AEG LFR7314O4V Manuale utente
aeg.com/register
LFR7314O4V
EN User Manual | Washing Machine
aeg.com\register
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 3
2. SAFETY INSTRUCTIONS.............................................................................. 5
3. PRODUCT DESCRIPTION............................................................................. 6
4. TECHNICAL DATA......................................................................................... 8
5. INSTALLATION...............................................................................................8
6. CONTROL PANEL........................................................................................ 13
7. DIAL AND BUTTONS....................................................................................15
8. SETTINGS.................................................................................................... 18
9. BEFORE FIRST USE....................................................................................19
10. PROGRAMMES.......................................................................................... 19
11. DAILY USE..................................................................................................25
12. HINTS AND TIPS........................................................................................ 30
13. CARE AND CLEANING.............................................................................. 32
14. TROUBLESHOOTING................................................................................ 38
15. CONSUMPTION VALUES.......................................................................... 42
16. QUICK GUIDE............................................................................................ 43
17. ENVIRONMENTAL CONCERNS................................................................45
2 ENGLISH
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
ENGLISH 3
1.2 General Safety
• This appliance is for washing domestic-type, machine-
washable laundry only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Do not change the specification of this appliance.
• The appliance maximum load is 10.0 kg. Do not exceed the
maximum load of each programme (refer to the
“Programmes” chapter).
• The operating water pressure at the water entry point from
the outlet connection must be between 0.5 bar (0.05 MPa)
and 10 bar (1.0 MPa).
• The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
• The appliance must be connected to the water mains using
the new supplied hose sets, or other new hose sets
supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
• Do not use high pressure water sprays and/or steam to
clean the appliance.
• Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
4 ENGLISH
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply with
relevant national regulations.
• Remove all the packaging and the transit
bolts including rubber bush with plastic
spacer.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in the future they
must be reattached to lock the drum to
prevent an internal damage.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Follow the installation instructions supplied
with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance where
the temperature can be less than 0°C or
where it is exposed to the weather.
• The floor area on which the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
• Do not install the appliance directly above
a floor drain.
• Do not spray water on the appliance and
do not expose it to excessive humidity.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Do not put a closed container to collect
possible water leakage under the
appliance. Contact the Authorised Service
Centre to ensure which accessories can
be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not touch the mains cable or the mains
plug with wet hands.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
2.3 Water connection
• The inlet water shall not exceed 25 °C.
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not
used for a long time, where repair work
has been carried out or new devices fitted
(water meters, etc.), let the water flow until
it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• Do not use an extension hose if the inlet
hose is too short. Contact the Authorised
Service Centre for the replacement of the
inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing of the
appliance with the use of water in the
factory.
• You can extend the drain hose to
maximum 400 cm. Contact the Authorised
Service Centre for the other drain hose
and the extension.
ENGLISH 5
• Make sure that there is access to the tap
after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock, fire, burns
or damage to the appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber parts of
the washing machine. Prewash such
fabrics by hand before loading them into
the washing machine.
• Do not touch the glass door while a
programme operates. The glass can get
hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be available
for 10 years after the model has been
discontinued: motor and motor brushes,
transmission between motor and drum,
pumps, shock absorbers and springs,
washing drum, drum spider and related
ball bearings, heaters and heating
elements, including heat pumps, piping
and related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware including
reset software, door, door hinge and
seals, other seals, door locking assembly,
plastic peripherals such as detergent
dispensers. Please note that some of
these spare parts are only available to
professional repairers, and that not all
spare parts are relevant for all models.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
drum.
• Dispose of the appliance in accordance
with local requirements for the disposal of
Waste Electrical and Electronic Equipment
(WEEE).
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all modern
requirements for an effective treatment of
laundry with low water, energy and detergent
consumption and proper care of fabric.
• The UniversalDose drawer with a
compartment dedicated to each type of
detergent, including a compartment for
PODS®, equipped with a system able to
spread and mixing the detergent in an
optimal way, and to dissolve the detergent
residues after each cycle.
• The ProSense technology detects the
laundry load size defining the programme
duration in 30 seconds. The washing
6 ENGLISH
programme is tailored to the laundry load
and the type of fabric without consuming
more time, energy and water than
necessary.
