Alcatel A392T Manuale utente

English US - CJB331AALAAD

Quick Start Guide

For more information about how to use the phone, please

go to www.alcatelonetouch.com to download complete

user manual. Also on our website you can find helpful

FAQs, software upgrade, etc.

A392T

2 3

1 Your mobile ��

1�1 Keys and connectors

Left key Right key

Navigation key/

OK key

End key

Delete key

Send key

Volume key

micro-USB

connector

Headset

connector

Camera key

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen

at high volume levels for long periods. Exercise

caution when holding your device near your ear

while the loudspeaker is in use.

This product meets applicable national

SAR limits of 1.6 W/kg. The specific

maximum SAR values can be found

in the RADIOWAVES section of this

user guide.

When carrying the product or using it

while worn on your body, either use an

approved accessory such as a holster or

otherwise maintain a distance of 10 mm

from the body to ensure compliance

with RF exposure requirements.Note

that the product may be transmitting

even if you are not making a phone call.

www.sar-tick.com

Table of contents

1 Your mobile �� 3

2 Getting started �� 9

3 Making a call�� 10

4 Messaging�� 11

5 Contacts �� 13

6 Call log�� 14

7 Media�� 14

8 Files �� 16

9 Browser�� 17

10 Applications�� 18

11 Tools �� 19

12 Settings �� 21

13 Making the most of your mobile �� 21

Troubleshooting�� 22

Safety and use�� 27

General information �� 37

LIMITED WARRANTY�� 38

4 5

•Press: "0" Key

Press and hold: Switch between "+/P/W"

•In Edit mode

Press: Enter a space

Press and hold: Input "0"

•Press:Take a picture

•Press and hold:Access Camera

•Press:Volume up/down

•In Camera mode

Press: Zoom in/out

•In music playing mode

Press and hold: Previous/Next song

•In Radio mode

Press and hold: Previous/Next channel

•In Calendar mode

Press: Previous/Next month

•Incoming call (Clamshell close)

Press: Mute

Press and hold: End

•Alarm beep (Clamshell close)

Press: Snooze

Press and hold: Stop

•Navigation key(1)

Press to go left/right/up/

down

Press to access function

UP: Call log

DOWN: Contacts

LEFT (2):Tools

RIGHT (2): Media

•OK key Press to confirm an option

•Answer/Send a call

•Enter Call log

•Press: End a call

Return to the Home screen

•Press and hold: Power on/off

•Press: Delete characters in Edit mode

•Press: "#" key

Press and hold: Switch to General profile

•In Edit mode

Press: Switch between ABC/Abc/abc

Press and hold: Switch between Multi-Tap/

Smart

•Press: "1" Key

Press and hold:Access your voicemail

•In Edit mode

Press: Input "1"

Input frequently-used symbols

•Press: " " Key

•In Edit mode

Press: change input method

Press and hold:Access the Symbols table

(1) You can personalize navigation key in Settings.

(2) The shortcut to access function for LEFT/RIGHT only be

available when shortcut bar is off.

6 7

Email unread�

WAP messages.

Roaming.

microSD card scanning completed.

GPRS connecting.

GPRS attached�

EDGE connecting�

EDGE attached�

3G network connecting�

3G network attached�

Music active.

MMS receipt in progress�

Silence mode: your phone does not ring,

beep or vibrate with the exception of the

alarm.

1�2 Status bar icons(1)

Battery charge level

Vibrate alert: your phone vibrates, but does

not ring or beep with the exception of the

alarm.

Bluetooth®status (Activated).

Bluetooth®status (Connected to an audio

device).

Java status (Activated).

Headset connected.

Call forwarding activated: your calls are

forwarded.

Alarm or appointments programmed.

Level of network reception.

Voicemail message arrived.

Missed calls.

Call in progress�

Stopwatch is active.

Radio is on.

(1) The icons and illustrations in this guide are provided for

informational purposes only.

8 9

2 Getting started��

2�1 Set-up

Removing or installing the back cover

Inserting or removing the SIM card

You must insert your SIM card to make phone calls. Please

power off your phone and remove battery before inserting

or removing the SIM card.

Place the SIM card with the chip facing downwards and

slide it into its housing. Ensure the beveled edge of the SIM

card is aligned with the SIM card slot.To remove the card,

press and slide it out.

Installing or removing the battery

Insert and click the battery into place, then close the

telephone cover. Unclip the cover, then remove the

battery.

Message unread.

(Red) Message list is full: your phone cannot

accept any new messages. You must access the

message list and delete at least one message on

your SIM card.

