7845C

Cellular Control Channel Transceiver

Fast Track Setup

Pocket Guide

For ADEMCO and First Alert Controls

Fast Track Setup

Pocket Guide

Now

Pro*

Enabled!

*Programmerless

Registration Option

Before You Leave the Shop . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Equipment Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Check MicroBurst Coverage Availability . . . . . . . . . . . . . . . .1-1

Obtain AlarmNet Account Numbers . . . . . . . . . . . . . . . . . . .1-1

Which Operating Mode to Use With Different Types of

Control Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Antenna Placement and Transmitter Installation . . . . . . .3-1

Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Activate the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Select Mounting Location . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Program the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Mount the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Wire Radio to Control Panel . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Test Alarm Delivery to Central Station . . . . . . . . . . . . . . . . . . .3-2

Wiring and Programming Guides By Panel Type . . . . . . .4-1

Vista 10, Vista 20 and Via 30 (Non-E2 Panels) . . . . . . . . . . . .4-1

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . . .4-2

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

VISTA-10SE, VIA-30PSE, FA142C, FA145C and

VISTA-10ADTG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . . .4-3

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

FA147C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . . .4-4

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Table of Contents

VISTA-15, FA148C, 250P1 . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . . .4-5

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

VISTA-20SE, VISTA-20HWSE, FA162C, VISTA-20ADT,

VISTA-20Bay and SL150. . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Programming the 7845C with a 7720P Programming Tool or Using Pro4-6

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Vista 40, Vista 50 and Vista 100 (Non-E2 Panels) . . . . . . . .4-7

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

#93 Menu Mode Programming . . . . . . . . . . . . . . . . . . . . . . . .4-7

Device Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . . .4-8

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

VISTA-128B, VISTA-128FB, VISTA-32FB, and FA1600 . . . .4-9

Programming the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

#93 Menu Mode Programming . . . . . . . . . . . . . . . . . . . . . . . .4-9

Device Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . .4-11

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

Non-ADEMCO Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

Programming the 7845C with a 7720P

Programming Tool or Using Pro . . . . . . . . . . . . . . . . . . . . . .4-12

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

Appendix A. Tips for Finding the Best Antenna Location A-1

General Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

GO FOR HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

AVOID OBSTACLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

AVOID INTERFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

REMEMBER THAT AN ACCESSORY ANTENNA IS AVAILABLE . . . .A-1

Appendix B. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . .B-1

Table of Contents (cont’d)

1. Before You Leave the Shop

Equipment Checklist

• 7845C (Includes battery and standard antenna.

No transformer or power supply necessary.)

Optional Equipment

May be desired or necessary depending

on job specification or requirements.

• 4229 zone expander (refer to Section 2)

• 7720P AlarmNet programming tool

• 7825-OC outdoor antenna

• Antenna cables

• 7720V2TR 6V DC power pack

Check MicroBurst Coverage Availability

Use job premises zip code to confirm that MicroBurst service is active in

the local cellular network. Check zip code at the AlarmNet web site.

WWW.ALARMNET.COM

Or call the AlarmNet Technical Assistance Center at

800-222- 6525

Obtain AlarmNet Account Numbers

Contact your providing AlarmNet Central Station or your

local data center to obtain all three of the necessary AlarmNet

account numbers. You will not be able to register the radio

without these numbers.

SUBSCRIBER NUMBER (Four digits, 0-9)

CENTRAL STATION NUMBER (Two hexadecimal digits, 0-9, A-F)

CITY ID NUMBER (Two digits, 0-9)

Section 1. Before You Leave the Shop

2. Which Operating Mode to Use With

Different Types of Control Panels

The 7845C has four different modes of operation, which can be selected

using the tamper switch during start-up. Which mode you use depends

on what type of control panel you will connect to the radio.

Table 1 indicates which modes to use with various panels.

Table 1. Operating Modes for Use with Control Panels

• ECP Mode (VISTA with E2 only) - Contact ID communication

• Programmable Relay Emulation Mode - Relay commands are

sent via data connection (ECP) from the host (VISTA)panel to

the 7845C (does not require 4204 module)

• 4229 Mode - Allows the use of a 4229 zone expander as a

seven zone input board

• Zone Mode - Single Zone Input (Pulsed Input = Zone 1, Steady

Input = Zone 2).

