AgfaPhoto DC-2030M Manuale utente

DC-2030m

Quick guide

Thank you for purchasing this AgfaPhoto digital camera. Please read these operating

instructions carefully in order to use the digital camera correctly. Keep the instructions in a safe

place after reading so that you can refer to them later.

Precautions

•Do not aim the camera directly into the sun or other intense light sources which could

damage your eyesight.

•Do not try to open the case of the camera or attempt to modify this camera in any way.

High-voltage internal components create the risk of electric shock when exposed.

Maintenance and repairs should be carried out only by authorized service providers.

•Do not press the flash too close to the eyes of animals or young children. Eye damage may

result. Please remain at least one meter away from infants when using flash.

•Keep the camera away from water and other liquids. Do not use the camera with wet hands.

Never use the camera in the rain or snow. Moisture creates internal danger and may cause

electric shock.

•Keep the camera and its accessories out of the reach of children and animals to prevent

accidents or damage to the camera.

•If you notice smoke or a strange odor coming from the camera, turn the power off immediately.

Take the camera to the nearest authorized service center for repair. Never attempt to repair

the camera on your own.

•Use only the recommended power accessories. Use of power sources not expressly

recommended for this equipment may lead to overheating, distortion of the equipment, fire,

electrical shock or other hazards.

Disclaimer

We assume no responsibility over and above the provisions of the Product Liability Law for

damages suffered by the user or third parties as a result of inappropriate handling of the product

or its accessories, or by their operational failure and by their use. We reserve the right to make

changes to this product and its accessories without prior notice.

Warning!

Never disconnect to open the camera or remove any parts of it. This will invalidate all guarantee

claims.

1. Shutter Button

2. Stabilizer

3. Power Button

4. Speaker

5. USB/AV Terminal

6. Microphone

7. Lens

8. Self-timer Lamp

9. Flash

10. LCD Monitor

11. Operation Lamp

12. Zoom Button

13. Playback Button

14. Strap Ring

15. Mode Button / Delete Button

16. Menu Button

17. Battery Cover

18. Four-way Control: Flash Button / Macro

Button / SET / DISP Button

19. Tripod Socket

20. Memory Card Slot Cover

ŸTo remove the card, gently press on the

edge of the card and release it. Pull the

card out and close the SD Card cover

Changing the Mode

You can record images and voices in the REC mode. And using the PLAYBACK mode to

replay, delete, or edit images on the LCD monitor.

Switching between REC mode and PLAYBACK mode

In REC mode, press the PLAYBACK button

(Œ) to switch to the PLAY mode.

In PLAY mode, press the PLAYBACK (Œ) or

the MODE (•) button to switch to the REC

mode.

Selecting the REC mode

Set the camera to the REC mode

Launch the mode palette.

ŸPress the MODE button (•) to

show the scene mode palette.

Select a mode.

ŸUse the four-way control to

select a desired mode and press

the SET button to confirm the

setting.

Using the Menus

When a menu is displayed, the four-way control and the SET button are used to make the

desired settings.

REC menu

Turn the power on, and set the

camera to the REC mode.

Open the REC menu.

ŸPress the MENU button to

display the menu.

Select an item.

Press or to select a menu item.

Change the setting.

Press or to change the setting.

Press the MENU or the SET button to save the settings and close the menu.

Setup menu

Turn the power on, and set the

camera to the REC or PLAYBACK

mode.

Press the MENU button to open

the REC or PLAYBACK menu.

ŸThe menu displays depends on

whether you are in the REC

mode or the PLAY- BACK

mode.

Open the Setup menu.

ŸPress four-way control to select SETUP ( ) and then press the SET button to

display the Setup menu.

Select an item.

ŸPress or to select a menu item and then press or the SET button to

launch the submenu.

Change the setting.

ŸPress or to select an option and press or the SET button to apply the

setting.

Press the MENU button to close the menu.

Deleting a Single File

Turn the power on, and set the

camera to the PLAYBACK

mode

Open the menu.

