Akiyama Deck2 Manuale utente

USER MANUAL

MANUAL DE USUARIO

PROFESSIONAL MULTI-

MEDIA DJ PLAYER

DECK2

1. Read Instructions. All the safety and operating instructions

should be read before this product is operated.

2. Retain Instructions. The safety and operating instructions should

be retained for future reference.

3. Heed Warnings. All warnings on the appliance and in the

operating instructions should be adhered to.

4. Follow Instructions. All operating and use instructions should

be followed.

5. Water and Moisture. The appliance should not be used near

water - for example, near a bathtub, washbowl, kitchen sink,

laundry tub, in a wet basement, or near a swimming pool, and

the like.

6. Carts and Stands . The appliance should be used

only with a cart or stand that is recommended

by the manufacturer. An appliance and cart

combination should be moved with care. Quick

stops, excessive force, and uneven surfaces

may cause the appliance and cart combination

to overturn.

7. Wall or Ceiling Mounting. The product should be mounted to a

wall or ceiling only as recommended by the manufacturer.

8. Heat. The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

9. Power Sources. This product should be operated only from the

type of power source indicated on the rating label. If you are

not sure of the type of power supply to your home, consult your

product dealer or local power company. For products intended

to operate from battery power, or other sources, refer the

operating instructions.

10. Grounding or Polarization. This product may be equipped with

a polarized alternation-current line plug (a plug having one

blade wider than the other). This plug will fit into the power

outlet only one way. This is a safety feature. If you are unable

to insert the plug fully into the outlet, try reversing the plug. If

the plug should still fail to fit, contact your electrician to

replace your obsolete outlet. Do not defeat the safety purpose

of the polarized plug.

11. Power. Cord Protection. Power-supply cords should be routed

so that they are not likely to be walked on or pinched by items

placed upon or against them, paying particular attention to the

cord in correspondence of plugs, convenience receptacles, and

the point where they exit from the appliance.

12. Cleaning. The appliance should be cleaned only as

recommended by the manufacturer. Clean by wiping with a

cloth slightly damp with water. Avoid getting water inside the

appliance.

13. For AC line powered units - Before returning repaired unit to

user, use an ohm-meter to measure from both AC plug blades

to all exposed metallic parts. The resistance should be more

than 100,000 ohms.

14. Non-use Periods. The power cord of the appliance should be unplugged

from the outlet when left unused for a long period of time.

15. Object and Liquid Entry. Care should be taken so that objects do not fall

and liquids are not spilled into the enclosure through openings.

16. Damage Requiring Service. The appliance should be serviced by

qualified service personnel when:

A: The power-supply cord or the plug has been damaged; or

B: Objects have fallen, or liquid has been spilled into the appliance; or

C: The appliance has been exposed to rain; or

D:The appliance does not appear to operate normally or exhibits a

marked change in performance; or

E: The appliance has been dropped, or the enclosure damaged.

17. Servicing. The user should not attempt any service to the appliance

beyond that described in the operating instructions. All other

servicing should be referred to qualified service personnel.

18. Ventilation Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the product and to

protect it from overheating, and these openings must not be blocked or

covered. The openings should never be blocked by placing the

product on a bed, sofa, rug, or other similar surface. This product

should not be placed in a built-in installation such as a bookcase or

rack unless proper ventilation is the manufacturer's instructions have

been adhered to.

19. Attachments do not use attachments not recommended by the product

manufacturer as they may cause hazards.

20. Accessories Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing serious injury

to a child or adult, and serious damage to the product. Use only with a

cart, stand, tripod, bracket, or table recommended by the

manufacturer, or sold with the product. Any mounting of the product

should follow the manufacturer's instructions, and should use a

mounting accessory recommended by the manufacturer.

21. Lightning For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet and disconnect the antenna or

cable system. This will prevent damage to the product due to lightning

and power-line surges.

22. Replacement Parts When replacement parts are required, be sure the

service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

23. Safety Check Upon completion of any service or repairs to this

product, ask the service technician to perform safety checks to

determine that the product is in proper operating condition.

