NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

Given its hard glass protection and

metal casing, the RX-22 promises

to excel in all sorts of modern

surveillance environments, however

demanding they may be.

Specically design and tested for commercial video security

applications, the RX-22 comes with AG Neovo’s AIP technology

that reproduces contrast, colours and details with an extraordinary

faithfulness. Armed with EcoSmart Sensor and Anti-Burn-in™

technologies, the energy ecient RX-22 runs on less than

0.5W at stand-by mode, a feature that ensures its performing

nonstop service immaculately. More versatile capabilities allow

multiple RX-22 displays to be easily installed in any surveillance

conguration for security environments.

> LED-backlit technology with high FHD 1920 x 1080 resolution

> NeoV™ Optical Glass

> Anti-Burn-in™ technology

> AIP technology: PIP and PBP functions; 3D Comb Filter/ Deinterlace/ Noise

Reduction; Image rotation function / Freeze

> Horizontal resolution up to 620TVL(NTSC), 625TVL(PAL)

> Quick signal-switching time ( ≤ 0.8 sec.)

> Selectable aspect ratio for ultimate image

> EcoSmart Sensor for low watt power consumption

> Black-level alignment

> Versatile inputs: VGA, DVI, HDMI, S-Video, CVBS in/out (BNC x 2), Audio in/out

> Built-in speakers (2W x2)

> BNC video out passive looping

> Power DC-out design to power connected peripherals

> Durable metal housing

> Rigorous screening of the components for mission-critical 24/7 applications

RX-22

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: RX2200, Version 1.1, 20120701

Speciﬁcations RX-22

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

LED-backlit TFT LCD

21.5”

FHD 1920 x 1080

0.2482 mm

250 cd/m2 (Typical)

1,000 : 1 (Typical)

170°/160° (Typical)

16.7M

3 ms (GTG)

Horizontal

Resolution

TV Lines 620TVL (NTSC), 625TVL (PAL)

Frequency (H/V) H: 24 kHz - 83 kHz

V: 50 Hz - 85 Hz

Input VGA

DVI

CVBS

S-Video

HDMI

15-Pin D-Sub

24-Pin DVI-D

BNC x 2

4-Pin mini DIN

HDMI x 1

Output CVBS

DC Output

BNC x 2

12V/500mA, DC jack 2.5Ø

Audio Audio In

Audio Out

Speaker

1 x stereo audio in for PC (audio

jack, 3.5 Ø)

RCA L+R for video

RCA L+R

2W x 2

Power AC-DC Adaptor

Power

Consumption

External

100 – 240V, 50 – 60Hz

<25W (On)

<0.5W (Active Off)

<0.5W (Off)

Sync Format Video System NTSC/PAL/SECAM

NeoV™

Optical Glass

Thickness

Reﬂection Rate

Coating Hardness

3.0 mm (0.18”)

< 1%

> 9H

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F~104°F)

10%~90% (No condensation)

Storage

Conditions

Temperature

Humidity

-20°C ~ 60°C (-4°F~140°F)

5%~95% (No condensation)

Mounting VESA FPMPMI Yes (100mm x 100mm & 75mm x

75 mm)

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

513 x 369 x 155 mm

(20.2” x 14.5” x 6.1”)

633 x 497 x 213 mm

(24.9” x 19.6” x 8.4”)

Weight (net) Product Weight

Packaging Weight

6.9 kg (15.2 lbs)

9.5 kg (20.9 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, CB, CE, BSMI, RoHs, WEEE,

REACH

Accessories Supplied Quick Guide, CD ROM(user manual),

power cord, power adapter,

15-Pin D-Sub cable, audio cable

RX-22

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

On top of PIP and PBP, Smart Omni Viewer oers selectable

aspect ratios and the option of 180° image rotation

EcoSmart Sensor and versatile capabilities ensure

round-the-clock operations

Available in black or white

Multiple video inputs (HDMI, DVI, VGA, CVBS, S-Video)

make possible eortless system integration
