Airwell DAF009 Manuale utente

YIF series

Indoor Units Outdoor Units

DAF009 YIF009

DAF012 FAF012 CAF012 YIF012

DAF018 FAF018 CAF018 YIF018

DAF024 FAF024 CAF024 YIF024

DAF030 FAF030 CAF030 YIF030

YIF036

DAF036 FAF036 CAF036 YIF036T

DAF042 FAF042 CAF042 YIF042T

DAF060 YIF060T

REFRIGERANT

R410A HEAT PUMP

SM YIFSER 2-A.1 GB JAN - 2012

Version:2

LIST OF EFFECTIVE PAGES

A SM YIF 2-A.1 GB

LIST OF EFFECTIVE PAGES

Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page

(when none indicates no changes in the relevant page). All pages in the following list represent

effected/ non effected pages divided by chapters.

Dates of issue for original and changed pages are:

Total number of pages in this publication is 171 consisting of the following:

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Title........................... 1

A .............................. 1

i................................. 1

1-1 -1-4……………… 1

2-1 - 2-23……………. 2

3-1…………………….1

4-1 - 4-4…………….. 1

5-1-5-19………………1

6-1 -6-4……………….1

7-1 -7-13…………….. 2

8-1-8-2………………. 1

9-1- 9-12……………. 1

10-1-10-1……………. 1

11-1…………..............1

12-1 -12-6…………....1

13-1 - 13-3……………1

14-1- 14-49…………. 2

* Zero in this column indicates an original page.

TABLE OF CONTENTS

SM YIF 2-A.1 GB i

Table of Contents

1. INTRODUCTION............................................................................................................................. 1-1

2. PRODUCT DATA SHEET............................................................................................................... 2-1

3. RATING CONDITIONS................................................................................................................... 3-1

4. OUTLINE DIMENSION ................................................................................................................... 4-1

5. PERFORMANCE DATA................................................................................................................. 5-1

6. AIRFLOW CURVES........................................................................................................................ 6-1

7. SOUND LEVEL CHARACTERISTICS ........................................................................................... 7-1

8. ELECTRICAL DATA....................................................................................................................... 8-1

9. WIRING DIAGRAM......................................................................................................................... 9-1

10. REFRIGERATION DIAGRAMS...................................................................................................... 10-1

11. TUBING CONNECTIONS............................................................................................................... 11-1

12. CONTROL SYSTEM....................................................................................................................... 12-1

13. TROUBLESHOOTING.................................................................................................................... 13-1

14. EXPLODED VIEW & SPARE PART LIST...................................................................................... 14-1

15. APPEDDIX...................................................................................................................................... 15-1

INTRODUCTION

1. INTRODUCTION

1.1 General

The YIF series range comprises RC (heat pump) models. The whole range covers

nominal cooling capacity from 9kBtu/h to 60kBtu/h which matching following indoors, as

follows:

IDU:

Ducted(8 Models): DAF009 DAF012 DAF018 DAF024 DAF030 DAF036 DAF042

DAF060

Floor/Ceiling(4 Models): FAF012 FAF018 FAF024 FAF030 FAF036 FAF042

Cassette(6 Models): CAF012 CAF018 CAF024 CAF030 CAF036 CAF042

ODU:

1 Ph(6 Models): YIF009 YIF012 YIF018 YIF024 YIF030 YIF036

3 Ph(3 Models): YIF036 YIF042 YIF060

1.2 Main Features

The YIF series benefits from the most advanced technological innovations, namely:

•Auto mode

•Cooing/Heating/Dehumidification

•Sleep mode (from remote control)

•ON/OFF Timer

•Auto swing

•4-dimension swing (Cassette only)

•Energy saving

•Intelligent Deicing

•Memory from power failure

•Cold air prevention in heating

•Self diagnostic (Error indications) for ease of maintenance

SM YIF 2-A.1 GB 1-1

INTRODUCTION

1-2 SM YIF 2-A.1 GB

1.3 Indoor Unit

The indoor unit is calling mounted, and can be easily fitted to many types of residential

and commercials applications. It is major designed for light commercial air-conditioning

needs.

It includes:

•Coil with hydrophilic aluminum fins.

•Advanced electronic control box assembly

•Mounting plate

1.4 Filtration

The YIF series presents several types of air filters:

•Easily accessible, and re-usable pre-filters (mesh)

1.5 Control

The microprocessor indoor controller, and an infrared remote control, supplied as

standard, provide complete operating function and programming. For further details,

please refer to the Operation Manual, Appendix.

1.6 Outdoor Unit

The outdoor units can be installed as floor or wall mounted units by using a wall

supporting bracket. The metal sheets are protected by anti- corrosion paint work

allowing long life resistance. For further information, please refer to the Product Data

Sheet, Chapter 2.

It includes :

•Compressor mounted in a soundproofed compartment :

•Axial fan.

