Aircare PILLAR Manuale utente
Everything you need to know about your
Read and save these instructions
PILLAR
ALL PU320DDWD MODELS 1B73380
8/2020
1
Remove the PILLAR from its packaging. Be
sure to grab the package under the base.
You should have:
a. Base
b. Water tank and lid
#1B73246
c. Remote (includes a CR2025 battery)
#1B73244
d. Essential oil diuser pad
#AURP10PK
e. Essential oil tray
#1B73248
f. Demineralization cartridge (this is in the Styrofoam cube)
#DC4003PK
g. AC adapter
#1B73247
h. Owner’s manual
#1B73380
1
LET’S GET YOU UP AND RUNNING
Prefer to see a video?
Watch the PILLAR set-up at
aircareproducts.com/support.
SCAN THE CODE TO THE RIGHT
WITH YOUR PHONE’S CAMERA
If you are missing any parts, or need
replacement parts, call us at 800.547.3888 or
visit our website aircareproducts.com.
♥We hope you love your PILLAR.
a
b
c
ef
g
h
d
2
Install the demineralization cartridge in
the bottom of your tank (not in the base):
Remove the demineralization cartridge from the
Styrofoam cube.
Look inside your water tank and locate the water
release port on the bottom of the tank. It has a
black rubber ring around it.
Hold the demineralization cartridge with the
beads on top, then press the cartridge into the
slot around the water release port. Twist the
cartridge clockwise until it clicks into place over
the port.
Your demineralization cartridge helps break down
the minerals naturally found in water – improving
your air quality and preventing the white dust
people sometimes notice with ultrasonic
humidifiers. You should replace your cartridge
every 60-90 days.
Put your PILLAR base on a level surface
in the room where humidity is most
needed. To avoid condensation, make sure the
unit is at least two inches from the wall and not
under a window.
2
3
CUTAWAY VIEW
OF TANK
TOP VIEW
OF TANK
DC4003PK
Note: The PILLAR is an ultrasonic humidifier, so it emits a very fine mist.
Position the lid to direct this mist away from furnishings and electronics.
Put the water tank on the base and fill the
tank. Your PILLAR holds 1.7 gallons of water.
4
To add essential oils, remove the
essential oil tray from the side of the
PILLAR base. Add a few drops of essential oil to
the tray pad. Add more oil to your liking. Only use
essential oils in the tray; any brand will work with
the PILLAR.
5
About water additives:
• Do not add essential oils directly to the PILLAR water tank. Only
add them to the essential oil tray.
• Do not use water softeners.
Press the humidity setting button
on either the unit or the remote to set
your humidity level from 25% to 65%. Your mist
output will pause when the set humidity level is
reached, and resume when the humidity dips
below your setting. When set to 65%, your unit
will run continuously.
Press the timer button on either the
unit or the remote to run your PILLAR
for a set period of 1, 2, 4, or 8 hours. The timer
icons will show on the display when the timer
is on. Turn the timer o by pressing the timer
button again.
7
8
9
Press the power button on either
the unit or the remote. Your PILLAR
has three mist output levels and it will be on the
highest output when you turn it on. Pushing the
power button again will set the output to medium,
and pressing it again will set the output to low.
7
9 8
6
6Attach the AC adapter to the PILLAR
and plug in your unit and remove the
plastic tab from the remote.
About the display:
• While running, your PILLAR will alternately display the temperature
and relative humidity on the screen.
• When the water tank is empty, the unit will beep and display a red
water droplet on the screen. Your PILLAR will turn o until it is refilled.
That’s it! Your PILLAR is ready to use.
5
Regular cleaning is important for preventing
mold, mildew, and other bacterial growth in your
humidifier. It also keeps your PILLAR working its
best
NOTE: Do not allow any liquid to get into the air intake while you
are cleaning your PILLAR.
1. Let the unit run until it’s empty, then turn it o and unplug it.
2. Remove the tank and pour out any remaining water from
the tank and base.
3. Remove the demineralization cartridge from the bottom of
the tank. Throw your cartridge away if it is time to replace it.
Otherwise, rinse it well with running water and put it in a sink
while you finish cleaning your PILLAR.
4. Fill the water tank half-full with warm water and 2 ½ cups of
white vinegar. Use a cup to scoop out a little of this mixture
and pour it into the base. Swish the remaining water-vinegar
mixture around the tank. Let this sit for 20 minutes.
5. With the mixture in the base, use a soft cloth to clean the
inside of the base. Gently scrub the oscillator (the dark ring
in the basin). Let it sit for 20 minutes.
6. After 20 minutes, empty the water tank and base.
7. Dampen a sponge with white vinegar and wipe down the
base, tank, and lid. Rinse everything thoroughly.
8. Wipe everything dry and replace the demineralization
cartridge, if needed. Then reassemble.
When storing your PILLAR, discard the used demineralization
cartridge and clean the unit as described above. Dry the unit
thoroughly, and store in a temperature-regulated area. Do not
install a new demineralization cartridge until you are ready to use
your humidifier again.
HOW TO CLEAN YOUR PILLAR
AIR INTAKE
6
Où se trouve mon numéro de
série?
Pourquoi mon unité produit-elle
très peu de brume?
Pourquoi la goutte d’eau
clignote-t-elle en rouge?
Puis-je commander des
pièces de rechange?
Pourquoi y a-t-il de la
poussière blanche autour de
mon humidificateur?
Votre numéro de série se trouve sur l’autocollant au bas
de votre appareil. Vous pouvez l’écrire ici pour référence
future :
__________
Votre PILLAR n’a plus d’eau.
Oui! Les pièces de rechange de PILLAR et leurs numéros
de référence sont indiqués à la page 10.
La poussière blanche est le résultat de minéraux
naturellement présents dans votre eau. Elle est inoensive.
• Assurez-vous que vous n’utilisez pas d’adoucisseur d’eau
dans votre PILLAR.
• Installez une nouvelle cartouche de déminéralisation.
Q
Q
Q
Q
Q
R
R
R
R
A
FOIRE AUX QUESTIONS
• Assurez-vous que votre appareil PILLAR se trouve sur
une surface plane.
• Assurez-vous que votre humidificateur est rempli d’eau.
• Assurez-vous que l’oscillateur est propre
info@essickair.com aircareproducts.com
800.547.3888
PILLAR
TOUS LES MODÈLES PU320DDWD
Tout ce que vous devez savoir sur votre
Lisez et conservez ces instructions
Pour toute autre problème, contactez nos experts en humidification!
Ils sont prêts à vous aider par téléphone, courriel ou chat.
PILLAR
TOUS LES MODÈLES PU320DDWD 1B73380
8/2020
Tout ce que vous devez savoir sur votre
Lisez et conservez ces instructions
9
