Alarmcom ADC-VDB780B Manuale utente

Charge the ADC-VDB780B battery

The Alarm.com Wireless Video Doorbell (ADC-VDB780B) battery can be charged using a 5V/1.5A USB wall charger

and the supplied charging cable.

To charge the ADC-VDB780B battery:

Note: A fully depleted battery takes approximately 7 hours to charge.

1. Unlatch the bottom of the mount.

2. Remove the VDB780B from the mount.

3. Separate the battery pack from the VDB780B body.

https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Wireless_Video_Doorbell_(A…

Updated: Wed, 08 Mar 2023 14:46:43 GMT

4. Plug the supplied micro USB cable into the battery pack.

5. Plug the USB end of the cable into a USB wall charger and insert the charger into an outlet.

6. The charging LED, located on the top of the battery pack, will be solid orange while the device is charging. The

charging LED will turn solid green when charging has completed.

https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Wireless_Video_Doorbell_(A…

Updated: Wed, 08 Mar 2023 14:46:43 GMT

Charging state LED guide

Mode description Top LED Behavior Button LED behavior

Charging

The battery pack is plugged in and

charging.

Solid orange

On button press

Solid green =

>75% charged

Solid yellow =

75%-20% charged

Alternating red and blue = <20%

charged

Fully charged

The battery pack is fully charged.

Solid green On button press, solid green

Failure charging

The battery pack stopped charging

because the device was plugged in

too long. This may signal that there

is an issue with your battery pack.

Remove the charging cabled and re-

attempt charging after an hour. If you

see the same behavior, please

contact your provider.

Alternating orange and green Alternating red and white

https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Wireless_Video_Doorbell_(A…

Updated: Wed, 08 Mar 2023 14:46:43 GMT

Mode description Top LED Behavior Button LED behavior

Operational temperature range for

charging exceeded

The battery pack's internal

temperature is either too hot or too

cold. Please charge the battery pack

in a room-temperature environment.

Solid green or solid orange

Alternating red and yellow

Alternating red and white

https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Wireless_Video_Doorbell_(A…

Updated: Wed, 08 Mar 2023 14:46:43 GMT
