AG Neovo H-17 Manuale utente

www.agneovo.com

REACH

H-17

True multimedia value: a vivid 17”

display with built-in stereo speakers

designed for both home and ofﬁce

environments.

Featuring AG Neovo’s award-winning image quality that matches

the performance typically found on competitor’s higher-end

models, the H-17 delivers excellent multimedia value. e rapid

response time ensures smooth playback of video, while the built-in

speakers deliver high-quality stereo sound. e slim bezel design

and VESA compatible wall mounts allow for a variety of display

options. e H-17 is the perfect multimedia display for any

cost-conscious environment.

> SXGA 1280 x 1024 resolution

> Slim and sleek design

> Fast 3 ms response time

> Crisp 700:1 contrast ratio

> High 300 cd/m2brightness

> Built-in speakers

> Easy-to-use friendly OSD

> Auto-adjustment for optimal viewing

> Kensington® security socket

> VESA standard wall mount

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: H170A0 Version 22.0, 20100101

Speciﬁcations H-17

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

300 cd/m2( Typical )

700:1 (Typical)

Hard Coating (3H),

Anti-glare Treatment

160°/160° (Typical)

16.7M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 30 kHz - 80 kHz

V: 56 Hz - 75 Hz

Max. Pixel Clock 140 MHz

Input Analogue 15-Pin D-Sub

Audio Audio In

Speaker

3.5 mm Audio Line-in

1 W x 2

Power AC-DC Adaptor

Power

Consumption

Internal

AC 100 - 240 V, 50 - 60 Hz

< 38 W (On)

< 2 W (Stand-by)

< 1 W (Off)

Plug & Play VESA DCC 2B, DCC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -5° ~ +20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

371 x 384 x 211 mm

(14.9” x 15.4” x 8.4”)

433 x 455 x 144 mm

(17.3” x 18.2” x 5.8”)

Weight Product Weight

Packaged Product Weight

4.2 kg (9.4 lbs)

5.5 kg (12.1 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, TUV/GS, CB,

GOST-R, FCC, CE, BSMI,

WEEE, RoHS, Vista/Basic,

REACH

Accessories Supplied Quick Guide, CD ROM (user

manual and drivers),

15-Pin D-Sub cable, audio

cable, AC power cord, base

H-17

Sleek design with an anti-glare display panel for

superior viewing comfort

Integrated stereo speakers provide rich sound to accompany

games, DVDs and other visual entertainment
