Redwing GPRS

User Guide

Version 2.30 - September 2006

Redwing GPRS - User Guide, version 2.30 ii

Information in this document is subject to change without notice.

WARNING

The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm

from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

Important Notice

Because of the nature of wireless communications, transmission and reception of data can never be guaranteed.

Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data

are rare when wireless devices such as the AirLink Communications modem are used in a normal manner with a

well-constructed network, the AirLink modem should not be used in situations where failure to transmit or

receive data could result in damage of any kind to the user or any other party, including but not limited to per-

sonal injury, death, or loss of property. AirLink Communications, Inc., accepts no responsibility for damages of

any kind resulting from delays or errors in data transmitted or received using the AirLink Communications

modem, or for failure of the AirLink Communications modem to transmit or receive such data.

Safety and Hazards

Do not operate the AirLink Communications modem in areas where blasting is in progress, where explosive

atmospheres may be present, near medical equipment, near life support equipment, or any equipment which

may be susceptible to any form of radio interference. In such areas, the AirLink Communications modem MUST

BE POWERED OFF. The AirLink Communications modem can transmit signals that could interfere with this equip-

ment. Do not operate the AirLink Communications modem in any aircraft, whether the aircraft is on the ground

or in flight. In aircraft, the AirLink Communications modem MUST BE POWERED OFF. When operating, the Air-

Link Communications modem can transmit signals that could interfere with various on board systems. The driver

or operator of any vehicle should not operate the AirLink Communications modem while in control of a vehicle.

Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and

provinces, operating such communications devices while in control of a vehicle is an offence.

Limitation of Liability

The information in this manual is subject to change without notice and does not represent a commitment on the

part of AirLink Communications, Inc. AIRLINK COMMUNICATIONS, INC. SPECIFICALLY DISCLAIMS LIABILITY

FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEM-

PLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS

OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY AIRLINK COMMUNICATIONS, INC. PROD-

UCT, EVEN IF AIRLINK COMMUNICATIONS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES

OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.

Warranty Summary

For the full and complete text, refer to the warranty appendix in the modem user guide or to the AirLink website

(http://www.airlink.com) for the full text of the warranty.

Software: Software is warrantied for 90 days to work in substantial conformance to applicable software specifi-

cations. AirLink’s sole obligation is to, at their option, refund the liscense fee or replace the software with other

software.

Hardware: All equipment is warrantied for one year after delivery to conform with AirLink’s specifications and be

free from manufacturing defect. Optional warranty extensions can be purchased for two and four years which

would increase the warranty period to three and five years respectively. If under normal use, the hardware

proves to have any such defect and the Customer notifies AirLink of such defect within the warranty period, Air-

Link, at its option, will either repair or replace the same without charge but only upon written authorization and

in accordance with instructions of AirLink using a Return Material Authorization ("RMA") process (details of the

process are in the full warranty statement).

THIS WARRANTY DOES NOT COVER PRODUCTS THAT DO NOT CONFORM TO SPECIFICATIONS BECAUSE OF

ACCIDENT, ALTERATIONS, FAILURE TO FOLLOW INSTRUCTIONS, USE OUTSIDE THE SCOPE OF ANY OTHER

PROVIDED DOCUMENTATION (E.G., USER GUIDE, INSTALLATION GUIDE, QUICK START GUIDE), MISUSE,

ABUSE, NEGLECT, FIRE, FLOOD OR ACTS OF GOD.

Redwing GPRS - User Guide, version 2.30 iii

Contents

Introduction to Redwing GPRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

GPRS Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Establishing an Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Using the GPRS Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

How your Redwing gets its IP Address from Your Wireless Service Provider . . . . . . . . . . . . . . 2

APN (Access Point Name) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Dynamic vs Static IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Common Uses for the Redwing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Activating the Redwing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Installing the SIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Opening the Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Ejecting the SIM tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Inserting the SIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Finishing the SIM installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting the Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting the Redwing to a computer or other device . . . . . . . . . . . . . . . . . . . . . . . . . .9

Redwing Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Specifications for the Redwing GPRS . . . . . . . . . . . . . . . . . . . . . . . . . .10

