Akron 9313 Series Manuale

Valve Actuator moves at the end

of the open or closed function.

Loose screws While some motion is normal from torque, excessive movement

may be caused by loosened screws.

Before tightening the screws, remove them and apply Permabond

LM 113 or Loctite 222 and retighten.

No Power to the

Controller

Bad wiring

Open breaker or blown fuse

Power not connected.

Check all power connections, wires, fuses or breakers.

Be sure a separate power wire is connected to any Controller used

as an Auxiliary.

Valve Actuator does not work.

Motor does not drive.

1. No signal from the Controller

to the Actuator Motor.

2. Defective Actuator Motor

3. Worm Gear system jammed.

4. Planet Gear system jammed.

1. Check all connectors are fully engaged.

Check the voltage through the Wiring Harness

should be at least 11.5 volts for 12 volt systems and

22 volts for 24 volt systems. Check the signal from

the Controller.

2. Remove the Motor from the Actuator and operate

the Motor to be sure the Motor Shaft turns freely.

3. Check the Worm Gear. Operate the Valve using the

Manual Override.

4. Remove the Motor and check the Planet Gears.

Motor Runs but Valve does not

operate

1. Grove Pin is missing from the

Shaft.

2. Gear Sector is not engaging

the Worm Gear.

3. Motor Shaft is disengaged

from the Planet gears.

1. Check the Groove Pin is fully engaging the Worm

Gear and Shaft.

2. Check if the Worm Gear and Sector Gear are

engaged.

3. Remove the Motor and check for engagement of the

Motor Shaft and Planet Gears.

Valve closes when the OPEN

Button is pressed and vice versa.

1. Sector Gear is in the wrong

position.

2. Cable wiring is reversed.

1. Reposition the Sector Gear.

2. Replace the Cable.

Valve OPEN/CLOSE LED’s switch

immediately from Red to Green

and vice versa.

1. Wiring

2. Mechanical Binding

1. Check wiring as explained in Problem #1.

2. Remove the Motor and check the Shaft turns freely. Also, oper-

ate the Valve manually via the Override to check for binding.

APPENDIX

Mating Weather-Pack Connectors for Power Cable

A Mating Weather-Pack connector must be used to connect to the power source.

DO NOT CUT THE CONNECTOR on the power wire of the controller.

Doing so will void the warranty.

Part number 9300-0058 is a packet of (5) mating Weather-Pack connections.

Wiring Harnesses

Part Number Description

7-21-290 10’ long (standard length)

7-21-381 15’ long

9303-0016 20’ long

9303-0012 30’ long (utilizes Potting Shells and 10 gauge wire)

9303-0013 38’ long (utilizes Potting Shells and 10 gauge wire)

9303-0014 50’ long (utilizes Potting Shells and 8 gauge wire)

Auxiliary Cables

Part Number Description

9300-0052 10’ long (standard length)

9300-0055 25’ long

9300-0056 50’ long

ISO 9001 REGISTERED COMPANY

PHONE: 330.264.5678 or 800.228.1161 I FAX: 330.264.2944 or 800.531.7335 I www.akronbrass.com

WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of ﬁve (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace

product which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service.

We will not be responsible for: wear and tear; any improper installation, use, maintenance or storage; negligence of the owner or user; repair or modiﬁcation after delivery; damage; failure to

follow our instructions or recommendations; or anything else beyond our control. WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED, OTHER THAN THOSE INCLUDED IN THIS WARRANTY

STATEMENT, AND WE DISCLAIM ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. Further, we will not be responsible for any consequential,

incidental or indirect damages (including, but not limited to, any loss of proﬁts) from any cause whatsoever. No person has authority to change this warranty.

reproduced without the express written consent of Premier Farnell Corporation.

REVISED: 4/12

Style 9313 Controller Ordering Information

Part Number Description

9313-0001 Controller Only

9313-0002 Controller w/ 10’ Wiring Harness

9313-0003 Controller w/ 10’ Auxiliary Cable

STYLE 9313 CONTROLLER

INSTALLATION & OPERATING INSTRUCTIONS

The Style 9313 Controller from Akron is designed to provide reliable and accurate valve control with valve position

indication through 10 LED (Light Emitting Diodes) indicators identifying the degree of Open/Close.

