Alcatel 3080A Manuale utente
English - CJB1S23ALAAA
Quick Start Guide
www.sar-tick.com
This product meets applicable national
SAR limits of 1.6 W/kg. The specific
maximum SAR values can be found on
Radio waves section.
When carrying the product or using it
while worn on your body, either use an
approved accessory such as a holster
or maintain a distance of 15 mm from
the body to ensure compliance with RF
exposure requirements. Note that the
product may be transmitting even if you
are not making a phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at
high volume levels for long periods. Exercise caution
when holding your device near your ear while the
loudspeaker is in use.
For more information about how to use your phone, please visit
www.alcatelmobile.com to download the complete user manual.
On our Website, you will also find our FAQ (Frequently Asked
Questions) section.
1
1 Your Mobile ������������������
1�1 Keys and connectors
2
3
1
4
1. Headset connector
2. Camera
3. Flash
4. USB port
2
1. Center soft key
•Confirm an option (press the middle of the key)
•Press: access to app list (Home screen)
2. Left soft key
3. Call key
•Pick up/send a call
•Press: enter call log (from Idle screen)
4. Right soft key
5. Back/End Key
•Return to the previous screen, or close a dialog
box, options menu
•Press: End a call
1
2
3
4
5
6
7
8 9
3
6. Navigation key
•Goes to up, down, left or right menu
•Press (from Idle screen):
•Up / Down key: access to volume adjustment
•Right key: access to Profiles
•Left key: access to Message
7. “5”key
•In idle screen:
•Press: dial “5”
•Long press: switch on/off the torch
8. “*”key
•In idle screen
•Press: Input “*”
•Long press: lock screen
•In Edit mode:
•Press: insert symbols
9. “#”key
•Idle screen
•Press to input #
•Long press: Vibrate mode on/off
•In edit mode
•Press: change the input method
4
1�2 Status bar icons(1)
New message or multimedia message
Silent mode
Level of network reception
Airplane mode
Headset connected
No SIM card installed
Alarm is set
Bluetooth is on
New voicemail
Music activated.
FM is on
SD card installed
(1) The icons and illustrations in this guide are provided for
information purposes only.
5
2 Getting started�������������
2�1 Set up
Removing and installing the back cover
Removing and installing the battery
Inserting and removing microSD card
Inserting and removing the SIM card
Place the SIM card with the chip facing down and slide it into its
housing. Make sure that it is correctly inserted. To remove the
card, press it and slide it out.
This is a single SIM model which only supports a mini
SIM card. Do not attempt to insert other SIM types
like micro and nano cards, otherwise this may cause
damage to your phone.
6
Charging the battery
•Connect battery charger to your phone and plug it into the
socket.
•Charging may take about 20 minutes to start if the battery is
out of power.
•Be careful not to force the plug into the socket.
•Make sure the battery is correctly inserted before connecting
the charger.
•The main socket must be near the phone and easily accessible
(avoid electric extension cables).
7
•You are advised to charge the battery to its maximum
when using the phone for the first time (approximately
3.5 hours) .
•To reduce power consumption and energy waste, when battery
is fully charged, disconnect your charger from the phone;
reduce the backlight time, etc.
The charge is complete when the animation stops.
2�2 Power on your phone
Hold down the key until the phone powers on.
2�3 Power off your phone
Hold down the key from the idle screen.
3 Calls Log �����������������
3�1 Making a call
Enter the desired number, then press the key to place the
call. If you make a mistake, you can delete the incorrect digits by
pressing the right soft key. To hang up the call, press the key.
Making an emergency call
If your phone is covered by the network, dial the emergency
number and press the key to make an emergency call. This
works even without a SIM card.
Making an International call
To dial an international call, press twice to enter “+”, then
enter the international country prefix followed by the full phone
number and finally press the key.
3�2 Calling your Voice mail (1)
•To access your voicemail, hold down the key.
•Long press to make a voicemail call.
(1) Contact your service provider to check service availability.
8
3�3 Answer or decline a call
When you receive an incoming call, press the key to answer
and then hang up using the key.
4 Contacts ������������������
4�1 Consulting your contacts
Contacts enables quick and easy access to the contact you
want to reach.
You can access this function by pressing the Center Soft Key
from the Home screen and select Contacts.
4�2 Adding a contact
In contacts list screen, press the Left Soft Key to add new
contacts with detailed information.
When finished, press the Left Soft Key to save.
4�3 Editing your contacts
In contacts list screen, press the Center Soft Key to access
Options, select Edit and press the Center Soft Key to edit.
4�4 Deleting a contact
In contacts list screen, press the Center Soft Key to view details,
press the left Soft Key to select delete.
5 Calendar ������������������
Use the Calendar to keep track of important meetings,
appointments, etc.
To access this function, press the Center Soft Key from the Home
screen and select Calendar.
9
6 Tools �������������������������
6�1 Alarm
Your phone has a built-in alarm clock with snooze feature. You
can set five alarms with wake-up time and other customised
options.
6�2 Calculator
Press the up, down, left, right and Centre soft key to select +, -,
×, ÷ and = respectively.
6�3 Bluetooth
You can exchange data, such as video, images, and audio, with
other Bluetooth supported devices within a limited range after
pairing.
6�4 Convert
Convert support weight conversion and length conversion.
6�5 Fake call
You can fack fake call through this function. It helps you to
politely escape from social situations at any time you wish.
6�6 Call filter
You can edit the blacklist / whitelist through this function. In
settings, you can enable the blacklist to automatically block all
callls listed on the blacklist and nable the whitelist will only allow
calls from the numbers listed on the whitelist.
6�7 Torch
Turn on/off the torch as per your need.
6�8 World clock
The first clock displays the time based on your location when you
set up your phone. You can add other cities to show the time in
their time zones.