•Outdoor coil with hydrophilic louver fins for RC units.

•Outlet air fan grill.

•Interconnecting wiring terminal block.

1.7 Tubing Connections

Flare type interconnecting tubing to be produced on site.

For further details, please refer to the Installation Manual, Chapter 10.

INTRODUCTION

SM YIF 2-A.1 GB 1-3

1.8 Accessories

RCW Wall Mounted Remote Control

The RCW remote control is mounted on the wall, and controls the unit either as an

infrared remote control or as a wired controller.

The wired remote control with larger LCD display provides the following functions

•Interconnecting wiring terminal block.

•On/OFF unit

•Choose the operating mode (Heating-Cooling-Dehumidification-Fan or

Automatic mode),

•Increase or decrease the setting temperature.

•Adjust the fan speeds (Auto/High/Medium/Low)

•Setting ON-OFF timer within 0.5hr-24hrs

•Air exchange (Fresh air) settings

•Sleep mode saves energy by preventing overcooling or overheating during night

time

•Energy saving function

•Technician functions

- Display of Outdoor Ambient Temperature

- Power-fail Memory Function Setting

- Setting of Ambient Temp. Sensor

- Setting of Fan Speed

- Failure Display

For further details, please refer to the Technical Service Manual.

1.9 Inbox Documentation

Each unit is supplied with its own installation, operation and remote control manuals.

INTRODUCTION

1-4 SM YIF 2-A.1 GB

1.10 Matching Table

INDOOR UNITS

OUTDOOR

UNITS DAF009

DAF012

CAF012

FAF012

DAF018

CAF018

FAF018

DAF024

CAF024

FAF024

DAF030

CAF030

FAF030

DAF036

CAF036

FAF036

DAF042

CAF042

FAF042

DAF060

YIF009 √

YIF012 √

YIF018 √

YIF024 √

YIF030 √

YIF036 √

YIF036T √

YIF042T √

YIF060T √

PRODUCT DATASHEET

2. PRODUCT DATA SHEET

2.1 DAF009 / YIF009

R410

PRELIMINARY PRODUCT DATA SHEET

Model Indoor Unit

DAF0

Model Outdoor Unit YIF009

Installation Method of Pi

e ducted

Characteristics Units Coolin

Heatin

Btu/h

8870 9720

Capacity (4) kW 2.6 2.85

Power in

(

)

kW 1.00 0.97

EER

(

Coolin

or COP

(

Heatin

(

)

W/W 2.6 2.93

Ener

efficienc

class

Power su

V/Ph/Hz 220-240V/Sin

le/50Hz

Rated current A 4.5 4.3

Startin

current A

Circuit breaker ratin

(

IDU/ODU

)

A 6/10

Fan t

e &

uantit

Centrifu

al x 2

Fan s

eeds H/M/L RPM 830/640/550

Air flow

(

)

H/M/L m3/h

550/470/400

External static

ressure Min-Max Pa 25

(

0~25

)

Sound

ower level

(

)

H/M/L dB

(

)

47/46/44

Sound

ressure level

(

)

H/M/L dB

(

)

37/36/34

Moisture removal l/h

Condenstate drain tube I.D mm 20

Dimensions WxHxD mm 913x220x680

Wei

ht k

Packa

e dimensions WxHxD mm 995x258x750

Packa

ed wei

ht k

Units

allet units

INDOOR

Stackin

hei

ht units

Refri

erant control Ca

illar

Com

ressor t

e, model Rotar

Fan t

e &

uantit

Pro

eller

(

direct

)

x 1

Fan s

eeds H/L RPM 850

Air flow H/L m3/h

2800

Sound

ower level H/L dB

(

)

Sound

ressure level

(

)

H/L dB

(

)

Dimensions WxHxD mm 848x540x320

Wei

ht k

Packa

e dimensions WxHxD mm 878x590x360

Packa

ed wei

ht k

Units

allet Units

Stackin

hei

ht units

Refri

erant t

e R410A

Refri

erant char

eless distance k

/m 1.1/5

Additional char

er 1 mete

/m 30

uid line In.

(

)

1/4"

(

6.35

)

Suction line In.

(

)

3/8"

(

9.53

)

Max.tubin

len

th m. Max.20

OUTDOOR

Connections between units

Max.hei

ht m. Max.15

eration control t

e Remote control

Heatin

elements

(

tion

)

Others

(1)Airflow in ducted uni

ts; at nominal external static pressure.

(2)Sound power in ducted units is measured at air discharge.

(3)Sound pressure level measured at 1-meter distance from unit.

(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).