Physical Characteristics: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Data Services & RF Features: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Environmental: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Power Management: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Short Message Service (SMS): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Serial Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Mounting Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

AT Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Direct Serial Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Direct Serial Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Using AT Commands with a Terminal Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Information and Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Serial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

GPRS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Redwing GPRS - User Guide, version 2.30 iv

Contents

Windows Dial-up Networking (DUN) . . . . . . . . . . . . . . . . . . . . . . . . . .24

Installing the Modem Driver in Microsoft Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Dial-Up Networking (PPP) Configuration for Microsoft Windows . . . . . . . . . . . . . . . . .27

Making a DUN Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Warranty Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Warranty Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Standard Software Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

One Year Standard Equipment Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Optional Two Year Extended Equipment Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Optional Four Year Extended Equipment Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Warranty Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Remedy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

WARRANTY DISCLAIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

LIMITATION OF LIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

General Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Frequently Asked Questions and Technical Support . . . . . . . . . . . . . .38

FAQ Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Power, Antennas, and Signal Strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

The Redwing’s IP Addresses and Local Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Security for the Redwing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

AirLink Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

AirLink Support Web Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

AirLink Documentation and Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contacting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Redwing GPRS - User Guide, version 2.30 1

CHAPTER 1 Introduction to Redwing GPRS

The Redwing's rugged form factor is ideal for industrial and commercial applications that require

real-time communications. The Redwing provides cellular data communications for a variety of

applications, such as telemetry, public safety, SCADA, traffic control, traffic metering, transit

arrival systems and more.

FIGURE 1. Redwing front and back

GPRS Overview

Establishing an Internet Connection

The Internet Service Provider (ISP) from you to the Internet is Your Wireless Service Provider with

your Redwing as the connection to Your Wireless Service Provider.

General Packet Radio Service (GPRS) is packet-switched with many users sharing the same

transmission channel, but only transmitting when they have data to send. This means that the total

available bandwidth can be immediately dedicated to those users who are actually sending at any

given moment, providing higher utilization where users only send or receive data intermittently.

GPRS provides speeds of 30–70 kbps with bursts up to 170 kbps.

Redwing GPRS - User Guide, version 2.30 2

Introduction to Redwing GPRS

Steps of a connection:

Using the GPRS Network

As stated above, when your Redwing registers on the Your Wireless Service Provider network, it

receives an IP address. There are two types of addresses on networks: dynamic and static.

•Dynamic addresses are assigned on a “need to have” basis. Your Redwing might not always

receive the same address each time it connects with Your Wireless Service Provider.

•Static addresses are permanently assigned to a particular account and will always be used

whenever your Redwing connects to the Internet. The IP address will not be given to anyone

else.

How your Redwing gets its IP Address from Your Wireless Service Provider

1. When your Redwing is powered on, it automatically searches for cellular service using GPRS.

2. Your Redwing establishes a PPP (Point to Point Protocol or “dial” up connection) link to Your

Wireless Service Provider’s network, also called registering on the network, and receives an IP

address from Your Wireless Service Provider.

3. When your Redwing has received the IP address from Your Wireless Service Provider, then it

is ready to allow communication to the cellular network.

To use your Redwing’s serial port to connect to the Internet from your computer, you need to con-

nect the computer directly to the Redwing’s serial port and use Dial-Up Networking (DUN).

FIGURE 2. Using the Redwing to connect to the Internet

The APN (Access Point Name) defines the network that is accessible with your .

APN (Access Point Name)

Internet

GPRS

Redwing GPRS - User Guide, version 2.30 3

Introduction to Redwing GPRS

Private network connections are unique for each configuration and not covered as part of the stan-

dard installation.

Dynamic vs Static IP Addresses

If you need to contact the Redwing, a device connected to the modem, or a host system using the

Redwing from the Internet, you need to have a known IP (such as one which is static) or domain

name (an IP address which is converted by a DNS server into a word based name).

Most ISPs (cellular included) use dynamic IP addresses rather than static IP addresses since it

allows them to reuse a smaller number of IP addresses for a large number of customers. A

dynamic IP address is suitable for many common Internet uses, such as web browsing, looking up

data on another computer system, or other client functions (such as data only being sent out or only

being received after an initial request).