This device is equipped with Class 1 laser

diodes. To ensure a safe operation do not

remove any covers or try to access the

inside of the equipment. The inside of the

device does not contain any parts which

are subject to maintenance. Maintenance

must only be carried out by qualified staff.

CAUTION LASER RADIATION!

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock, do not remove any cover. No user-serviceable

parts inside. Refer servicing to qualified service personnel only.

The lightning flash with arrowhead symbol within the equilateral

triangle is intended to alert the use to the presence of un-insulated

“dangerous voltage” within

The exclamation point within the equilateral triangle is intended to

alert the user to the presence of important operation and maintenance

(servicing) instructions in the literature accompanying this

appliance.

TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET

UNLESS THE BLADES CAN BE FULLYINSERTED TO PRESENTBLADE TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSETHIS

APPLIANCE TO RAIN OR MOISTURE. TO PRVENT ELECTRICALSHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT FULLYINSERT.

WARNING

ENGLISH

DECK2

MAIN FEATURES

NOTE ON USAGE

Allow for sufficient heat dispersion when installed on a rack.

- Handle the power cord carefully.

- Hold the plug when unplugging the cord.

- Keep the appliance free from moisture, water, and dust.

- Unplug the power cord when not using the appliance for long periods of time.

- Do not obstruct the ventilation holes. (For units with ventilation holes)

- Do not drop foreign objects into the unit.

- Do not let insecticides, benzene, and thinner come in contact with the set.

- Never disassemble or modify the set in any way.

COMPACT DISC

1. Precautions on handling compact discs

-Do not allow fingerprints, oil or dust to get on the surface of the disc.

- If the disc is dirty, wipe it off with a soft dry cloth.

-Do not use benzene, thinner, water, record spray, electrostatic-proof

chemicals, or silicone-treated cloths to clean discs.

-Always handle discs carefully to prevent damaging the surface; in

particular when removing a disc from its case or returning it.

-Do not bend the disc.

-Do not apply heat.

-Do not enlarge the hole in the center of the disc.

-Do not write on the label (printed side) with a hard-tipped implement

such as a pencil or ball point pen.

-Condensation will form if a disc is brought into a warm area from a

colder one, such as outdoors in winter.

-Do not attempt to dry the disc with a hair dryer, etc..

2. Precaution on storage

-After playing a disc, always unload it from the player.

-Always store the disc in the jewel case to protect from dirt or

damage.

- Do not place discs in the following areas:

(1)Areas exposed to directs sunlight for a considerable time.

(2)Areas subject to accumulation of dust or high humidity.

(3)Areas are affected by heat from indoor heaters, etc..

PREPARATIONS

Check that the carton contains the following items:

(1) Main Unit 1pc

(2) Controller Unit 1pc

(3) Operating Instructions 1pc

(4) 8P cable right angle 1pc

(5) 2P RCApath cord (L/R) 2pc

(6) Auto-Start cable 2pc

(7) AC power cord 1pc

(8) DB Builder CDRoom 1pc

Installing the Units

(1)Place your unit on a flat surface or mount it in a secure rack mount

case.

(2)Be sure the unit is mounted in a well-ventilated area where it will not

be exposed to direct sunlight, high temperatures, or high humidity.

(3)Try to place the unit as far as possible from TVs and tuners, as the unit

may cause undesirable interference.

CAUTION:

- The unit will work normally when the unit is mounted with the front

panel at within 15 degrees of the vertical plane. If the unit is tilted

excessively,discsmay notbeloaded orunloadedproperly.

- The unit's LCD is designed to be clearly visible within the angles.

Mountthe unitso thatthe visual angleiswithin thisrange.

CONNECTIONS:

(1) Turn off the POWER switch

(2) Connect the RCApath cord to the input on your mixer.

CAUTION:

- Be sure to use the supplied cables. Otherwise the unit may not work

properly.

- Be sure the power is off when connecting the control cords. Otherwise

it may result in damage.

- Auto Cue.

- MP3 Playback.

- Single / Continuous Playback.

- Anti-shock Playback.

- Fader Start Playback.

- Switching power supply.