SM YIF 2-A.1 GB 2-1

PRODUCT DATASHEET

2-2 SM YIF 2-A.1 GB

2.2 DAF012 / YIF012

R410

PRELIMINARY PRODUCT DATA SHEET

Model Indoor Unit DAF012

Model Outdoor Unit YIF012

Installation Method of Pipe ducted

Characteristics Units Cooling Heating

Btu/hr 11940 12280

Capacity (4) kW 3.5 3.6

Power input (4) kW 1.2 1.1

EER (Cooling) or COP(Heating) (4) W/W 2.91 3.27

Energy efficiency class

Power supply V/Ph/Hz 220-240V/Single/50Hz

Rated current A 5.4 4.9

Starting current A

Circuit breaker rating (IDU/ODU) A 6/13

Fan type & quantity Centrifugal x 2

Fan speeds H/M/L RPM 1110/910/760

Air flow (1) H/M/L m3/hr 600/540/490

External static pressure Min-Max Pa 25(0~25)

Sound power level (2) H/M/L dB(A) 50/48/46

Sound pressure level(3) H/M/L dB(A) 40/38/36

Moisture removal l/hr 1.3

Condenstate drain tube I.D mm 20

Dimensions WxHxD mm 913x220x680

Weight kg 27

Package dimensions WxHxD mm 995x258x750

Packaged weight kg 32

Units per pallet units

INDOOR

Stacking height units

Refrigerant control Capillary

Compressor type, model Rotary

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 900

Air flow H/L m3/hr 2800

Sound power level H/L dB(A) 66

Sound pressure level(3) H/L dB(A) 56

Dimensions WxHxD mm 848x540x320

Weight kg 32

Package dimensions WxHxD mm 878x590x360

Packaged weight kg 37

Units per pallet Units

Stacking height units

Refrigerant type R410A

Refrigerant chargeless distance kg/m 1.0/5

Additional charge per 1 meter g/m 30g/m

Liquid line In.(mm) 1/4"(6.35)

Suction line In.(mm) 1/2"(12.7)

Max.tubing length m. Max.20

OUTDOOR

Connections between units

Max.height difference m. Max.15

Operation control type Remote control

Heating elements (Option) kW

Others

(

)

Airflow in ducted units

;

at nominal external static

ressure.

(2)Sound power in ducted units is measured at air discharge.

(3)Sound pressure level measured at 1-meter distance from unit.

(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Airwell Pompa di calore

Airwell

Airwell Wellea Mono Manuale utente

Airwell

Airwell XDA Manuale utente

Airwell

Airwell FLO 9 DC INV Manuale utente

Airwell

Airwell AWSI-DED076-N11 Manuale utente

Airwell

Airwell HRW 019 Manuale

Airwell

Airwell Aqu@Scop HT SPLIT 12-6 Manuale utente

Airwell

Airwell PNX 30 DCI Manuale utente

Airwell

Airwell GC 30 DCI Manuale utente

Airwell

Airwell AWSI YIFA060-H13 Manuale utente

Airwell

Airwell Monobloc R32 Manuale utente

Airwell

Airwell WELLEA SPLIT AW-WHPST0410-N91 Istruzioni per l'installazione

Airwell

Airwell Monobloc R32 Istruzioni per l'installazione

Airwell

Airwell Aqu@Scop ADV 006 Guida di riferimento

Airwell

Airwell WELLEA MONO SPLIT A R32 Manuale utente

Airwell

Airwell SX 12 RCC Manuale utente

Airwell

Airwell ODMA-100T-09M22-19 Manuale utente

Airwell

Airwell KXL DCI Series Manuale utente

Airwell

Airwell LWM8-1P Manuale utente

Airwell

Airwell AW-XDO009-H11 Manuale utente

Airwell

Airwell AQL20-75 Manuale

Airwell

Airwell DLS 18 Manuale utente

Airwell

Airwell AWAU-YBDE012-H11 Manuale utente

Airwell

Airwell PAC HT Series Manuale utente

Airwell

Airwell Aqu@Scop Advance R410A Manuale utente

Manuali Pompa di calore popolari di altre marche

MICROWELL

MICROWELL HP 1000 GREEN Manuale utente

Sanyo

Sanyo SAP120FCH Manuale utente

Daikin

Daikin EHYHBH05AA Manuale utente

Panasonic

Panasonic WH-SDF03E3E5 Guida

Bryant

Bryant 544B Manuale utente

Airxcel

Airxcel 45000 Series Manuale

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuale utente

Dimplex

Dimplex LI 16I-TUR Guida utente

Carrier

Carrier WSHP Open v3 Guida rapida alla configurazione

TGM

TGM CTV14CN018A Manuale utente

Carrier

Carrier 38MGQ Series Manuale utente

Kokido

Kokido K2O K880BX/EU Guida alla risoluzione dei problemi

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guida rapida

Carrier

Carrier 48EZN Manuale utente

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Istruzioni operative

Ariston

Ariston NIMBUS Manuale utente

Weishaupt

Weishaupt WWP L 7 Guida utente

GE Zoneline AZ85H09EAC Manuale utente
