Operational Instructions Purification
Lock
Press “ LOCK” button on the remote control or touch “LOCK”
button of machine for 5 seconds to start/end operation panel
lock function.
Wind speed adjustment
Press “SPEED” button of remote control or touch “SPEED” of
machine to adjust the speeds when the machine is power on.
Filter replacement
Replacefilter：
Filter loading：
1. Pre- filter
2. HEPA filter
3. Activated carbon filter
Remove the panel Remove the filters
to be replaced
Load the filters
in its line
Touch “ AUTO” and “TIMER”
button together for 5 seconds
to restart( Filter replacement
indicator ending)
Close the
front panel
Anion
Press “FUNCTION” button of remote control or touch “ ANION”
button on the machine to start or end anion function.
UV
Press “FUNCTION” of remote control to start or end
UV purification.
In ordinary occasion, filter replacement
indicator is off, it will need to replace filter
when the light flashes and ring bells.
Water adding indicator
When water tank placed in order and water
full, the icon is off, when it lacks of water,
the icon is on, water adding needed.
Lack of
water
12 3 4 5
3 filters 8 stages purifications
P08 P09
filter
LOCK
SPEED
ANION
FUNCTION
Auto
1.Pre-filter,which consist of the the aluminum frame and 0.3 aluminum mesh and primary
efficiency filter cotton.Using for removal of dandruff, hair, dust ,larger particle etc. This
filter can reduce user costs by cleaning repeatedly.
2.Efficient HEPA filter, effectively filters micro particles like airborne allergens, pollen,
mites, dust, mold spores, textiles fiber products, with a ratio 99% to PM2. 5 purification
based on the international standard, and the minimum particle to 0. 3μm.
3. Activated carbon filter can effectively remove formaldehyde, benzene, xylene, TVOC,
smoke and garbage odors.
4. Molecular sieve adsorption layer, is a kind of particles of granular activated carbon filter,
purifying air by absorbing and exchanging. The pores of sieve gaps are high enough with
large volume inside. After high temperature activated zeolite, they form pores in same
sizes, which have strong absorption ability to block particles larger than the pores allowed
and to pass the particles smaller or water/gas molecular, to increase the life of activated
carbon filter and save costs for users.
5. Photocatalyst layer function:
A: Antibacterial property
B: It can effectively decompose organic compounds and toxic substances, such as
benzene, ammonia, TOVC etc.
6. Cold catalyst filtration layer( No UV) function:
A: Antibacterial property
B: It can effectively decompose organic compounds and toxic substances, such as
benzene, ammonia, TOVC etc.
7.Ultraviolet sterilizing filter
UV light can destroy microbial molecular structure of DNA or RND and kill variety of
bacteria.
8. Negative anion functions well at removing bacteria and dust, known as “vitamin in the air”
by Medical community. 10 million negative ions indoor, are produced per second by this
machine, which helps promote metabolism and improve human body immunity.