- Pitch range: +/-4%, +/-8%, +/-16% and 100% (CDDA).

-Selectableelapsed,remainandtotalremaintimedisplay.

- Relay play allow consecutive playback during two decks.

- Frame Search.

- Seamless Loop.

- 4 fast search mode.

- Transport protection.

- +10 Track skip search

- Pitch Control & Pitch Display.

CDDA* Compact Disc Digital Audio

DECK2

GENERAL FUNCTIONS MAIN UNIT

1. DISC TRAY. This tray is used to load and unload a compact disc into the drive mechanism. The tray is opened and closed by pressing the OPEN/CLOSE

BUTTON. Never attempt to force the disc tray open or close when the power is turned off.

2. OPEN/CLOSE BUTTON (Transport Tray Open/ Close).

This button is used to open and close the disc tray. NOTE: When a disc is loaded, the tray will not open unless the unit is in pause or cue mode.

3. USB 1 PORT.This is the USB 1 port where you insert your USB mass storage device for playing MP3 files.

4. POWER SWITCH.This switch is used to control the unit's main power.ALED directly above the power switch will glow to indicate main power is on.

5. POWER CONNECTOR.This is the main power connection. Only use the supplied power cord. Use of any other power may result in severe damages to

the unit.

6. USB 2 PORT.This is the USB 2 port where you insert your USB mass storage device for playing MP3 files.

7. CONTROLCONNECTOR.Connect this connector to the control unit using the supplied mini-DIN8 cable.

8. AUDIO OUT R & L.These jacks send a left and right analog mono output signal. Use these jacks to send standard audio to a mixer or receiver. The red

colored jack represents the right channel output and white jack represents the left channels output.

GENERAL FUNCTIONS CONTROL UNIT

1. DISC TRAY OPEN/CLOSE BUTTON. This button is used to open and close the disc tray.

NOTE: When a disc is loaded, the tray will not open unless the unit is in pause or cue mode.

2. SOURCE SELECT BUTTON. This button lets you toggle between CD tray and USB Ports which music source device will play. The LEDs will

verify which source is activated. The function can only be selected under pause mode.

3. TIME BUTTON. The TIME button will switch the time value described in the time meter between track elapsed playing time, track remaining time,

and total remaining time of entire CD disc.

1234

567

1234 5 6 7

891018 17 16 15 14 13 12 11

1920

ENGLISH

DECK2

GENERAL FUNCTIONS CONTROL UNIT

4. LCD DISPLAY. This high quality LCD display indicates all the functions, as they are occurring. This display is viewable at several comfortable

angles.

5. PITCH SLIDER. This slider is used to adjust the playback pitch percentage when the PITCH function is activated. The slider is a set adjustment and

will remain set until the pitch slider is moved or the PITCH function has been turned off. The maximum pitch range of the slider is +/-100%. This

adjustment can be made with or without a music source device (USB stick or CD) in the player.

6. SGL/CTN BUTTON. This button allows the play mode to change between Single and Continuous. In single mode the unit will play a single track and

return to cue mode. In continuous mode the unit continues to play track by track.

7. TAP BPM BUTTON. This button is used to override and manually set a track BPM. Occasionally the built-in BPM meter may not function as desired.

To manually set the BPMs; tap this button a few times to a tracks heavy down beat, the unit will automatically calculate your tapping and translate it into

a tracks BPMs. The BPM READOUTis then displayed in the LCD.

You can also hold the TAPBPM button, turn the TRACK knob to adjust BPM value, hold down and turn track knob to adjust the decimal BPM value.

To return to the automatic BPM counter, hold down the TAPBUTTON at least 2 seconds and then release.The default setting isAUTO BPM.

8. PITCH BEND BUTTONS. The speed rises while the “+button” is pressed and returns to the original pitch when the button is released. The speed drops

when the “-button” is pressed and returns to the original pitch when the button is released. These buttons can be used to synchronize the beats of 2

tracks.

