EN User Manual
Washing Machine L 99697 NFL
CONTENTS
1. SAFETY INFORMATION.................................................................................................3
2. SAFETY INSTRUCTIONS................................................................................................ 4
3. PRODUCT DESCRIPTION.............................................................................................. 6
4. CONTROL PANEL...........................................................................................................7
5. PROGRAMMES ............................................................................................................ 10
6. CONSUMPTION VALUES.............................................................................................14
7. OPTIONS....................................................................................................................... 15
8. SETTINGS...................................................................................................................... 16
9. BEFORE FIRST USE.......................................................................................................17
10. DAILY USE................................................................................................................... 17
11. HINTS AND TIPS.........................................................................................................21
12. CARE AND CLEANING.............................................................................................. 22
13. TROUBLESHOOTING.................................................................................................27
14. EMERGENCY DOOR OPENING............................................................................... 30
15. TECHNICAL DATA..................................................................................................... 30
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler
features you might not find on ordinary appliances. Please spend a few minutes
reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com
2
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and damages. Always
keep the instructions with the appliance for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•If the appliance has a child safety device, we
recommend you activate it.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Obey the maximum load volume of 9 kg (refer to the
“Programme chart” chapter).
•The operating water pressure (minimum and
maximum) must be between 0,5 bar (0,05 MPa) and 8
bar (0,8 MPa).
•The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
ENGLISH 3
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
•Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts. When you
move the appliance again you must
block the drum.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C or where it is exposed to the
weather.
• Make sure that the floor where you
install the appliance is flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
• Do not install the appliance where the
appliance door can not be fully
opened.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Only for UK and Ireland: The
appliance has a 13 amp mains plug. If
it is necessary to change the fuse in
the mains plug, use a 13 amp ASTA
(BS 1362) fuse.
• This appliance complies with the
E.E.C. Directives.
www.aeg.com
4
2.3 Water connection
• Make sure not to cause damage to
the water hoses.
• Before you connect the appliance to
new pipes or pipes not used for a
long time, let the water flow until it is
clean.
• The first time you use the appliance,
make sure that there is no leakage.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Use this appliance in a household
only.
• Obey the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that you remove all metal
objects from the laundry.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
2.5 Internal light
WARNING!
Risk of injury.
• Visible LED radiation, do not look
directly into the beam.
• The type of light bulb or halogen
lamp used for this appliance is only
for household appliances. Do not use
it for house lighting.
• To replace the internal light, contact
the Authorised Service Centre.
2.6 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
ENGLISH 5
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1
2
3
5
6
7
8
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Internal light
6Rating plate
7Drain pump filter
8Feet for the appliance level
3.2 How to activate the child
safety device
This device prevents children or pets to
be closed in the drum.
Turn the device clockwise, until the
groove is horizontal.
You cannot close the door.
To close the door, turn the device
anticlockwise until the groove is vertical.
3.3 Fixing plate kit
(4055171146)
Available from your authorized dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
www.aeg.com6
4. CONTROL PANEL
4.1
Temp.°C TPM Vlekken/
Voorw. Extra
Spoelen Tijd
Besparen Start-
uitstel Start/Pauze
Geheugen 2
Geheugen 1
Stoom
Wol/Zijde
Katoen
Extra Stil
Synthetica
Strijkvrij
Fijne Was
Dekbed
Anti-Allergie
Centrifugeren/
Pompen
Spoelen
Outdoor
20 Min. - 3 kg
Super Eco 30°
Opfrissen
Ontkreuk
Auto Off
Katoen
Eco
1 2 3
6789101112
4
5
1Auto Off button (Auto Off)
2Programme knob
3Display
4Steam touch button (Stoom)
5Memory touch buttons (Geheugen)
6Start/Pause touch button (Start/
Pauze)
7Delay Start touch button
(Startuitstel )
8Time Save touch button (Tijd
Besparen)
9Extra Rinse touch button (Extra
Spoelen)
10 Option touch button (Vlekken/
Voorwas)
11 Spin reduction touch button (TPM)
12 Temperature touch button (Temp.°C)
4.2 Display
A B C D
EFGH
IJ
The display shows:
ENGLISH 7
A
The text bar:
• Guides you in the use of the appliance.
