AIPTEK Mobile Eye HD Manuale utente
User Manual
| 1
English
Names of Parts
Clip Mount Magnet Mount
Tripod Mount
Strap Mount
Record Button
Status
Indicator
Mic
Micro SD
Card Slot
Micro USB Port
Strap Hook
Speaker
Video Mode
Photo Mode
Local Mode
Cloud Mode
Mode Button
Power Button
2 | English
Getting Starte
d
Charging the Unit
• Before initial use, fully charge the camera via power adapter or
USB to computer system
.
'XULQJFKDUJLQJWKHVWDWXVLQGLFDWRUÀDVKHVLQUHG:KHQWKH
camera is fully charged, the indicator turns off.
Modes Navigation
• Press Power button to turn on camera.
• Press Mode button to switch between modes.
Install [Unieye] or [PC APP]
Before using wireless mode, install below applications to setup
for both Local Mode and cloud setup, and also use them to watch
live view in Local Mode.
•
Mobile app: Download [Unieye] from Google Play or Apple Store.
3&VRIWZDUH,QVWDOO>3&$33@IURPFDPHUD:LQGRZVSDJH
Video Mode Press Record button to shoot and press again to stop.
Photo Mode Press Record button to take pictures.
Local Mode Connecting camera to mobile or PC directly for remote
controlling, live viewing, album managing, and camera
setup.
Cloud Mode &RQQHFWLQJFDPHUDWRFORXGVHUYHUYLDDFFHVVSRLQW$3
or mobile hotspot for internet video or live monitoring.
With micro SD
card inserted
Camera Modes Video Mode
Photo Mode
:LUHOHVV0RGHV Local Mode
Cloud Mode
Without micro
SD Card :LUHOHVV0RGHV Local Mode
Cloud Mode
| 3
English
Local Mode
(
WLAN
)
For initial use, install [Unieye] app on
mobile. Each camera has a unique
Camera ID. ( 8[[[[[[[[
Password is not required for the initial use, however, it is advised
to go to [Setup] in app to setup password after connected.
Connect to Camera
• Set camera to Local Mode
and wait until the indicator
stops flashing.
2QPRELOHDFWLYDWH:L)L
• Run [Unieye].
• Press camera bar to start.
• Set camera to Local Mode
and wait until the indicator
stops flashing.
• On mobile, go to [Settings]
>:L)L@ Choose a camera.
3G connection will switch to
:L)LZLWKLQPLQ
• Run [Unieye].
• Press camera bar to start.
For iOS user: For Android user:
Mobile / PC
Take Photo
6'FDUGUHTXLUHG 6'FDUGUHTXLUHG
Loop Recording
• Record and archive in 3 min interval
Quad View
Zoom In Zoom out Shoot Video
Invert Image
Two Way Voice
3UHVVWRHQDEOH4XDG9LHZXSWRIRXUFDPHUDV
7DS>@EXWWRQWRUHWXUQWRVLQJOHYLHZ
• Tap to talk to the camera from mobile; tap
again to allow the camera to talk back to
mobile.
Android:
iOS:
1RWH0RYHWKHFDPHUDIXUWKHUDZD\IURPPRELOHZKHQHFKRRFFXUV
2. Mobiles with poor CPU performance may affect audio during broadcasting.
4 | English
AP
Cloud Server
Cloud AP
AP
Mobile Hotspot
Mobile / PC
USTREAM
3G/4G
A live broadcasting social media.
USTREAM
Recommended Cloud Server for Access:
C
loud Mode
(
Internet
)
Before using Cloud Mode, it is required to setup cloud AP and
cloud server in Local Mode.
Step 1: Setup Cloud AP in Local Mode
On mobile, start [Unieye], go to app [Setup] [Cloud Settings]
>&ORXG$3@6HOHFWD:L)LQHWZRUNIURP>$3/LVW@DQGHQWHU
password. If no preferred AP is found, press [Other...] from [AP
List] Enter network name and password.
Note: Mobile hotspot can be act as cloud AP.
Step 2: Setup Cloud Server in Local Mode
• New user, press then enter email/username/password/
FRQ¿UPIRU
auto-registration. Returning user, enter username/
password only.
