavamat 539 Manuale utente
AEG
AEG LFR6114O4V Manuale utente
AEG
AEG OKO Lavamat 80000 series Manuale utente
AEG
AEG L7FEE942R Manuale utente
AEG
AEG LAVAMAT WSOFT 12 Manuale operativo
AEG
AEG LAVAMAT 50720 Manuale utente
AEG
AEG L7FEE845R Manuale utente
AEG
AEG L 76475 FL Manuale utente