Section 2. Which Mode to Use

CONTACT ID ADEMCO HIGH SPEED

ECP Single

Zone

VISTA with E2 X* X X

VISTA without E2 X X*

LYNX X

Non ADEMCO panels X X*

NOTE: * indicates preferred mode.

Programma

ble Relay

Emulation

Mode

4229

Mode

3. Antenna Placement and Transmitter Installation

Guidelines

• Use the signal strength meter (five horizontal LEDs) to determine

quality of reception

• Strive for the maximum possible signal strength-5 BARS, and

• Never settle for less than three steady bars of signal strength.

Procedures

Activate the Radio

1. Connect the battery.

2. Radio will initiate start-up procedure (2-5 minutes).

3. When completed:

• Red LED will be OFF, indicating positive

MicroBurst availability.

• IF red LED stays on, go to Appendix II Troubleshooting.

• Amber LED will blink steadily, either once or twice per second, depend-

ing on carrier selected.

• Green LED on solid.

Select Mounting Location

1. Hold radio against wall for 10 seconds at desired

mounting location.

2. Check to be sure that this location provides at least three steady bars

on the signal strength meter.

3. If signal strength is inadequate, move radio and hold for another 10

seconds.

4. Use 7825-OC outdoor antenna if specified or necessary.

5. Even if original location provides three bars of signal strength, test

several other locations for better signal strength.

6. Refer to Appendix I for tips on finding best locations.

7. STRIVE FOR FIVE bars of signal strength.

8. Conduct click test using tamper switch to confirm clear RF path to the

network.

9. Mark location with best signal strength for

later mounting.

Program the Radio

1. Power down the unit.

2. Identify operating mode to be used according to control panel type

(refer to Section 2).

3. Power up unit.

4. Use tamper switch to select operating mode.

5. Program radio using PRO registration method or

7720P if necessary.

NOTE: Refer to appropriate subsection in Section 4 for details.

Mount the Radio

1. Mount in previously selected and tested location.

2. Register the Radio

3. Triple click tamper switch or press SHIFT [È] to register.

4. GreenL ED will go OFF when radio has successfully

registered (30 seconds).

5. Wire Radio to Control Panel

6. Refer to appropriate diagram in Section 4.

7. Test Alarm Delivery to Central Station

8.Test according to your company’s standard

installation procedure.

4. Wiring and Programming Guides By Panel Type

Vista 10, Vista 20 and Via 30 (Non-E2 Panels)

Programming the Panel

*25 WIRED EXPANSION/RELAY USED . . . . . . . . . . . . . . . . . . . . . .[0]

0 = none; 1=4219; 2=4229; 3=4204

*80 OUTPUT RELAYS

Notes:: 1. Field *25 must be programmed for a 4229 (Relays 01 and 02) or a 4204

(Relay 01 to 04)

2. Tampers of contacts or expansion units cannot be used to operate

relays.

Where: A = RELAY ACTION 0 = No Response; 1 = Close for 2 sec;

2 = Close and stay closed; 3 = Pulse on and off

EV = EVENT 0 = Not Used; 1 = Alarm; 2 = Fault; 3 = Trouble

ZL = ZONE LIST 1,2, or 3 (from Field *81) or 0 = Not Used.

START ZONE LIST: Upon alarm, fault, or trouble of ANY

zone on this list, relay action will START

STOP “RESTORE of” ZONE LIST: Upon restore of ALL

zones on this list, relay action will STOP. It need not be

same list as used for START

ZT= ZONE TYPE/SYSTEM OPERATION

Choices for Zone Types are:

00 = Not Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06 = 24 Hr Silent

01 = Entry/Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07 = 24 Hr Audible

03 = Perimeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .08 = 24 Hr Aux

04 = Interior Follower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09 = Fire Trouble

05 = Trouble Day/Alarm Night . . . . . . . . . . . . . . . . . . . .10 = Interior w/Delay

Choices for System Operation are:

20 = Arming - Stay . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 = At Bell Timeout**

21 = Arming - Away . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 = Chime

22 = Disarming (Code + OFF) . . . . . . . . . . . . . . . . . . . . . .39 = Any Fire Alarm

31 = End of Exit Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 = Bypassing

32 = Start of Entry Time . . . . . . . . . . . . . . . . . . . . . . . .41 = AC Power Failure

33 = Any Burglary Alarm . . . . . . . . . . . . . . . . . . . . .42 = System Battery Low

34 = Code + # + 7 Key Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 = Duress

35 = Code + # + 8 Key Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

**Or at Disarming, whichever occurs earlier

ZONE TYPE

/SYST OP’N

(ZT)

S T A R T

either or both

S T O P

either or both

OUTPUT

RELAY

ACTION

(A)

EVENT

(EV)

ZONE

LIST

(ZL)

ZONE TYPE

/SYST OP’N

(ZT)

“RESTORE of”

ZONE LIST

(ZL)

Programming the 7845C with a 7720P Programming Tool or Using Pro

Using a 7720P, enter programming mode.