Features of the Akron Style 9313 Controller include:

Protected against EMI (Electro Magnetic Interference), both incoming and outgoing

Programmable Auto Open (not preset)

Works with both 12 and 24 Volt systems

Retroﬁts to existing apparatus

4 ¼” square face

Meets all aspects of NFPA 1901

Carries Akron’s 5 year warranty against manufacturing defects

Standard Components

Controller

Wiring Harness for connection to the valve-10’ length standard

Note: the Controller is designed for use only with Akron Brass Electric Valves. Do not use with any other manufacture of valve. Doing

so will void any warranty.

INSTALLATION INSTRUCTIONS

Select the mounting location for the Controller. The Controller can be mounted from the outside with (4) Screws and

Delrin Nuts (included). Torque requirement is 6-8 lb-in for the nuts. The unit requires 2 ½” clearance behind the panel. Dimensions

for a panel cutout are shown in ﬁgure #1.

Warning: The Controller is a sealed unit. Disassembly of the unit will void any warranty. There are no user serviceable parts in the

Controller. If service is required the unit should be returned to the factory. Also, do not cut any connections. Doing so will void any

warranty and prevent product returns.

Note: The Valve and Auxiliary wires are plugged prior to shipment. These plugs must be removed before connections can be made. If

a lead is not being utilized, the plug should be left in place to prevent moisture damage.

CONTROLLER LEADS

Each Controller has three (3) Connectors extending from the back of the unit.

Power Connection lead

The Controller Power connection utilizes a 2 prong Weather-Pack connector. A mating Weather-Pack connector is required (cus-

tomer supplied-see appendix for purchasing information). Proper wire gauge is required to assure a quality connection. 12 gauge wire

is recommended. Heavier gauge wire is required for runs over 10’.

Note: when using larger than 12 gauge wire, be sure to use a 12 gauge connector and splice after the connector so as to not void any

warranty. The splice should be made close to the Controller.

121568

For best connections all grounds should be made to either the frame or to a similar solid surface. A faulty ground will lead to

unit malfunction.

Added loads on any power wire should be avoided.

Direct runs are recommended for all connections.

12 Volt systems require a minimum of 11.5 volts at the valve under full load (28 amps).

24 Volt systems require a minimum of 22 volts at the valve under full load (14 amps).

Typical current draw for a 2”-3” valve is 2-4 amps in a 12 volt system (1-2 amps for 24 volt). It will be slightly higher for larger sized

valves. When the mechanical stops are reached (full open or full closed) current draw can reach 28 amps in a 12 Volt system and 14

Amps in a 24 Volt system.

Note: The truck should always be running before operating the Controller.

Electric Valve Connection lead

Use an Akron Wiring Harness to connect the Controller to the Valve Motor. The standard length is 10’. All Wiring

Harnesses have Deutsch connectors. See the appendix for a complete list of Wiring Harnesses.

Auxiliary Connection lead

The Controller Auxiliary connection is a 3 prong Weather-Pack connector.

To connect a Master to an Auxiliary, an Auxiliary Cable is required. Standard length is 10’. See the appendix for a list of Auxiliary

Cables.

NOTE: When utilizing an Auxiliary, a separate power lead is required for the Auxiliary

AUTO OPEN FEATURE

Auto Open allows a pump operator to open a fully closed valve by momentarily pressing the “OPEN” button.

The Auto Open feature is factory set in the DISABLED position. The Auto Open option can be changed to on or off in the Setup Mode.

If Auto Open is disabled, the valve only operates as long as an “OPEN”, or a “CLOSE” button is being pressed.

INITIAL SETUP

The Controller must be calibrated when used for the ﬁrst time with a new valve or with a different valve. When used for the ﬁrst

time, the LED Bar Graph Display will ﬂash indicating calibration is needed.

Calibration can be done easily by accessing the Setup Mode shown below.