• The steam has a quick and easy way to
refresh the clothes. The gentle steam
programmes remove odours and reduce
creases in dry fabrics so they need little
ironing.
The Plus Steam option, finishes every
cycle with gentle steam that relaxes the
fibres and reduces fabric creasing. Ironing
will be easier!
• The AEG Steam Fragrance, thanks to the
steam programmes offers the perfect
solution for refreshing even the most
delicate garments without washing. Use
the delicate fragrance exclusively
developed by AEG to add a pleasant
feeling of "just-washed" garment to the
removing odours and wrinkles action.
3.2 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports:
A. model name
B. product number
C. electrical ratings
D. serial number
ENGLISH 7
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /66.0 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2100 W
10 A
50 Hz
Level of protection against ingress of solid particles and moisture ensured
by the protective cover, except where the low voltage equipment has no
protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply 1) Cold water
Maximum Load Cotton 10.0 kg
Spin Speed Maximum spin speed 1351 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging and the transit
bolts before installing the appliance.
WARNING!
Use the gloves.
1. Remove the external film. If necessary,
use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Remove the internal film.
4. Open the door and remove the
polystyrene piece from the door seal and
all the items from the drum.
8 ENGLISH
5. Carefully put the appliance down on its
rear side.
6. Put the front polystyrene packaging
element on the floor under the appliance.
Make sure not to damage the hoses.
7. Remove the polystyrene protection from
the bottom.
1
2
8. Pull up the appliance in vertical position.
9. Remove the power supply cable and the
drain hose from the hose holders.
It is possible to see water flowing
from the drain hose. This is due to
the testing with water of the appliance
in factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in the
user manual bag, in the holes.
ENGLISH 9
We recommend that you keep the
packaging and the transit bolts for any
movement of the appliance.
5.2 Positioning and levelling
1. Install the appliance on a flat hard floor.
Make sure that carpets do not stop the
air circulation below the appliance.
Make sure that the appliance does not
touch the wall or other units.
2. Loosen or tighten the feet to adjust the
level.
WARNING!
Do not put cardboard, wood or equivalent
materials below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the appliance
level prevents the vibration, noise and
the movement of the appliance when in
operation.
When the appliance is installed on a
plinth or a tumble dryer is stacked on the
washing machine, use the accessories
described in chapter 'Accessories'. Read
carefully the instructions supplied with
the appliance and with the accessory.
5.3 Fixing plate kit
If you install the appliance on a plinth that is
not an accessory supplied by AEG, secure
the appliance with the fixing plates. This
spare part is available in web shop or from
authorised dealer.
Read carefully the instructions supplied with
the accessory.
5.4 The inlet hose
1. Connect the water inlet hose to the back
of the appliance.
2. Position it toward left or right depending
on the position of the water tap.
10 ENGLISH
Indice
Altri manuali AEG Rondella
AEG
AEG L 76685 FL Manuale utente
AEG
AEG OKO-Lavamat 623D Digitronic Manuale utente
AEG
AEG LR8E70480 Manuale utente
AEG
AEG LFN8E8436C Manuale utente
AEG
AEG LF6ES8431A Manuale utente
AEG
AEG L6FBK866G Manuale utente
AEG
AEG LAVAMAT LN 79680A3 Manuale utente
AEG
AEG LTR8E363C Manuale utente
AEG
AEG OKO LAVAMAT 610 electronic Manuale utente
AEG
AEG LAVAMAT 16850A3 Manuale utente
AEG
AEG LAVAMAT 62840 Manuale utente
AEG
AEG L7FNE48SC Manuale utente
AEG
AEG LAVAMAT 60 Manuale utente
AEG
AEG L6FBI847 Manuale utente
AEG
AEG L7FEC146R Manuale utente
AEG
AEG L7FBREMEN Manuale utente
AEG
AEG L 72672 NFL Manuale utente
AEG
AEG LAVAMAT 7200 ELECTRONIC Manuale operativo
AEG
AEG L 74489 WVFL Manuale utente
AEG
AEG L7FEC48S Manuale utente