Airplane mode�

1�3 Home screen

1�3�1 Shortcut bar

Shortcuts are home screen icons for your frequently used

items, like Calls or Messages.

You can customize shortcut bar by selecting «Settings\

Phone settings\Shortcut bar».

10 11

4 Messaging ��

4�1 Access

You may access this menu using the following options:

•Access from the main menu by selecting «Messaging».

•Select from shortcut bar, and then enter the sub-

menu you require.

When you access «Messaging», you can switch between

SMS/MMS and Email by navigation key.

4�2 Conversational On (Off) mode

Conversational view mode is set as default.You may switch

to conventional mode by selecting «Settings\Switch

view mode». In conversational on mode, you can view

the chat history in chronological order. In conversational

off mode, you may have access to the following folders:

Inbox, Outbox, Sent, Drafts, Voicemail, Broadcast

SMS, Empty folder, Archive, Templates, Emergency

alerts and Settings.The following instructions are based

on conversational mode.

4�3 Write message

You can select «Messaging\New message» from the

main menu or access from shortcut to write text/

multimedia message. One or more recipients can be

added from contact list and you can remove a recipient

by pressing the Delete key. Press the key and select

«More» to select multiple recipients from Contacts.

Charging the battery

Connect the battery charger to your phone and outlet

respectively.

To reduce power consumption and energy waste, when

battery is fully charged, disconnect your charger from

the plug; switch off Bluetooth and background-running

applications when not in use; reduce the backlight time, etc.

2�2 Power on your phone

Hold down the key until the telephone powers on.

2�3 Power off your phone

Hold down the key from the Home screen.

3 Making a call ��

Dial the desired number then press the key to place

the call.The number you entered can be saved to Contacts

by selecting «Save». If you make a mistake, you may press

key to delete the incorrect digits one by one, or you

may press and hold key to delete all.

To hang up the call, press the key.

12 13

5 Contacts ��

5�1 Accessing your contacts

You can access this function by selecting “Contacts” from

the main menu.

5�2 Adding a contact

You can add a new contact to the phone or SIM card by

selecting «Add new contact».

For the first time consulting your contacts, your are

required to import contact from SIM card to your phone

or SIM card.

5�3 Import contacts from SIM

You can access Contact, select your contact and press

Options\Copy or Options\Move to your phone.

An SMS(Short Messaging Service) will be converted to

MMS automatically when images, videos, audio, slides or

attachments are inserted; Subject, CC/BCC/email address

is added; or the message contains more than 8 pages

of text.

An SMS message of more than a certain number

of characters (the number of characters depends

on your language) will be charged as several SMS.

An MMS message containing photos and/or

sounds may also be billed as more than one

message. Specific letters (accent) will increase the

size of the SMS, this may cause multiple SMS to be

sent to your recipient.

4�4 Email

Your phone has an email client with pre-defined settings

for a few popular email services like – Gmail,Yahoo,AOL,

etc. Besides this, you can set up other POP3 or IMAP4

email accounts that you may be using.

4�4�1 Email account set-up

Pre-defined email service

If you own an email account of predefined services,

you can install it to your phone by selecting the service

(GoogleMail, yahoo, etc.), entering the Email address and

password, and then confirming with «OK».

New email service

To set up a new email account other than the predefined

email services, select «Other accounts».

You are required to enter your Email address, select

protocol(1) (POP3 or IMAP4) and data account, then

enter your incoming server address, outgoing server

address, username, password and account name, finally

confirm with «Done».

14 15

7�2 Music player

You can access this feature from the main menu by

selecting «Media\

Music player». You will have full flexibility of managing

music both on your mobile and microSD card.

7�3 Picture viewer

A library links to the pictures both shown in list, slide, sent,

set as wallpaper, by MMS, Email, and Bluetooth.

7�4 Video player

Contains all video clips both in phone and microSD card

and enables you to play, send, delete, rename, sort, etc.

7�5 FM Radio

Your phone is equipped with a radio(1) with RDS(2)

functionality. You can use the application as a traditional

radio with saved channels or with parallel visual

information related to the radio program on the display if

you tune to stations that offerVisual Radio service.You can

listen to it while running other applications.

7�6 Voice recorder

Accessing this feature from the main menu by selecting

«Media\Voice recorder», allows you to make voice or

sound recordings.

(1) The quality of the radio depends on the coverage of the radio

station in that particular area.

(2) Depending on your network operator and market.

