AG Neovo X-W19 Manuale utente

www.agneovo.com

X-W19

A versatile display with the

perfect combination of widescreen

performance, durability and

multimedia inputs demanded by

modern professional environments.

NeoV™ Optical Glass protects a bright 19” widescreen panel making

the X-W19 ideal for retail displays and multi-user environments

such as labs, libraries, banks and more. Images come alive with

the super-resolution WXGA+screen capable of displaying up to

1440 x 900 pixels. Strong metal casing, VESA compatible wall

mounts and the exibility of multiple video inputs make the X-W19

a truly versatile display device.

> 19” widescreen format

> WXGA+1440 x 900 resolution

> NeoV™ Optical Glass

> Slim 14 mm bezel

> Distinctive metal casing for added strength

> Swi 3 ms response time

> Crisp 3000:1 dynamic contrast ratio

> Multiple video inputs including Analogue, Digital, S-Video, CVBS

> Built-in HDCP allows HD-format video

> 1080p support

> Hot key for preferred video mode: User, Text, Movie, Game, and Graphic

> Auto-adjustment for optimal settings

> Kensington® security socket

> VESA standard wall mount

> Compliance with leading TCO’06

> Available colours: black, white

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: XW1900_XW1901 Version 6.0, 20081201

Speciﬁcations X-W19

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

19.0” (484 mm)

WXGA+1440 x 900

0.285 mm

380 cd/m2 (Typical)

3000:1 (DCR)

170°/160° (Typical)

16.7M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 30 kHz – 80 kHz

V: 56 Hz – 75 Hz

Max. Pixel Clock 140 MHz

Input Analogue

Digital

S-Video

CVBS

15-Pin D-Sub

24-Pin DVI-D

4-Pin Mini Din S-Video

CVBS Jack

Power AC-DC Adaptor

Power

Consumption

External

AC 100 – 240 V, 50 – 60 Hz

< 48 W (On)

< 2 W (Stand-by)

< 1 W (Off)

NeoV™

Optical Glass

Thickness

Reﬂection Rate

Transmission Rate

Hardness

3.0 mm (0.18”)

< 1%

> 96%

> 6H (MOH’s Rating)

Plug & Play VESA DCC 2B, DCC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt 0° ~ +15°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

448 x 351 x 155 mm

(17.6” x 13.8” x 6.1”)

534 x 472 x 195 mm

(21.0” x 18.6” x 7.7”)

Weight Product Weight

Packaged Product Weight

5.4 kg (11.8 lbs)

7.9 kg (17.5 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, TUV/Baurt, Nordic,

CB, TCO06, GOST-R, NOM,

FCC, CE, BSMI, WEEE, RoHS,

Energy Sta

Accessories Supplied Quick Guide, CD ROM (user

manual and drivers), power

cord, power adaptor, 15-Pin

D-Sub cable, 24-Pin DVI-D

cable, S-Video cable, CVBS

cable, DVI-HDMI cable

X-W19

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

A host of video input options allows for rich

video connectivity

Metal casing for secure mounting, rapid heat

dissipation and a unique industrial look

Attractive slim industrial design saves space on

desktops or multi-display congurations
