8
page (Date/Time page) until “Schedule 1” appears in the menu, you can then use the ▲
(UP/TIMER) and ▼ (DOWN/VOLUME) buttons to toggle between ON (activate) and OFF
(deactivate).
To adjust the setti ng s for schedule 1, press the STOP button while on “Schedule 1” in main menu
page (Date/Time page) to access the different schedule settings. There are three different settings
that can be configured; Day, Start Time, and Stop Time. Use the ▲ (UP/TIMER) and ▼
(DOWN/VOLUME) buttons to toggle between the different settings.
*Day set: - Is the day or days the schedule 1 will activate and is represented by the following; S, M,
T, W, T, F, S . a n d re p resent Sunday through Saturday respectively. Use the ▲ (UP/TIMER) and ▼
(DOWN/VOLUME) buttons to select the days you would like the AG-1600 to run. For example; If
you would like the AG-1600 to run on Mondays and Wednesdays, adjust the days setting to read _,
M, _, W, _, _, _. Only the “M” (Monday) and “W” (Wednesday) should be displayed in the menu.
Once you have finished your selection press the STOP button once to confirm and save the settings.
*Start Time
– is the time of day the AG-1600 will begin to fog. This setting is displayed in 24 hour
time and can be adjusted between 00:00 and 23:59 by using the ▲ (UP/TIMER) and ▼
(DOWN/VOLUME) buttons. Once you have finished your selection press the STOP button once to
confirm and save the settings.
*Stop Time
– is the time of day the AG-1600 will stop the fogging process. This setting is displayed
in 24 hour time and can be adjusted between 00:00 and 23:59 by using the ▲ (UP/TIMER) and ▼
(DOWN/VOLUME) buttons. Once you have finished your selection press the STOP button once to
confirm and save the settings.
Once all settings are made press STOP button again to exit the settings menu and return to the
“Schedule 1” menu page and use the ▲ (UP/TIMER) and ▼ (DOWN/VOLUME) buttons to either
activate or deactivate schedule 1.
Example of the schedule function: If you wish the AG-1500 to start to fog at 13:00 and stop fogging
at 13:15 in the afternoon every Monday, the settings should be set as follows: Day: _, M, _, _, _, _,
_. , Start Time: 13:00, Stop Time: 13:15,
To acti vate and chang e the setting for schedule two (2), tap the MENU button four (4) times from
the main menu page (Date/Time page) until “Schedule 2” appears in the menu and follow the same
instructions listed above for Schedule 1.
