Akura ANEPF06H Manuale utente
ANEPF06H
Digital Picture Frame
Customer Helpline:01422 2633 13
Website:www.ekey.co.uk
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of un- insulated "dangerous
voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to the persons.
The exclamation point within an equilateral triangle is intend to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
Correct disposal of this Product
(Waste Electrical & Electronic Equipment (WEEE)
The crossed out "Wheelie bin" is intended to show that this appliance must not be placed
with ordinary household waste at the end of its useful life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please keep separate from other
household waste and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where you purchased the product, or their local
government office for details of where and how you can take this item for environmentally safe
re-cycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product must not be mixed with other commercial wastes for disposal.
This appliance complies with European Safety and Electrical directives
Warning. Turn off the Photo frame when inserting or removing a memory card, to avoid
damaging the unit or ca
CAUTION. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS USER
MANUAL AND MARKED ON THE APPLIANCE. RETAIN THIS BOOKLET FOR FUTURE USE.
This set has been designed and manufactured to assure your personal safety. Improper use can result in Electric shock or
Fire hazard. The safeguards in this appliance will protect you if you observe the correct procedures for installation,
servicing and operation. There are NO user parts inside. DO NOT REMOVE THE CASE OR OTHER COVERS YOU
WILL INVALIDATE YOUR WARRANTY. REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL
2
Power Supply.
This apparatus is designed to operate from a 5V DC mains adaptor do not use an
alternative supply.
Ventilation.
Slots and openings in the cabinet are provided for ventilation to ensure the correct
operation of the appliance.
Do NOT block any slots.
Do NOT place on fabric or soft furnishings, this will restrict airflow.
Cleaning.
When cleaning is required. Unplug the appliance from the mains adaptor. Use a soft dry
cloth. For stubborn sticky stains use a damp cloth with a mild detergent. Do not use
chemical cleaners.
Care of the Screen.
The screen is manufactured with millions of tiny transistors and has been carefully
engineered to give you a clear bright image. Do not hit, drop or physically harm the
LCD screen.
Heat.
Do not place on or near appliances that radiate heat such as radiators or in direct
sunlight.
Water and Moisture.
Do not use this appliance near water, or in damp locations such as basements.
3
Contents
Safety Information………………………….…………………………………………2
Introduction................................................................................................... 5
Features.......................................................................................................... 5
Packaging Check List.....................................................................................6
Specifications.................................................................................................. 6
Product Diagram........................................................................................... 7
Side view…………………………………………………………...8
Using Your Frame . .....................................................................................9
Viewing Modes……………………………………………………………....10
Technical Notes………………………………………...................................11
Troubleshooting ......................................................................................…... 12
Introduction
Your new digital picture frame lets you view digital pictures from memory
cards easily and quickly.
No computer or printer is needed.
Includes convenient slide show mode, which starts automatically when the
frame is turned on.
Supports many popular memory card types.
Easy to take with you to share photos with family and friends anywhere.
A step beyond the traditional photo frame. View tens or even hundreds of
digital photos without the need to pay for printing.
1. Features:
•7 inch TFT LCD screen
•Supports Secure Digital (SD), Multimedia Card (MMC), Memory Stick
MS
•View the pictures from memory cards directly
•Supports rotation of photos for proper display of vertical pictures.
•Resolution: 480x234 pixels
•Supports high resolution photos
•Automatic start of slide show
•Key holes for wall mounting
•Removable stand allows frame to be displayed vertically or horizontally
5
Introduction
2,PackagingCheckList
* Digital Picture Frame
*Stand
*UserManual
* Power Adapter
3,Specifications
Panel Size 7 inches
Resolution 480 x 234
Brightness 250 cd/m2
Contrast 300
Viewing Angle 60/60/50/40 (CR=10)
Response Time 20~30ms
Screen Size Mode 16 : 9
Picture Rotation 270 degrees
File Format Type JPEG
Max. Photo Size 10 megapixels
Power Requirement 5V DC
Power Consumption 4W
Operating Temperature -20~65 degrees centigrade
Storage Temperature -30~75 degrees centigrade
6
ProductDiagram
a. Top view
1、Pressthebuttonsbelowa 2、Press the buttons below a longer
short time to operate the functions time to operate the functions
Play/Pause interval
Previous View
Next
Rotate
Mode
7
Side view
The removable stand can be connected to use your Digital Picture Frame vertically
or horizontally.
1. Memory card slot
2. Power input jack
3. USB input jack
8
UsingYourDigitalPictureFrame
Install the stand for tabletop display, or mount to a wall. Connect the AC adapter.
Insert a memory card in the digital picture frame (with the card’s electrical contacts
toward the back of the unit). If the power is off, press the PLAY/PAUSE button
to turn the frame on.A slide show will begin automatically.
To pause the slide show, press the PLAY/PAUSE button briefly. The word
Pause will appear on the screen briefly, and the slide show will be stopped. The
current photo will remain on the screen until another button is pressed, at which
time the slide show will resume.
To display the next or previous picture, press the Next button or the Previous
button .
The speed of the slide show is automatic. Photos will remain on the screen for
about 5 to 20 seconds, depending on the size of the files. Larger files will take
longer to load.
The Rotate button allows photos to be turned for proper viewing.
press this button long time each time to transfer 3 seconds,10seconds,15seconds
playing time
9
ViewingModes
The MODE button allows the user to adjust how the pictures are displayed on
the screen.
The modes function as follows:
NORMAL
This mode will cause your pictures to fit on the screen with no stretching or
cropping of the images. Photos with a typical 4:3 or 3:2 width-to-height ratio will
have black sections on the left and right sides of the screen.
CROP
This mode will cause your pictures to be enlarged to the full width of the screen,
without stretching them. As a result, the top and bottom of most pictures will not
be visible.
Press MODE button long time to browse several small screen,press ,to
select and press to confirm to play.
10
TechnicalNotes:
1. Your digital picture frame is a sophisticated electronic device. Do not drop or
subject the unit to jarring or strong vibrations.
2. Avoid placing the digital photo frame in areas of high humidity or where it
might be subjected to splashing.
4. The LCD panel is made of plastic and can be easily damaged. Avoid sharp
objects.
5. Use only a soft dry cloth to clean the screen
11
Questions/TroubleshootingGuide
1. Question: What kind of photos does this device support?
Answer: The frame will display digital photos that are stored in the JPEG
format, which is the standard format for nearly all digital cameras. Some
cameras allow images to be stored as TIFF or RAW files as well as JPEG.
Only the JPEG format is compatible with the frame. Photos of up to 10
million pixels can be displayed.
2. Question: What should I do if the system does not respond when the power
is turned on?
Answer: Please make sure the unit is properly connected to a power source.
Then turn it off, re-connect the power and turn it on again.
3. Question: Why is the memory card not recognized?
Answer: The memory card might be inserted backwards or is not pushed in
far enough. After inserting the memory card in the right direction, if the card
still cannot be read, please turn off the unit and then power it on again.
12