9. PITCH PERCENTAGE BUTTON. Hold this button down at least 2 seconds to turn the pitch slider function on and off.When the function is active the

corresponding LED “PITCH ON” glows. Press this button to choose any pitch range percentages of 4%, 8%, 16%, and 100%. When the pitch range of

+/-100 %(CDDAonly) is selected, the 4%, 8% and 16% LEDs will be illuminated.

The default setting is 8%.

10. TRACK KNOB. Use this knob to select track or folder, depending on these two different modes as below.

- In TRACK mode, use to select a track. Turning track knob will navigate between tracks. Holding down and turning track knob will rapidly forward /

backward skip through the tracks by 10 tracks per click.

You can also switch between displaying File Name/Title/Artist/Album/Genre for easy searching by each pressing the Track knob you want to keep.

- In FOLDER mode, turning track knob will forward /backward skip between folders. Holding down and turning track knob will rapidly forward / back

skip through the folders by 10 folders per click.

11. SEAMLESS LOOP BUTTONS.

- LOOPIN BUTTON This function allows you to set the starting point of a loop.

-LOOP OUT BUTTON This button is used to set the ending point of a loop. A loop is started by pressing the IN BUTTON, pressing the OUT

BUTTON sets the loop ending point.The loop will continue to play until the OUT BUTTON is pressed once again.

- RELOOP BUTTON If a LOOP has been made, but the Player is not active in LOOP mode (a loop is not playing), pressing the RELOOP BUTTON

will instantly reactivate the LOOP mode. To exit the loop, press the LOOP OUT BUTTON. You can also tap the RELOOP button to create a

STUTTER EFFECT.

- IN/OUT POINTEDIT

In the LOOP mode, hold RELOOP button, LED of OUT will flash and display will show the loop-out point time, now you can turn the jog wheel to

edit OUT point. Then press the OUT button to exit editing; or press the RELOOPbutton again, LED of IN will flash and “IN EDIT” will be indicated

on the LCD, now you can turn the jog wheel to edit IN point. Then press the IN button to exit editing.

Note:

12. RELAY BUTTON. Set both sides of the player to single mode and switch the Relay function on, alternately a track will be played from both players

until the relay function is deactivated. You can always put a new music source in the device that is waiting in standby mode. In this way you can create

an endless program. Perfect for use in pubs etc.

13. KEYLOCK BUTTON. This button is used to choose the key lock mode and the pitch control mode. Key lock mode allows speeding up or slow down

playback speed without altering the tonality of music.

14. SEARCH BUTTON.

SEARCH BUTTON. This search button allow you to quickly scan backward through a track.

SEARCH BUTTON. This search button allow you to quickly scan forward through a track.

You will scan forward or reverse at 4 different speeds depending on how long you hold these buttons down.

15. FOLDER BUTTON. Use to switch between FOLDER and TRACK search modes. When the LED of FOLDER button is lit, the player is in the

FOLDER search mode, otherwise it is in TRACK search mode. **File name is the first display when select a track; and Folder name is the first display

when select a folder.

Hold FOLDER button down at least 2 second to activate and to deactivate REPEATfunction.

REPEAT on:All the tracks in the current folder will play track by track until the repeat function is inactive.

REPEAT off: All the tracks in the music source device will play in the normal mode.

Note:

End Loop Edition:

Loop Mode (RELOOP ON)

HOLD

Blinks

End Loop time

Select new Loop End point

PRESS

Or..

Exit Edit Mode

Beginning Loop Edition:

(RELOOP OFF)

HOLD

Blinks

IN EDIT

Select new Loop Start point

PRESS

3Exit Edit Mode

ENGLISH

GENERAL FUNCTIONS CONTROL UNIT

DECK2

16. PLAY/PAUSE BUTTON. Each press of the PLAY/PAUSE BUTTON causes the operation to change from play to pause or from pause to play. While

in play mode the play LED will glow, and while in pause mode the play LED will flash.

17. CUE BUTTON. Pressing the CUE button during playback immediately pause playback and return the track to the last set cue point. The CUE BUTTON

LED will glow when the unit is in cue mode. The LED will also flash every time a new CUE POINT is set. The CUE button can also be held down to

momentarily play the music. When you release the CUE button it instantly returns to the last set CUE POINT. You can also tap the CUE button to create a

STUTTER EFFECT.