• Press [Save to Camera].
| 5
English
C
loud Mode
(
Internet
)
Step 3: Connect Camera to Cloud Server
Two ways to connect to cloud server:
2Q>8QLH\H@SUHVV>&DPHUDWR&ORXG@LQ>6HWXS@SDJH
2. On camera, set to Cloud Mode .
:KLOHFRQQHFWLQJWKHVWDWXVLQGLFDWRUÀDVKHVUDSLGO\LQRUDQJH
2QFHFRQQHFWHGWKHVWDWXVLQGLFDWRUÀDVKHVLQJUHHQ,IFRQQHFWLRQ
IDLOVWKHVWDWXVLQGLFDWRUÀDVKHVLQUHGDQGDOHUWVLQGLIIHUHQW
beeping frequencies.
Or go into [Unieye] to view the error message.
Step 4: View Live Videos on Cloud Server
Options to view live videos:
8VHPRELOHDSSUSTREAM
is available in Google Play or
Apple Store.
2. Visit website: http://www.ustream.tv
Then search for username and select "username's show" to watch
live video through camera.
Alert Cause/Solution
One time
Cannot connect to cloud AP or invalid network password.
&DPHUDQRWLQVLGH:L)LDUHDRUZHDNVLJQDO
Check AP settings or move camera closer to cloud AP.
Two times
No internet access or the cloud server is not accessible.
Cannot log in cloud server via internet.
&ORXGVHUYLFHPD\EHEORFNHGE\¿UHZDOO
Three times
Cloud server username or password is incorrect. Refer
to in [Setup] for instructions.
Username already taken. Create new account in [Unieye].
1RWH8675($0FORXGVHUYHUKDVULJKWWRFKDQJHVHUYLFHSROLF\
:KHQXVLQJFORXGPRGHPDNHVXUHWKHPRELOHLVFRQQHFWHGWR**
3. Experiencing delays while viewing live video may be due to high
LQWHUQHWWUDI¿F
6 | English
U
se P
C
APP
7RXVH>8QLH\H@IHDWXUHVLQ3&LQVWDOO>3&$33@VRIWZDUH¿UVW
The [PC APP] has similar features and interface to [Unieye] for
easy user experience.
Installing [PC APP] from Camera
• Connect the camera to PC via a USB cable.
• [PC APP] AutoRun/AutoPlay activates.
• If AutoRun/AutoPlay is not starting:
Go to [My computer] and search [PC APP] for installation.
• Once installed, unplug the camera from PC then run [PC APP].
Local Mode - [PC APP]
Use [Unieye] to setup camera's Local Mode and Cloud Mode. [PC
APP] has more features than [Unieye].
• Press [View HD] or double-click the viewing window to
maximize it into full screen. Double-click again to return to the
[PC APP] interface.
• To save videos or photos to PC:
Go to [Album] Select videos or photos Press [Save to
PC].
Mass Storage and Webcam Modes
:KLOHFDPHUDLVSOXJJHGLQWR3&SUHVV0RGHEXWWRQRQFDPHUD
WRVZLWFKEHWZHHQ0DVV6WRUDJH0RGHGHIDXOWDQG:HEFDP
Mode. The status indicator shows steady red in Mass Storage
0RGHDQGVWHDG\JUHHQLQ:HEFDP0RGH
In Skype or QQ, select
89&B:(%&$0
.
| 7
English
C
amera Ind
i
cat
i
o
n
Condition Status Indicator Alert
Recording Flashing green One time
Loop Recording Flashing orange One time
Charging Flashing red None
Fully Charged No indication Two times
Low Battery Flashing red every 5 sec.
:DUQLQJ
Five times
6KXWGRZQ
Power Off No indication Two times
Auto Power Off
PLQVLGOH Flashing red Two times
Memory Full
SD Card Error Flashing red Three times
Camera Hotkey
Forced Shutdown
Press and hold Power button for 5 sec. to
turn off camera.
Forced
Default
Settings
Press and hold Mode and Record buttons
for 5 sec. to restore default settings.
Car Camcorder
Press and hold Record button for 3 sec. to start
loop recording
and
invert image.
8 | English
T
roubleshoot
i
n
g
Situation Cause/Solution
Camera cannot turn on Battery power is low. Recharge the battery.
Camera is frozen Press Power button for 5 sec. to turn off.
Press Power button twice to turn on.
Camera cannot record
No SD card or SD card is full.
SD card cannot be recognized. Format SD
card in [Unieye] or replace SD card.
Camera not found Turn on camera, switch to Local Mode. Press
"Refresh" on mobile or PC to scan again.
Forgot camera password Press both Mode and Record buttons for 5
sec. to reset.
Cannot watch live view Move camera closer to mobile.
Flickering segments on
live view 79V\VWHPVHWWLQJ+]+]LVLQFRUUHFW
