Aiwa MI-X420 Manuale utente
User Manual
MI-X420
Aiwa Electronics Int’l Co., Ltd.
Explore more at www.int-aiwa.com
- MI-X420 Speaker
- Remote Control
- Microphone
- DC15V 1.6A Charger
- 3.5mm Audio Cable
- Apple Audio Cable
- Android Audio Cable
- User’s Manual
Please refrain from using any damaged components.
Contact your local authorized AIWA distributor/customer service
should you need any assistance.
Unboxing
1/12
Model Number: MI-X420
BT Version: V5.0
IP Rating: -
RMS Output: 100W
Frequency Response: 50~15kHz
S/N Ratio: ≥ 70dB
Distortion THD: ≤ 10%
Sensitivity: 95dB + 3dB
Supports: TF Card, USB,
Supported Profiles: MP3, WAV, APE, FLAC, WMA
Transmission Distance (Estimated): 10 Meters (No Obstacles)
Battery Capacity: 18000mAh
Playback Time: 3 – 8 Hours (Depends on Volume)
Charging Time: 3-4 Hours
The above are estimated values tested in a practical environment and may
vary upon individual usage habits.
Product Specifications
2/12
Product Overview
Charging Port
USB Slot
312
Product Overview
4/12
Product Overview
Live Broadcast Function Effect
Live Broadcast Function Effect
Record (Record only when USB/TF
Card is inserted)
Keypad (Number 0-9)
For double-digit numbers, press both
numbers at the same time for two (2)
seconds. (For e.g, pressing 1 & 0
together will give you 10)
5/12
Product Overview
Microphone
LED Indicator Light
Display Screen: Displays battery level & Current
Frequency
Power Button: Long press to Power ON/OFF, Short
press to toggle between LED Lighting effects
(Blinking, Constant Illumination)
Pairing Button: Click button after turning the
microphone ON to enter pairing mode (The
Microphone’s display screen will start flashing). Turn
speaker ON now to commence pairing. Click button
to exit pairing mode.
Transmission Antenna (Please refrain from holding
this area during usage)
6/12
Product Usage Guide
Power ON/OFF:
Long press power button
Music Control:
Play/Pause: Click once (1)
Next Song: Click once (1)
Previous Song: Click once (1)
Assorted Functions:
Record: Insert TF card/ USB into the designated port. Please make sure
Microphone is connected. Short press the record button to start/stop
recording. (Supports recording accompaniment soundtrack + Microphone
input)
Play Recorded Tracks: Long press
Delete Recorded Files: Long press during selected music playback.
(Deletes current music playback from recorded files)
Change Playback Mode: Short press power button to switch between
BT/AUX/USB/TF card playback
AUX Playback Mode: Insert AUX cable and connect it to audio source to start.
TF Card Playback Mode: Insert TF card into TF port.
Sound field switch: Click to cycle between Original-Professional-Popu-
lar-Echo sound field profile.
Microphone Delay: Works with all sound field modes except original mode.
Microphone Echo: Works with all sound field modes except original mode.
7/12
Tone +/-: Short press Tone +/- button once. Short press on Tone+ or Tone- to
adjust tone accordingly.
Mic Inflexion: Short press Tone+ or Tone – button to adjust Mic Inflexion
accordingly.
Special Effects: Users can play special effects through the remote control.
Microphone Priority: Press the mic priority button on the remote control
first.
Accompaniment: Press the accompany button on the remote control/
Accompany button on the speaker.
EQ: Short press mode button on the speaker/ Long press mode button on
the remote control to cycle between various EQ modes.
Monitor/Earphone Function: Simple plug in your earphones/headphones
into the monitor port. The speaker will now be muted. Long press the sound
field button to un-mute speaker. (Playback will commence in both speaker
and earphones/headphones.
Perform Factory Reset:
Insert needle into reset button until the speaker powers down.
8/12
Connecting the Product
Paired device
Pairable devices
MI-X420
MI-X420
ON/OFF ON/OFF
Paired device
Pairable devices
1. Turn on Bluetooth (BT) on your mobile device.
2. Turn on the speaker.
3. Search and connect to “MI-X420” from your mobile device
9/12