6 Call log ��

6�1 Access

You can access the function using the following options:

•Select the from main menu

•Press the key from Home screen

•Select the from shortcut bar, and then enter the sub-

menu you require.

6�2 Available options

When you press «Options», you can have access to

Send message, Call, Missed calls, Edit before call,

Delete, etc.

7 Media ��

7�1 Camera

Your mobile phone is fitted with a camera for taking

photos and shooting videos.You can press Camera key to

access Camera, press again to take a picture.

16 17

9 Browser ��

From the main menu, select the menu icon to access

Browser.

9�1 Homepage

Launch the Browser with the preset homepage.

9�2 Bookmarks

Access your favorite sites.

9�3 Go to URL

Manually enter the URL of WAP site.

9�4 Open file

Open web pages stored on your phone.

9�5 Last web address

Opens the last visited URL.

9�6 Recent pages

Pages which you recently browsed.

9�7 Offline pages

Pages available for offline viewing.

8 Files��

You will have access to all audio and visual files stored in

phone or microSD card in File manager.

When a microSD card which is including photos from

other phone is inserted for the first time, it will be scanned

and the default folders will be created. You can transfer

photos from the microSD to your phone.

Inserting the microSD card:

Insert the microSD card with the golden contacts facing

downwards into the microSD slot until it is locked. Gently

push the memory card until it is unlocked.

The microSD card is an optional accessory that is

sold separately.

18 19

10�4 Java

Your ALCATEL ONE TOUCH phone may include(1) some

Java™ applications and games.You can also download new

applications and games to your phone.

11 Tools ��

From the main menu, select the menu icon to access

Tools.

11�1 Alarm

Your mobile phone has a built-in alarm clock with a snooze

feature.You can set up to five separate alarms and choose

whether or not the alarm should repeat.

11�2 Calculator

Access this feature by selecting «Tools\Calculator» from

the main menu.

11�3 Calendar

Once you enter this feature from the main menu, there is a

monthly-view calendar for you to keep track of important

meetings, appointments, etc. Days with events entered will

be marked in color.

11�4 Tasks

Enables you to easily manage and track the progress of

a task with priorities. All the tasks will be sorted by due

date.

(1) Depending on your country or your operator.

9�8 Service inbox

Store WAP push messages.

9�9 Settings

Customize your Browser preferences.

10 Applications�

From the main menu, select the menu icon to access

Application.

10�1 WEB

WEB not only gives you the full Web experience where

you stay in touch with your friends, obtain information,

do your online banking etc., but also saves time by using

compressed web pages.

10�2 News

This application provides you with news updates from

website channels you subscribe to.

Once subscribed to a channel, it gives you the ability to

track and manage all your favorite RSS content on your

mobile phone at anytime, anywhere!

10�3 Weather

Your phone is equipped with a weather function for

viewing up to 3-day forecasts of your favorite cities.

You can access this feature from the main menu by

selecting «Applications\Weather».

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Alcatel Telefono cellulare

Alcatel

Alcatel One Touch 233 Manuale utente

Alcatel

Alcatel OneTouch Star 6010D Manuale utente

Alcatel

Alcatel 2035X Manuale utente

Alcatel

Alcatel ONE TOUCH OT-V212C Manuale utente

Alcatel

Alcatel One Touch Scribe easy 8000A Manuale utente

Alcatel

Alcatel 4013K Manuale utente

Alcatel

Alcatel One Touch 818 Manuale utente

Alcatel

Alcatel ELLE GlamPhone N5 Manuale utente

Alcatel

Alcatel One Touch PIXI 3 5025 E Manuale utente

Alcatel

Alcatel 4013E Manuale utente

Alcatel

Alcatel One Touch Idol 6030D Manuale tecnico

Alcatel

Alcatel A10 Manuale tecnico

Alcatel

Alcatel One Touch 132 Manuale utente

Alcatel

Alcatel One Touch 902 Manuale tecnico

Alcatel

Alcatel OT-E157 Manuale utente

Alcatel

Alcatel BP60 Manuale utente

Alcatel

Alcatel ONE TOUCH 7025 Manuale utente

Alcatel

Alcatel OneTouch POP 2 Manuale utente

Alcatel

Alcatel Pixi 4 8050G Manuale utente

Alcatel

Alcatel ONE TOUCH 756 Manuale utente

Alcatel

Alcatel 3041D Manuale utente

Alcatel

Alcatel One touch 720 Manuale utente

Alcatel

Alcatel Glam Elle 3 Manuale utente

Alcatel

Alcatel One Touch Soleil 5021E Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
