Aladdin MOSAIC-SERIES USER MANUAL
THANK YOU FOR YOUR PURCHASE
Aladdin Lights
User Manual
Version: 22. August 2022, 2:23 PM
Unpack your panel and accessories from the kit. Plug in the panel connetor
to your dimmer-unit. Use the extansion in between if needed. Plug in your
dimmer-unit to a power outlet.
If you have also purchased the optional DMX Attachment or the Wired
Dimmer (M-WDIM) you can put them between the panel (or extension ca-
ble) and the AC adapter.
For any further questions about using our products please refer to our cus-
tomer service or watch the instructional videos on www.aladdin-lights.com
or YouTube.
START-UP GUIDE
1
LEGEND
1Plug for M-WDIM (optional)
2Plug for DC Power
3Control Box with Buttons
STATUS DISPLAY
Description LEFT LED RIGHT LED
Bi-Color Mode ON OFF
RGB Mode OFF ON
Remote Controller Connected ON ON
High Temperature Warning BLINK BLINK
Blackout BLINK BLINK
push “M” button for more than a second to black out, push shortly to change modes
12
3
DOWNLOAD THE APP
Using your ALL-IN panel with the new app for smartphones is a convenient
way of controlling your light. It is available as free download on Android
and iOS. You can store your own color filters in the app by dialling the
desired RGB / Bi-Color values, have more control over the hues and sat-
uration of lighting effects and much more. Give it a try and you will be
amazed about the convenience in your workflow. Find the QR-codes for
direct download below.
iOS Android
2
IMPORTANT CAUTIONS AND WARNINGS
• Do not use near flammables and heaters.
• Do not expose the unit to direct sunlight for a long period (applies also for
storing in a car).
• Do not use the dimmer wire or extension wire to hang or mount the panel.
• Do not bend or fold the panel more than 90 degrees.
• Do not tape directly on the LEDs of the panel - they can burn out.
• Do not damage the product with improper force or cause any impact with
heavy objects.
• Do not cut the panel with sharp objects.
• Keep out of reach of children.
• The panel will heat up when running a long period of time on 100% pow-
er, make sure to have it in your eyesight at all times. Use the frame to assure
enough air flow for heatreduction.
• Use the product only within the temperature range of -10°C – +40°C.
• Make sure the panel has cooled down before storing it in the pouch or
any other case.
• When you have technical problems while using the product, stop using it
immediately and contact your dealer / reseller.
3
SELECTED OPTIONAL ACCESSORIES
WARRANTY
We provide a one year warranty period after the purchase. This warranty
covers repairs or a replacement for faulty products within this period. After
this warranty has been expired, you can still get repairs for your product
which will be charged extra.
Aladdin Lights reserves the right to refuse warranty service on products un-
der disputable conditions.
WARRANTY EXCLUSIONS
In case of any of the below listed causes, the warranty does not apply, even
if it is within the free warranty period.
- Product failure due to consumer negligence.
- Product failure due to usage of not compatible power sources.
- Product failure due to disassembly by not official resellers/distributors.
4
M-WDEXCA3M
3 meters of extension
cable for Dimmer
M-WDIM
Lumenradio Capability,
Easier Control and
Eects!
M-EXCA3M
3 meters of extension
cable for power supply
TECHNICAL SPECIFICATIONS
THANK YOU FOR YOUR PURCHASE
5
MOSAIC 4X4
Color Temperature: 2900K - 6100K
Input (PSU): 100V AC to 240V AC
Input (LED Panel): 48V DC / 12.5A
Power Consumption: 600W
Connectivity:
BLE (Bluetooth Low Energy)
Lumenradio*
DMX-512**
Control:
Control Box on the Back
App Control (iOS / Android)
Remote Dimmer*
MOSAIC 3X6
Color Temperature: 2900K - 6100K
Input (PSU): 100V AC to 240V AC
Input (LED Panel): 48V DC / 12.5A
Power Consumption: 600W
Connectivity:
BLE (Bluetooth Low Energy)
Lumenradio*
DMX-512**
Control:
Control Box on the Back
App Control (iOS / Android)
Remote Dimmer*
MOSAIC 2X4
Color Temperature: 2900K - 6100K
Input (PSU): 100V AC to 240V AC
Input (LED Panel): 48V DC / 7.3A
Power Consumption: 350W
Connectivity:
BLE (Bluetooth Low Energy)
Lumenradio*
DMX-512**
Control:
Control Box on the Back
App Control (iOS / Android)
Remote Dimmer*
* optional Wired Dimmer (M-WDIM)
** optional DMX Attachment (DMX-AT)