18. JOG MODE BUTTONS. The jog wheel has 2 effect functions as below:

VINYLMODE When wheel mode is set to VINYL, use the JOG WHEELto activate the scratch effect by touching the surface of Jog Wheel.

CDJ MODE When wheel mode is set to CDJ, scratch mode is exit, JOG WHEEL can be used to pitch bend during playback and be used to frame

search in pause mode.

19. CONTROLSTART SOCKET. These sockets are to connect to a mixer using a 3.5mm jack plug to give remote start capability.

20. CONTROLCONNECTOR. Connect this connector to the main unit using the supplied mini-DIN8 cable.

GENERAL FUNCTIONS LCD DISPLAY

1. CUE INDICATOR. This indicator will glow when the device is in CUE mode and will flash every time a new CUE POINT is set.

2. FOLDER INDICATOR. Indicates the number of the currently playing folder.

3. TIME BAR INDICATOR. Shows either time remaining or elapsed depending on the setting of the TIME BUTTON.This bar will begin to flash shortly

before the end of a track. The flashing bar is a great visual reminder a track is about to end regardless of which time mode the unit is.

4. BPM STATUS. This will indicate that theAUTO BPM counter is active.

5. BPM METER. Indicates the BPM value of the currently playing track.

6. PITCH METER. Indicates the percentage of a track's pitch.

7. KEYLOCK SYMBOL. Indicates if the key lock is activated (lock symbol).

8. LOOPINDICATOR. Indicates if LOOPfunction is activated.

9. RELOOPINDICATOR. Indicates that the LOOPis ready to be played again..

10.AUTO CUE STATUS. The indicator will flash when a LOOP is played and the indicator will disappear when a LOOPis inactivated.

11.KEY INDICATOR. Indicates when the touch sensitive wheel can be used to control playback or scratch effects.

12.TIME DISPLAY. Indicates the time of the chosen Time mode in minutes, seconds and frames.

13.MP3 INFORMATION INDICATOR. Indicates the current name of the track, of the folder and the sampling rate.

14.TIME MODE. Indicates the elapsed time of a track ("ELAPSED"), the remaining time of a track ("REMAIN") or the remaining time of entire

disc(TOTALREMAIN). Change between these modes with the Time button.

15.REPEAT INDICATOR. Indicates whether the unit is in repeated play mode.

16.SINGLE INDICATOR. Indicates whether the play mode is set to single ("SINGLE") or continuous mode (no display).

17.TRACK INDICATOR. Indicates the number of the currently playing track.

18.PLAY/PAUSE INDICATOR. Indicates the device is in play mode ("►"), or the player is in pause mode (" ").׀׀

INTERNAL MENU

Hold TIME BUTTON for 3 seconds to enter the internal menu.

Turn TRACK KNOB to scroll through the different menus and press theTRACK KNOB to enter the corresponding submenu.

Turn TRACK KNOB to change the submenus and press TIME BUTTON to memorize your settings in any operating mode and exit the menu.

1. Playlist Normal /Title/Artist /Album/ Genre

2. Sensitivity Touch Wheel SensitivityAdjustment (Adjustment range is -20~+20.)

3. Sleep Time No sleep, 5~120 min

1 2 318 17

16 15 13 10

567

12 11

ENGLISH

INTERNAL MENU

DECK2

4. Line Setup Determines how the information will be depicted at display.

- MODE= 1-3 (there are 3 different modes for text)

- Mode1 = text “runs” to the left and stops for a time (user selectable) before start moving again. This loop is played continuously.

- Mode 2 = text “runs” to the left once and stops

- Mode 3 = text “runs” to the left continuously

- Dis: being in Mode 1,2 or 3, turn the wheel. At display we will read “DIS”; sets the time that the text will remain fixed. Turn TRACK control to

select time. Time range for selection is 0.5~12.0 seconds.

