AG Neovo E-W19 Manuale utente

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

www.agneovo.com

The strength of hard glass protection

and smart multimedia functions: the

E-W19 is the optimum display for

professional and public environments.

e E-W19 features an impressive super-resolution panel capable of

displaying 1440 x 900 pixels as well as NeoV™ Optical Glass which

protects the display from scratches, accidents and other incidental

damage. Built-in DVI input, stereo speakers and a convenient

headphone jack make the E-W19 an excellent multimedia solution

for professional home oce environments or multi-user public spaces

such as classrooms, libraries, computer labs, or retail outlets.

> 19” widescreen format

> WXGA+1440 x 900 resolution

> NeoV™ Optical Glass

> Elegant exterior

> Unique rear cover design on backside of display

> Swi 3 ms response time

> Crisp 3000:1 dynamic contrast ratio

> High 380 cd/m2brightness

> Dual digital and analogue inputs

> Built-in HDCP for HD-format video

> 1080p support

> Built-in speakers with headphone jack

> Auto-adjustment for optimal settings

> Hot key for preferred video mode: User, Text, Movie, Game, and Graphic

> Kensington® security socket

> VESA standard wall mount

> Compliance with leading TCO’06

E-W19

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: EW1900 Version 5.0, 20080530

Speciﬁcations E-W19

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

19.0” (481 mm)

WXGA+1440 x 900

0.285 mm

380 cd/m2( Typical)

3000:1 (DCR)

170°/160° (Typical)

16.2M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 24 kHz - 80 kHz

V: 55 Hz - 76 Hz

Max. Pixel Clock 150 MHz

Input Analogue

Digital

15-Pin D-Sub

24-Pin DVI-D

Audio Audio In

Audio Out

Speaker

3.5 mm Audio Line-in

3.5 mm Headphone Jack

2 W x 2

Power AC-DC Adaptor

Power

Consumption

External

AC 100 - 240 V, 50 - 60 Hz

< 48 W (On)

< 2 W (Stand-by)

< 1 W (Off)

NeoV™

Optical Glass

Thickness

Reﬂection Rate

Transmission Rate

Hardness

3.0 mm (0.18”)

< 1%

> 96%

> 6H (MOH’s Rating)

Plug & Play VESA DDC-2B, DDC-CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt +5° ~ +25°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

477 x 370 x 171 mm

(18.8” x 14.6” x 6.7”)

565 x 515 x 178 mm

(22.2” x 20.3” x 7.0”)

Weight Product Weight

Packaged Product Weight

6.2 kg (13.7 lbs)

8.4 kg (18.4 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, FCC, NOM, CB, CE,

TUV/Baurt, Nordic, BSMI,

Energy Star, GOST-R/HYGIENIC,

TCO’06, WEEE, RoHS

Accessories Supplied Quick Guide, CD ROM (user

manual and drivers), audio

cable, power adaptor, power

cord, 15-Pin D-Sub cable, 24-Pin

DVI-D cable

E-W19

VESA standard wall mount allows for secure

mounting almost anywhere

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

DVI input, built-in speakers and easy access headphone

jack for multimedia and interactive applications

Impressive modern exterior and slim design