ŸPress the MENU button (Œ),

then use the four-way control

(•) to select Delete ( ) and

press the SET button (•).

Press or (•) to select [SINGLE], and then press the SET button (•).

Press or (•) to select the image you want to delete.

Press the SET button (•) to delete the image.

ŸRepeat step 4~5 to delete images.

Connecting the Camera to a Computer with the USB Cable

Install the USB software driver

included with the bundled CD-ROM.

Connect the supplied USB cable to

the computer’s USB port and turn on

the camera.

ŸThe LCD screen turns off when the

connection to the computer has

been successfully completed.

Open [My Computer] or [Windows Explorer]. A “Removable Disk”appears

in the drive list.

Double-click the “Removable Disk”icon to view its contents.

ŸFiles stored on camera are located in the folder name “DCIM”.

Customer care

More information on the complete AgfaPhoto digital camera product range can be found under

www.plawa.com / www.plawausa.com.

To return a product, you will need an RMA number which must be clearly visible on the returned

shipment. You can find further information on the return of goods either by phoning our Support

Hotlines or via the plawa website under the Menu item "Service & Support".

Service & Repair (USA/ Canada):

1-866 475 2605

www.plawausa.com

Support Service (USA/ Canada)

support-apdc@plawausa.com

Service & Repair Hotline (EU):

00800 752 921 00 (from a landline only)

Service & Support Hotline (Germany):

0900 1000 042 (1.49 Euro/ min. from a German landline only)

Online Service / International contact (Not for USA/ Canada):

support-apdc@plawa.com

Manufactured by

plawa-feinwerktechnik GmbH & Co. KG

Bleichereistraße 18

73066 Uhingen

Germany

AgfaPhoto is used under license of Agfa-Gevaert NV & Co. KG or Agfa-Gevaert NV.

Neither Agfa-Gevaert NV & Co KG nor Agfa-Gevaert NV manufacture this product or provide any

product warranty or support. For service, support and warranty information, contact the distributor

or manufacturer.

Disposal of Waste Equipment by Users in Private Households in the

European Union

This symbol on the product or on its packaging indicates that this product must not be disposed of

with your other household waste. Instead, it is your responsibility to dispose of your waste

equipment by handing it over to a designated collection point for the recycling of waste electrical

and electronic equipment. The separate collection and recycling of your waste equipment at the

time of disposal will help to conserve natural resources and ensure that it is recycled in a manner

that protects human health and the environment. For more information about where you can drop

off your waste equipment for recycling, please contact your local city office, your household waste

disposal service or the shop where you purchased the product.

FCC Compliance and Advisory

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: 1.) this device may not cause harmful interference, and 2.) this device must accept any

interference received, including interference that may cause unsatisfactory operation. This

equipment has been tested and found to comply with the limits for a Class B peripheral, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communication. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures.

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment. When shielded interface cables have

been provided with the product or when specified additional components or accessories have

elsewhere been designated to be used with the installation of the product, they must be used in

order to ensure compliance with FCC regulations.

Declaration of Conformity

We herewith confirm the following designated product: AgfaPhoto digital camera DC-2030m has

been tested and found to comply with the requirements set up in the council directive on the

approximation of the law of members’states relating to the EMC Directive 2004/108/EC. For the

evaluation regarding to the electromagnet compatibility, the following standards were applied:

EN 55022: 2006 Class B

EN 55024: 1998+A1: 2001+A2: 2003

EN 61000-3-2: 2006

EN 61000-3-2: 1995 + A1: 2001 + A2: 2005

IEC 61000-4-2: Edition 1.2: 2001-04

IEC 61000-4-3 Edition 3.0: 2006

IEC 61000-4-4 2004

IEC 61000-4-5 Edition 2.0: 2005

IEC 61000-4-6: Edition 2.2: 2006

IEC 61000-4-8 Edition 1.1: 2001-03

IEC 61000-4-11 Second Edition: 2004

AS/NZS CISPR 22:2006

The device is marked with CE logo.