- Run: being in Mode 1,2 or 3, turn the wheel. At display we will read “RUN”; sets the speed the text will scroll through the line. Turn TRACK

control to select speed from a range of 50~2000 milliseconds

5. Bit rate Display ON/OFF

6. Version CON:XX (Control version)

DSP:XX (DSPversion)

SER:XX (Servo version)

7. Load Default Press TRACK Knob to enter load defaults. (LCD displays “Load OK”.)

8. Exit & Save Exit & Save setting to next power on (LCD displays “Saving”.)

Press the TRACK knob to fast exit & save in any operating mode.

- SLEEPTIME: The CD player automatically shuts off the transport and laser after about 15 minutes when in pause or cue mode). This extends the life

of your motor drive and laser. During sleep mode the display shows the word “SLEEP”. To wake up the player, just press the cue or play button, the

display turns to normal and is ready to receive instructions.You can enter the Sleep Time menu to adjust sleep time, range is 5~120 minutes.

- SAVE: PITCH ON/OFF, PITCH RANGE, SGL/CTN, AUTO CUE, TIME MODE, KEY LOCK, SENSITIVITY, DISPLAY/SCROLL TIME/JOG

MODE.

-DEFAULTS: PITCH (ON), PITCH RANGE (8%), PLAY MODE(CTN), AUTO CUE(ON), TIME MODE (REMAIN), KEY LOCK(OFF),

SENSITIVITY(0), BIT RATE(Disp. ON), REPEAT MODE (OFF), PLAYLIST (NORMAL), SLEEP TIME (15 min), LINE SETUP(model 1),

DISPLAY(1 sec),RUN TIME(150msec)

NOTE:

DATABASE BUILDER

Minimum Hardware Requirements:

CPU: Intel Pentium 4, 1GHz processor or above, Intel Centrino Mobile Technology 1.6GHz

RAM: 512MB RAM

DISK SPACE: 100MB of free disk space need

OS: Microsoft Windows XPSP3, Vista SP2

The unit includes a database management software enables you to search for your files by Title,Artist,Album, and Genre.

- Installation:

Refer to the following figures for installing database management software on your computer.

For Windows

STEP1: click Next > STEP2: click Next > STEP3: click Install

In a programmed time lapse the text runs to the left

DIS; sets the time the text remains still

RUN; set the speed of the text movement

Text line

ENGLISH

DECK2

DATABASE BUILDER For Windows

The database builder will scan your USB hard drive and create database files to locate the files in your music library in your favor.

- Scan and Create:

Refer to the following figures to process scanning and creating database.

NOTE:

Please re-create the database builder whenever you change the contents of your USB device.

The root cause for customer failed to run DB builder in Windows

1. User will fail to run db builder in Windows because the UAC limitation.

ENGLISH

STEP4: processing STEP5: click Finish

STEP 1: select the desired USB hard drive and

click Build.

STEP2: processing STEP3: complete

2. User should press the right button of mouse to run

the db builder with the option of Run as

administrator.

3. Allow the DB builder to run.

BUILD DATABASE For Windows

DECK2

PLAYLIST OPERATION

1. Hold the TIME button down for 3 seconds to enter the internal menu and turnTRACK knob to search PLAYLIST.

2. Turn the Track knob to select “Normal/ Title/ Artist/Album/ Genre” (for USB only). And press the Time button again to memorize your setting and exit

the menu.

Use FOLDER button to switch to Folder mode.

Ex: to select “Artist”

(a). Hold and turn the TRACK knob or hold the TRACK knob and turn outer Jog wheel, you can select the folder you like by first letter ofArtist,

and theArtist alphabet is arranged in order (A, B, C….in order)

(b).Turn the TRACK knob; or hold the TRACK knob and turn inner Jog wheel to select next “Artist”.

Use FOLDER button to switch to Track mode.

Turn the TRACK knob; or hold the TRACK knob and turn Jog wheel to select the track you like.

Example:

We will show with draws the selection method for selecting tracks once they are processed by DB Builder software. We will show it with a practical

Example:

Searched track >Artist: PROPELLERHEADS Album: DECK&DRUMS&ROCK&ROLLTitle (track): SPYBREAK in mode “Playlist/Artist” and

“Playlist/Album”.