• Shows the programme status and phase.
• Shows alarm messages. Refer to 'Troubleshooting' .
The symbols appear on the display when the related phase or function is set.
BChild safety lock
C
Door locked
You cannot open the appliance door when the symbol is on. You can
open the door only when the symbol goes off.
If the programme is completed but the symbol stays on:
• The «Rinse hold» function is on.
• There is water in the drum.
D
Digit area
Time of the day
When you activate the appliance the display shows the time of the day for some
seconds. To adjust the clock, refer to "Clock setting".
Programme duration
When you touch the related button, the programme cycle duration is displayed for
few seconds then, the time of the programme end appears again.
Programme duration indicator
The indicator comes on when the digits shows the programme dura-
tion.
End time of the programme
Programme end indicator
The indicator comes on when the digits shows the programme end
time.
Time of delay
When you set the delayed start the time of the programme end increases by steps
of 30 minutes till 10 hours and by steps of one hour till 20 hours.
End of the programme
The display shows a zero.
www.aeg.com8
E
This part comes on only if the door is open - Refer to 'Activating the appliance and
setting a programme'.
Maximum allowed load of laundry for the set programme (in kg).
The indicator bar fills accordingly to the laundry set.
The indicator bar fully fills when you put the maximum load.
Graphic bars
To set a function:
The empty indicator bar appears only if the related function is avail-
able for the set programme.
If an indicator bar does not come on, it means that it is not available.
The indicator bar fills accordingly to the set functions.
If you make a wrong selection the message Err indicates that the selec-
tion is not possible.
F
Time save
The indicator comes on when you set one of the programme dura-
tion.
Shortened time
Extra Quick
H
Extra rinsing
The value shows the total number of the rinses.
The indicator bar fills accordingly the numbers of rinses.
ENGLISH 9
I
Stain indicator
Prewash indicator
Soak indicator
The indicator bar fills accordingly to the set functions.
J
Spin speed of the set programme
No Spin indicator1)
Rinse Hold indicator
1) Only available for SPIN/DRAIN programme.
K
Default temperature of the set programme
Cold water
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Washing programmes
Katoen
95°C - Cold
9 kg
1600 rpm
White cotton and coloured cotton. Normal soil
and light soil.
Extra Stil
95°C - Cold
9 kg White and coloured cotton. Normal soil and
light soil. The programme eliminates all spinning
phase to perform a silent cycle. The cycle stops
with water in the tub.
Synthetica
60° C - Cold
4 kg
1200 rpm
Synthetic items or mixed fabric items. Normal
soil.
Strijkvrij
60° C - Cold
4 kg
800 rpm
Synthetic items to be gentle washed. Normal
and light soil.1)
www.aeg.com10
Indice
Altri manuali AEG Rondella
AEG
AEG L6SNE47SCE Manuale utente
AEG
AEG L7FBE49BSA Manuale utente
AEG
AEG L 76475 NFL Manuale utente
AEG
AEG L 60260 TL1 Manuale utente
AEG
AEG Lavamat 539 Manuale utente
AEG
AEG L8FC8432BI Manuale utente
AEG
AEG L6FBG142R Manuale utente
AEG
AEG L6FBE740G Manuale utente
AEG
AEG L6FBK741P Manuale utente
AEG
AEG L6VAPOR Manuale utente
AEG
AEG LAVAMAT 60840 L Manuale utente
AEG
AEG LR7696AAD4 Manuale utente
AEG
AEG L6FSG841P Manuale utente
AEG
AEG L 98699 FL2 Manuale utente
AEG
AEG L6FE7261IM Manuale utente
AEG
AEG LAVAMAT 16850A3 Manuale utente
AEG
AEG L 75471 FL Manuale utente
AEG
AEG L7TBN73E Manuale utente
AEG
AEG L 89499 FL Manuale utente
AEG
AEG LAVAMAT 82470 BI Manuale utente