Common Uses for the Redwing

With GPRS, you can choose a type of Access Point which most suits your needs. Your Wireless

Service Provider can set up your account so you are able to have a Private IP address, a Public IP

address, a static IP address, or even a custom IP address which essentially extends your com-

pany's local area network to include the Your Wireless Service Provider network. The Access

Point is the link to the type of network with the Access Point Name (APN) as the gateway. It sets

up the DNS and other configurations needed to communicate on that network.

For most accounts, the default “Internet APN” is the connection you will need and want to config-

ure for your . Contact Your Wireless Service Provider to find out if your account is set up differ-

ently or uses a different APN.

Note: If you have a dynamic IP address for your Redwing, you will not be able to

contact the modem using a name.

Caution: The IP address given to your Redwing by Your Wireless Service Provider

must be Internet routable if you do not have a direct connection to the Your Wire-

less Service Provider's network (example, using frame relay).

The Redwing’s rugged construction and cellular connection make it ideal for use in remote and/or

industrial locations.

The Redwing is designed to work with legacy devices which do not need the advanced features of

ALEOS.

Redwing GPRS - User Guide, version 2.30 4

Introduction to Redwing GPRS

FIGURE 3. Remote Internet Access

Redwing GPRS - User Guide, version 2.30 5

CHAPTER 2 Activating the Redwing

The SIM (Subscriber Identity Module) card in the Redwing is a smartcard securely storing the key

identifying a mobile subscriber. Generally, you will only need to install the SIM once in the life of

the modem and it may be pre-installed by AirLink.

Installing the SIM

To install the SIM, you will only need a small phillips head screw driver.

a. Unplug the Redwing’s power and all cables.

b. Using a small phillips head screw driver, remove the screws on the back of the Redwing.

c. Slide the casing off of the Redwing and set it aside.

Note: If the SIM card was pre-installed by AirLink, unless you need to set a custom

APN, there is nothing more you need to do, activation of your modem is complete.

1. Opening the Case

FIGURE 1. Redwing back

2. Ejecting the SIM tray

Redwing GPRS - User Guide, version 2.30 6

Activating the Redwing

b. Slide the tray out of the slot.

FIGURE 3. Empty SIM Tray

a. Place the SIM into the tray and gently press to click it into place.

FIGURE 4. SIM Tray with a SIM

b. Slide the tray back into the modem and gently press to click it into place.

a. Using the tip of a PDA stylus, an unbent paperclip, or other slim blunt item press the yellow

button of the SIM tray. On the Redwing, the button is on the bottom of the main board.

FIGURE 2. Tray button: Redwing

3. Inserting the SIM

The SIM may be a different color than this

example.

Note: The top of the card faces the the bottom of the modem.

Indice

Altri manuali Airlink101 Accessori di rete

Airlink101

Airlink101 Redwing CDMA Manuale utente

Manuali Accessori di rete popolari di altre marche

Valcom

Valcom VIP-804 Manuale utente

SKUTCH

SKUTCH BA-1000 Manuale del prodotto

QUNDIS

QUNDIS RNN5 Manuale utente

Asus

Asus AAEON FWS-2365 Manuale utente

Sophos

Sophos XG 85w Manuale utente

AMCI

AMCI RBE2-8 Manuale utente

Patton electronics

Patton electronics 2888 Manuale utente

Cradlepoint

Cradlepoint COR IBR1100/IBR1150 Manuale utente

Paradyne

Paradyne Hotwire 8620 Manuale utente

Infra Cool

Infra Cool F-1.3 Manuale utente

Edgewater Networks

Edgewater Networks 4300T Manuale utente

Edimax

Edimax SB-2200g Manuale utente

Extreme Networks

Extreme Networks Mogul-100 Manuale utente

Aaeon

Aaeon FWS-8500 Manuale utente

Panduit

Panduit Z11C Series Manuale utente

F5 BIG-IP 10000 Series Istruzioni di montaggio

ZyXEL Communications

ZyXEL Communications NMA1115 Manuale utente

Auerswald

Auerswald COMtrexx Business Manuale utente
