Airlink101 AWLL5026 Manuale utente

Ver. 1A

PackageContent:

•USBAdapter

•Driver&UtilityCD

•QuickInstallation Guide

•USBCable

Model#AWLL5026

Section 1

Install Utility and Driver

Quick Installation Guide

802.11g USB XR™ Adapter

This Quick Installation Guide only provides the basic instructions. For more

advancedfeatures, pleaserefer tothe User’sManual inthe providedCD.

Note: Donotconnect theUSB Adapterto yourcomputeruntil youhave reached

theappointedstep.

For Windows 98SE and ME users, you may be prompted to insert the Windows

98SE or ME CD during the driver installation. Be sure to have your Windows 98SE

or ME CD ready.

Note: If the Autorun screen doesn’t appear automatically, go to Start, Run, and

type D:\Utility\Setup.exe (whereD isthe letterof your CDdrive) andclick OK.

Step 1 Insert the Driver & Utility CD into your CD drive and select Install Utility

and Driver from the menu.

Step 2 Click Next at the welcome screen.

Step 3 Click Next to accept the default destination folder.

Continue on back...

ContinueonBack

Step 4 Verify Yes, I want to restart my computer now is selected and click

Finish torestartyourcomputer. Step 7 Select Install the software automatically and click Next.

Step 8 Click Continue Anyway at the Windows Logo Screen.

(For Windows 2000, click Yes at the Digital Signature Not Found prompt).

For Windows 98SE and ME, select Search for the best driver for your device

and click Next. Verify all the check boxes are checked and click Next.

Step 9 Click Finish. (Restart the computer for Windows 98SE and ME).

Step 5After the computer is restarted, connect the USBAdapter to your

computer’s USB port.

Step 6 If Windows asks to connect to Windows Update, select No, not this time

and click Next.

Section 3

Section 2

Configure the USB Adapter

To open the USB Adapter’s utility go to Start > (All) Programs > Airlink101 USB

XR Adapter Utility >Airlink101 USB XR Adapter Utility.

Step 1 Go to the AP List tab, select the SSID (Network Name) of the wireless

network you wish to connect to, and click Connect.

Step 2 If encryption is not enabled for the selected access point / router, skip to

Step 6. Otherwise, enter a Profile Name for your wireless setting and click Next.

Step 3 Verify that the Network Name matches the SSID of your wireless network

and click Next.

E-mail:[email protected]

TollFree: 1-888-746-3238

WebSite:www.airlink101.com

Section 3

Technical Support

Section 4

Step 4 Select the proper encryption setting for your wireless router or access

point from the drop-down menu and click Next.

Step 8Verifythat you arereceiving adequate SignalStrengthand LinkQuality and

thatyouhave beenassigned a validIP address(instead of all0’s).

Step 5 Follow the on-screen instructions to complete the encryption settings.

Click Complete when finished.

andlogos that areidentifiedastrademarks and/or service marksare,unlessnoted otherwise, thetrademarksandservice marks of AirLink101.

Allother product or service namesaretheproperty of their respective holders.AirLink101productsare protected under numerous U.S. and

foreignpatents and pending applications, maskworkrights,andcopyrights.

*Theoreticalmaximum wireless signal rate basedonIEEEstandard 802.11gspecifications.Actualdata throughputwillvary.Network conditions

andenvironmental factors, including volume ofnetworktraffic,buildingmaterials and construction, mix ofwirelessproductsused,radio

frequencyinterference (e.g., cordless telephonesandmicrowaves)as well asnetworkoverheadlower actual data throughputrate.

Step 6 You should see a blue circle around the antenna icon indicating a valid

connection.

Step 7 Go to the Link Information tab and click on the More button.