Question 1. Mode Press the [space] key to scroll through

the modes of operation.

(4204)

Press [ENTER] to select 4204 Mode.

Question 2. Device Addr Enter the 4204 device address. This

must be address 1 for all panels.

Or, use PRO Mode. Select 4204 by toggling the test/tamper switch

during power-up so that MODE LED-1 is unlit and MODE-2 LED is lit.

The default device address will be 1.

Wiring

Connect as shown below. For detailed information, refer to the

appropriate installation and setup guide.

Section 4. Wiring and Programming Guides by Panel Type - cont

V+

GND

BATT

7845C

ECP IN

ECP OUT

BLK

RED

GRN

YEL

TB2

TB1

BATTERY

ADEMCO

K4362

12V AUX

GND

DATA OUT

DATA IN

FA147C

Control Panel

VISTA 10, 20 or VIA 30 Panel

VISTA-10SE, VIA-30PSE, FA142C, FA145C and VISTA-10ADTG

Programming the Panel

*27 OUTPUT TO LONG RANGE RADIO [0] [1]

0 = no; 1 = yes. If yes selected, dialer reports to PRIMARY No. (field Q47) will

also be sent via LRR. All dialer and LRR reports will be in Contact ID format

(overriding field Q46 selection).

*93 DYNAMIC SIGNALING [0] [0]

1ST digit: Dynamic Signaling Delay (DSD) 0 - 15 times a 15-second delay; e.g. 1

= 15 seconds, 2 = 30 seconds, etc. “0” for UL installations.

2nd digit: Dynamic Signaling Priority (DSP) 0 = primary dialer first; 1 = Long

Range Radio (LLR) first.

Note: Not an option on FA145C.

Programming the 7845C with a 7720P Programming Tool or

Using Pro

Using a 7720P, enter programming mode.

Question 1. Mode Press the [space] key to scroll

through the modes of operation.

(ECP)

Press [ENTER] to select ECP Mode.

Question 2. Device Addr Enter the ECP device address of the

radio. For the VISTA-10 Family, this

must be address 3.

Or, use PRO Mode. Select ECP by toggling the test/tamper switch

during power-up so that MODE LED-1 is lit and MODE-2 LED is

unlit. The default device address will be 3.

Wiring

Connect as shown below. For detailed information, refer to the

appropriate installation and setup guide.

Section 4. Wiring and Programming Guides by Panel Type - cont

V+

GND

BATT

7845C

ECP IN

ECP OUT

BLK

RED

GRN

YEL

TB2

TB1

BATTERY

ADEMCO

K4362

12V AUX

GND

DATA OUT

DATA IN

VISTA-10 Family

Control Panel

Altri manuali per 7845C

Indice

Altri manuali AlarmNet Ricetrasmettitore

AlarmNet

AlarmNet 7845C Manuale

Manuali Ricetrasmettitore popolari di altre marche

Yaesu

Yaesu FT-7B Manuale utente

Kenwood

Kenwood ProTalk TK-3201 Manuale utente

Texas Instruments

Texas Instruments TLK10232 Manuale utente

Mizuho

Mizuho MX-2 Guida del prodotto

Kenwood

Kenwood TK-3180 Manuale operativo e di manutenzione

Blitz

Blitz MJ-398U Manuale utente

Utilicom

Utilicom LongRanger 2050 Manuale utente

Standart

Standart HX290UKA Manuale utente

Altronix

Altronix Pace1PTM Manuale utente

Kirisun

Kirisun PT2208 Manuale utente

ELECRAFT

ELECRAFT KX2 Manuale utente

Zodiac

Zodiac K3 Manuale utente

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuale utente

Kenwood

Kenwood TK-2217 Manuale utente

Siemens

Siemens PSO 4000 Manuale utente

Kenwood

Kenwood TS-590SG Manuale utente

Midland

Midland G8E-BT Manuale

ComNav

ComNav Mariner X2 Manuale utente