First we select “Artist” as search mode.At the draw we depict the steps

to perform this search.

At the text line appears the artist that begins with the first character

on alphabet order.

The search can be done two ways: Aor B

A. 1. PRESS FOLDER > We enter Folder mode. 2. PRESS and TURN

TRACK > we scroll through the Folders alphabetically sorted by

“Artist”. Or…

B. 1. PRESS FOLDER > We enter Folder mode. 2. Hold TRACK and

turn outer wheel. We scroll through the Folders alphabetically sorted

by “Artist”.

ARTIST>

2ARTIST>

Once we find the artist name (PROPELLERHEADS) press FOLDER

buton to select Track Mode. The FOLDER LED is off.

(1).TURN TRACK > we scroll through the Tracks alphabetically

sorted belonging to the selected “Artist” until we find the Track

(SPYBREAK).

(2).Hold TRACK and turn wheel. we scroll through the Tracks

alphabetically sorted.

TITLE>

2- Search in mode Playlist > “Album”:

First we select “Album” as searching mode. At the draw we depict the

steps to perform this search.

At the text line appears theAlbum that begins with the first on

alphabet order.

character

Internal Menu search mode.

Pres 3 seg.

First press TRACK control and then we

turn it until the searched “Artist”

appears on the Text line.

Press TME again

ENGLISH

1- Search in mode 1.Playlist > “Artist”:

Internal Menu search mode.

Press 3 seg.

First press TRACK control and then we

turn it until the searched “Album” appears

on the Text line.

Press TME again

DECK2

UTILIZACIÓN DE LA BASE DE DATOS (PLAYLIST)

A. 1. PRESS FOLDER > We enter Folder mode. 2. PRESS and TURN

TRACK > we scroll through the Folders alphabetically sorted by

“Album”. Or…

B. 1. PRESS FOLDER > We enter Folder mode. 2. Hold TRACK and

turn outer wheel. we scroll through the Folders alphabetically sorted

by “Album”.

ALBUM>

TITLE>

Once we find the Album name (DECK&DRUMS&ROCK&ROLL)

press FOLDER button to select Track Mode. The FOLDER LED is off.

TURN TRACK > we scroll through the Tracks alphabetically sorted

belonging to the selected “Album” until we find the searched Track

(SPYBREAK).

Also we can Hold TRACK and TURN WHEEL. We scroll through the

Tracks alphabetically sorted.

BEFORE SWITCHING OFF THE POWER

When you have finished using the CD player, before switching off the power, be sure that the disc tray had been closed with the OPEN/CLOSE button.

CAUTION:

Do not forcibly close the disc holder when the power is off.

Do not switch off the power when the disc holder is open. To avoid damage, please don't switch off the power until “No

Disc” or “time code” is showed on the LCD after the disc

holder has been closed with the Open/Close button.

POWER OFF POWER OFF

ENGLISH

PLAYLIST OPERATION

Indice

Altri manuali Akiyama Lettore multimediale

Akiyama

Akiyama XCEED Manuale utente

Manuali Lettore multimediale popolari di altre marche

Visual Land

Visual Land Impulse Manuale utente

limHD

limHD 200i Manuale utente

Transcend

Transcend DMP10 Manuale utente

Philips

Philips GoGear Muse SA2MUS08 Manuale utente

Fantec

Fantec MM-HDRL Manuale utente

Dune HD

Dune HD Duo 4K Manuale utente

IAdea

IAdea HMP-505S Manuale utente

Camos

Camos MMS-1000 Manuale utente

Energy

Energy 75 Series Manuale utente

Z3 Technology

Z3 Technology DME-03 Manuale utente

Sony

Sony SVR-2000 Guida utente

Meicheng

Meicheng HD-1080K12 Manuale utente

DENAFRIPS

DENAFRIPS ARCE Manuale utente

Topaz

Topaz CMS Media Player Istruzioni per l’uso

InFocus

InFocus LightCast Manuale utente

IconBiT

IconBiT XDS1003D Manuale utente

Quanmax

Quanmax QDSP-2090 Series Manuale utente

Samsung

Samsung MP-80S Manuale utente
