This instruction must be kept available during installation and
for future maintenance.
1. FUNCTIONS
COOLING
The cooler works best if the already cooled cooler box is lled
with food and beverages that have already been cooled
beforehand. This way they will stay cool for a long time and
even become slightly more chilled. If the products are placed in
the cooler at room temperature, their cooling will take a couple
of hours. The cooling function cools the cooler box approx. 15
°C below the ambient temperature.
2. START AND STOP
Never connect the cooler's 12V power cord directly to mains
electricity (230V).
The cooler has a xed 12V/DC power cord that can be connect-
ed to the DC/12V socket of a car (not for lorries, 24V). A
so-called lorry adapter is available as an accessory: 24V-12V.
Connect the DC/12V power cord on the lid to the socket of a
car's DC/12V power socket(not for lorries/24V).
If the cooler is to be used connected to a car that has its engine
turned o, you may purchase an additional battery guard
device to avoid draining the car battery unnecessarily. The
product number of this battery guard accessory is 9300250,
GTIN 6435200112798.
3. SAFETY
1. Remember to ensure sucient ventilation for the cooler's
motor when using the cooler. Do not use the cooler in
closed spaces such as the trunk of a car, for example.
Do not leave the cooler in direct sunlight.
2. Do not block the motor's air channels on the lid.
Leave at least 10 cm of free space in front of the ventilator.
3. Avoid substances that leak colour. Do not use products that
contain acid, gasoline or alcohol when cleaning
the surfaces of the cooler.
4. Do not use a damaged or tangled power cord.
5. When the cooler is used in hot or humid conditions,
moisture will condense on the inside of the cooler.
This is not a malfunction. Wipe clean with a dry cloth.
6. Only the importer may repair the cooler. If repairs are
conducted by any other party, the warranty is voided.
7. Do not pour liquids on the cooler.
8. Do not allow children to use the cooler unsupervised.
9. Do not place electric equipment inside the cooler.
10. The cooler can be connected to several kinds of power
sources. Separately sold accessory: mains adapter 230V,
no. 9300201, GTIN 6435200237989.
11. The cooler can be used while camping.
Do not use in the rain. Avoid direct sunlight.
AIRAM BASIC COOLER 20L 12V
Fixed electric cable 2 m for car DC/12 V.
4. MAINTENANCE AND SERVICE
1. Unplug the power cord from the power source before
cleaning.
2. Remove grease with dishwashing liquid, for example.
3. Remove waxy dirt with a damp cloth.
4. Do not clean with running water.
5. Remove dirt from the air inlet with a vacuum cleaner or
brush and then wipe with a damp cloth.
5. MULFUNCTIONS
Please check the following points before sending the cooler to
be serviced: The cooler does not work and the fan does not
spin.
1. Ensure that the power cord for car is plugged in.
2. Ensure that the DC/12V power socket receives power.
In most vehicles, the car key must be in the so-called
"accessory position" for the 12 V power socket to work.
3. Ensure that the car’s DC/12V power socket provides proper
contact. The contact surfaces can become stained from
exposure to cigarette dust, which reduces their electrical
conductivity. Clean the power socket with a non-conductive
brush and a suitable cleaning agent until the contact
surfaces are clean and bright. If the power socket
heats up more than usual during use, it might be the result of
poor contact or the inside of the socket might be damaged.
4. The circuit of a car DC/12V power socket is protected with
a separate fuse. Ensure that the fuse is intact.
MALFUNCTION 1: Cooling function does not work. Reason:
poor contact at the socket/the device has been subjected to
direct sunlight/the device has been used in a space that is too
tight.
MALFUNCTION 2: Strange sound or vibration. Reason: the
device is malfunctioning, unplug it from the power source
immediately and send it in to be serviced.
MALFUNCTION 3: The device smells burnt or the cooler has
melted. Reason: The device has overheated. Unplug it
immediately and send it in to be serviced.
WARRANTY: 2 years from the date of purchase. The receipt of
purchase must be shown. The warranty covers all possible
material and factory defects, provided that the product has
been used according to instructions. The warranty does not
cover damages caused by user error, carelessness or accidents.
19.11.26
User manual
NO. GTIN
9300060 6435200266361
KG
3
DIMENSIONS
38 x 24 x 40 cm
Input power DC/12V approx. 45 W for cooling, 3.7A.
Climate class N.
Noise level 40 dB [A].
Indicator light
Sementtitehtaankatu 6, FI-04260 Kerava. www.airam.fi