Note: When a Controller is used as an Auxiliary, the Setup Mode is not accessible. Calibration and setup are only

necessary for a Master Controller.

SETUP MODE

Press and hold both the “OPEN” and “CLOSE” buttons for 15 seconds.

Note: Software versions (1.30 and higher) will blink out the Version after both buttons have been pressed for 2 seconds.

Example for version 1.32

- Press, and hold both the OPEN and CLOSE buttons.

- All LEDs turn off.

- After 2 seconds, the green LED ﬂashes once, then the middle yellow LED ﬂashes 3 times, and then the red LED ﬂashes 2 times.

- All LEDs turn off.

- If you continue to hold both buttons for 10 more seconds (LEDS will be all off), the Setup Menu will be accessed.

- If you release both buttons immediately after checking software version, the controller will resume normal operation.

After continuing to hold both the “OPEN” and “CLOSE” buttons for 15 seconds, the display will ﬂash once and then enter the SETUP

OPTIONS area. Now both buttons can both be released.

CALIBRATE DISPLAY to valve - middle YELLOW LED:

If you just entered the Setup Options area, the middle YELLOW LED should be the only LED on. This selection will cali

brate the display so that it matches the valve being used.

CAUTION: This function will cause the valve to cycle automatically! The valve will cycle to fully closed, fully open, then

back to the fully closed position. If you do not want to calibrate the display at this time, then refer to the EXIT instructions.

Page 02

To select the calibrate function; press the “CLOSE” button once.

AUTO OPEN Option - GREEN LED:

Use the “OPEN” button to navigate through the setup options until only the GREEN LED is on. (Each time the “OPEN

button is pressed, the display will jump to the next setup option.)

If the green LED is BLINKING, then Auto Open is DISABLED

If the green LED is ON SOLID, then Auto Open is ENABLED

The “CLOSE” button can be pressed to change this setting.

EXIT - RED LED:

Use the “OPEN” button to navigate through the setup options until only the RED LED is on. (Each time the “OPEN button

is pressed, the display will jump to the next setup option.) Now press the “CLOSE” button once. The unit will ﬂash the

LEDs once, and then return the controller to normal operation.

SPECIFICATIONS:

Electrical Inputs:

Power 9-32VDC@300mAmax (no load)

Valve Control 12 or 24VoltsDC

Communication Modbus Serial Connection

Environmental

Temperature -40C to +80C (Operating)

-40C to +85C (Storage)

Minimum Operations Voltage – 11.5 VoltsDC

Maximum Operations Voltage – 32 VoltsDC

Display Type – LED

TROUBLESHOOTING

Problem Cause Solution

Red or Green LED’s do not

illuminate but the Valve will

open and close.

Too much voltage drop or not

enough current for the unit to sense

the end of travel.

1. Truck engine must be running

2. Check the voltage to the Controller.

12 Volt systems require 11.5 volts @ 28 amps.

24 Volt systems require 22 volts @ 14 amps.

3. Check all wiring from the power source to the

Controller. A minimum of 12 gauge wire should

be used. For lengths over 10’ heavier gauge wire is

required.

4. Check all connections and grounds for loose

connections.

Red and Green LED’s

illuminate prematurely

before the Valve is fully open

or closed.

1. Short in the Motor or Controller

2. Gear system is jammed.

3. Seat or Valve Ball is damaged

1. Remove the Motor from the Gear Housing and

measure the amps needed to operate the Motor. The

Motor should require approximately 1.5 amps on 12

Volt systems; .75 amps for 24 volt systems.

2. Operate the Manual Override on the Actuator. If

difﬁculty is found, check under the housing cover

for damaged parts causing the Valve not to operate

properly.

3. Check the Valve waterway for any obstruction or

damage to the Ball or Seats.

The yellow LED

illuminates but the Valve

does not move while the

Motor continues to run.

Worm Gear is disengaged Remove the Gear Housing Cover and check for

damaged parts. Check the Groove Pin in the Worm Gear for

proper engagement.

Page 03

Questo manuale è adatto per i seguenti modelli

Altri manuali Akron Controllori

Akron

Akron 9321 Manuale di servizio

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
