AG Neovo DF-55 Manuale utente

•Important Safety Instructions ..........................................1

–Safety precautions and maintenance………………………..1

–Use………………………………………………………………4

–Installation Notes……………………………………………….6

•Package Content .................................................................8

–Unpacking………………………………………………………8

–Accessories……………………………………………………10

–DF-55 Option Accessories…………..……………………….11

–Overview……………………………………………………….12

•Setting Up the Display ......................................................14

–Step1 : Tear down the downside covers……………………14

–Step2 : Place the upside part into downside part………….15

–Step3 : Connect the LVDS and 24V………………………...16

–Step4 : Reinstall the downside covers……………………...17

–Step5 : Open the user door, Connect by HDMI connector.18

–DF-55 Full Size Stand installation………….……………….19

–Using the Remote Control……………………………………21

–OSD Setting Menu……………………………………………22

•Trouble shooting ................................................................26

•Specifications ................................................................ 27

•Product Dimensions ........................................................28

Table of contents

Safety precautions and maintenance

WARNING: Use of control, adjustments or

procedures other than those specified in this

documentation may result in exposure to shock,

electrical hazards and/or mechanical hazards.

Important Safety Instructions

Read and follow these instructions when connecting and

using your display:

Operation:

•Keep the display out of direct sunlight and away from stoves or any

other heat sources.

•Remove any object that could fall into ventilation holes of power box

or prevent proper cooling of the display’s electronics.

•Don’t block the ventilation holes on the power box.

•When positioning the display, make sure the power plug and outlet

are easily accessible.

•When turning off the display by detaching the power cord, wait 6

seconds before re-attaching the power cord for normal operation.

•Ensure the use of an approved power cord provided byAG Neovo at

all times. If your power cord is missing, please contact your local

service center.

•Don’t subject the display to severe vibration or high impact conditions

during operation.

•Don’t knock or drop the display during operation or transportation.

•Provide an earthing connection before the mains plug is connected to

the mains.And, when disconnecting the earthing connection, be sure to

disconnect after pulling out the mains plug from the mains.

Safety precautions and maintenance

Maintenance:

•To protect your display from possible damage, do not put excessive

pressure on the display.

•Unplug the display if you are not going to use it for an extensive

period of time.

•Unplug the display if you need to clean it with a slightly damp cloth.

The screen may be wiped with a dry cloth when the power is off.

However, never use organic solvent, such as, alcohol, or ammonia-

based liquids to clean your display.

•To avoid the risk of shock or permanent damage to the set, do not

expose the display to dust, rain, water or an excessively moist

environment.

•If your display becomes wet, wipe it with dry cloth as soon as possible.

•If a foreign substance or water gets in your display, turn the power off

immediately and disconnect the power cord. Then remove the foreign

substance or water.

•Don’t store or use the display in locations exposed to heat, direct

sunlight or extreme cold.

Safety precautions and maintenance

Read and follow these instructions when connecting and using

your display:

•Unplug the display if you are not going to use it for an extensive

period of time.

•Unplug the display if you need to clean it with a slightly damp cloth.

The screen may be wiped with a dry cloth when the power is

off. However, never use alcohol, solvents or ammonia-based liquids.

•Consult a service technician if the display does not operate normally

after having followed the instructions in this manual.

•Keep the display out of direct sunlight and away from stoves or any

other heat sources.

•Remove any object that could fall into the vents or prevent proper

cooling of the display’s electronics.

•Don’t block the ventilation holes on the power box.

•Keep the display dry. To avoid electric shock, do not expose it to rain

or excessive moisture.

•When turning off the display by detaching the power cable or DC

power cord, wait for 6 seconds before re-attaching the power

cable or DC power cord for normal operation.

•To avoid the risk of shock or permanent damage to the set do not

expose the display to rain or excessive moisture.

•When positioning the display, make sure the power plug and outlet

are easily accessible.

Use

Remote Controller Precautions：

•This product requires remote switch (ON/OFF) from Front Side ; the

Back Side only has OSD function operated by remote controller.

Front Side Back Side

The Front Side have a user

door.

Use

Disconnect devices:

•For pluggable equipment, the socket-outlet shall be installed near the

equipment and shall be easily accessible.

Installation Notes

Please make sure you

have a solid installation.

(Locks on the ground)

As shown in the picture.

You can install Dual

side display by screws

x10(M6x20mm)

Ground

Installation Notes

IPC installation:

•Dual side display (DF-55) contains a plate metal, it is used to fix your

IPC.

•The relative position of the screw holes is shown below. You can choose

the fit screw holes to use.

Package Content

Unpacking

•This product is packed in a carton, together with the standard

accessories.

•Due to the size and weight of this display it is recommended for two

people to move it.

•After opening the carton, ensure that the contents are complete and in

good condition.

Package 1

BOTTOM CARTON

BOTTOM CUSHION

DF-55 DUAL SET

PACKING BAG

TOP CUSHION

UPPER CARTON

PLASTIC GRIP
