ALDI FERREX GSR2800 Manuale utente
PRODUCED IN CHINA FOR:
GB IE
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
first 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to be
found both in this manual and on the product itself.
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE
Visit us at www.aldi.com
AFTER SALES SUPPORT 805016
GB IE
MODEL:
GSR2800 03/2021
+44(0) 1904727501 +353(0) 19022605
3
YEAR
WARRANTY
User Manual
ELECTRIC GARDEN
SHREDDER
Original User Manual
Overview
2
7
4
22
23
8
6
5
3
2
1
9
10111213
14
15
16
17
18
19
20
21
24
25
5
2728 26
Package contents/components
1
Wheel cover (2x)
2
Wheel (2x)
3
Support foot (2x)
4
Safety switch
5
Adjustment dial
6
Supply cord with plug
7
Hand grip
8
Hopper
9
Function selection switch
10
ON switch
11
OFF switch
12
Overload protection switch
13
Standby LED
14
Pusher
15
Shredder assembly
16
Base frame
17
Collection container
18
Inner washer (2x)
19
Outer washer (2x)
20
Splint (2x)
21
Wheel axle
22
Screw for cutter cover (4x)
23
Cutter cover
24
Cutting drum
25
Pressure plate
26
Allen wrench
27
Screw 6x25 (4x)
28
Screw 5x45 (2x)
Instruction manual and warranty
card (without illustration)
Required tools/consumables not included in the package
29
Phillips
screwdriver
PH2
29
30
Flat head
screwdriver SL3
30
31
Broom
31
32
Brush
32
33
Commercially
available tool
oil
33
Package contents/components
3
Table of content
Overview..................................................................................................................2
Package contents/components.............................................................................. 3
General information................................................................................................6
Reading and storing the operating manual..................................................................6
Proper use...........................................................................................................................6
Foreseeable misuse...........................................................................................................6
Residual risks......................................................................................................................6
Explanation of symbols........................................................................................... 7
Safety.......................................................................................................................9
Safety notes........................................................................................................................ 9
Safety instructions for persons........................................................................................11
Safety instructions for the shredder.............................................................................. 12
Safety instructions regarding extension cords............................................................ 12
Safety instructions............................................................................................................ 13
Before first use....................................................................................................... 13
Check the device and scope of delivery........................................................................ 13
Assembly............................................................................................................................14
Operation............................................................................................................... 16
Operating panel............................................................................................................... 16
Overload protection with restart lockout...................................................................... 17
Resetting overload protection........................................................................................17
Adjusting the pressure plate.......................................................................................... 18
Preparing for operation.................................................................................................. 18
Switching the device ON and OFF.................................................................................. 19
Using the pusher.............................................................................................................. 19
Emptying the collection container................................................................................20
Working with the shredder....................................................................................21
Shredding..........................................................................................................................22
Removing stuck material................................................................................................ 23
Cleaning, maintenance and storage.....................................................................24
Transport................................................................................................................27
Spare parts.............................................................................................................28
Troubleshooting.................................................................................................... 29
Technical data........................................................................................................30
Declaration of conformity......................................................................................32
Disposal..................................................................................................................33
Table of content
5
General information
Reading and storing the operating manual
This instruction manual is part of this electric garden shredder (in the
following also called "device"). It contains important information about
start-up and operation.
Before using the device, read the operating manual carefully, in particular
the safety instructions. Failure to follow this operating manual may lead to severe
injuries or product damage.
This user manual is based on the standards and regulations that are valid within the
European Union. Outside the EU, please also note the country-specific directives and
laws.
Keep this operating manual for future reference. If you pass this device on to a third
party, you must also supply this operating manual.
Proper use
The device is designed exclusively for shredding tree and hedge trimmings.
This device is intended for private use only and is not suitable for commercial use.
Use the device only as described in this operating manual. Any other use is improper
and may lead to product damage or even personal injury. This device is not a toy.
The manufacturer or retailer assume no liability for damage caused by improper or
incorrect use.
Foreseeable misuse
Do not use the device for soft materials such as kitchen waste. They will plug up the
shredder mechanism.
Do not use the device for shredding stone, glass, metal, bones, plastics or textiles.
Residual risks
Even if you use this device as intended, residual risks cannot be completely
excluded.
The following dangers can occur in connection with the design and construction of
this device:
- Danger of injury from being pulled in when reaching into the feed chute.
- Scratch, crush or cut injuries when working without protective gloves.
- Eye damage from flying particles or rebounding cuttings, if safety goggles are
not worn.
- There is a risk of damage if you do not wear hearing protection.
Reduce the residual risk by using the device carefully and correctly and by following
all instructions.
General information
6
Explanation of symbols
The following symbols and signal words are used in this user manual, on the device
or on the packaging.
This symbol provides you with useful additional information on
handling and use.
Declaration of conformity (see chapter “Declaration of conformity”):
Products marked with this symbol meet all the applicable Community
regulations of the European Economic Area.
IPX4
The device is protected from all sides against water splashes.
Read the instruction manual
Wear ear protectors.
Wear goggles.
Wear protective gloves.
Do not use the device in the rain.
Caution - Sharp knives - Unplug power plug prior to maintenance
work or if the power cable is damaged
Explanation of symbols
7
Danger – rotating knives.
Keep hands and feet out of openings while the device is running.
Keep uninvolved persons and animals away from the danger area.
This symbol warns of a risk of electrical shock.
92
The guaranteed sound power level LWA is 92dB.
Never stand on the device. Never use the device or device
components as a climbing aid.
Wait until all device components have stopped before touching the
device.
Function selection switch:
- Top position:
Direction of material flow is reversed to remove blockages.
- Middle position:
No operation
- Bottom position:
Normal operation - shredding
Explanation of symbols
8
Safety
IMPORTANT
READ CAREFULLY BEFORE USING THE DEVICE. KEEP FOR FUTURE
USE.
The following signal words are used in this operating manual.
WARNING! This signal symbol/word denotes a
hazard with an average risk level that
could lead to death or severe injury if
it is not avoided.
CAUTION! This signal symbol/word denotes a
hazard with a low risk level that could
lead to mild or moderate injury if it is
not avoided.
NOTE! This signal word provides a warning
about potential material damage.
Safety notes
WARNING!
Risk of electric shock!
Faulty electric installation or excess mains voltage can cause an
electric shock.
- Only plug the device into a properly installed outlet. The
mains voltage must correspond to the specification on the
type plate.
- Do not connect the device if there is visible damage to the
device, the power cable or a power plug.
- If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
Safety
9
- Do not open the device. Leave repairs to a qualified service
technician. Contact the service address indicated on the
warranty card. Liability and warranty claims are excluded if
you carry out repairs yourself, improperly connect the device
to the power supply or operate it incorrectly.
- Only parts that match the original device data may be used
for repairs. This device contains electrical and mechanical
parts that are essential for protection against sources of
danger.
- Operate the device only at an outlet with a protective contact
and at least a 16A fuse.
- The device must be supplied via a residual current protection
device (RCD) with a rated residual current of no more than 30
mA.
- Electrical supply cables must be positioned in such a way that
they cannot get into the device.
- Do not immerse the device or the power cable or the power
plug in water or other liquids.
- Never touch the power plug with wet hands.
- Keep the device and the power cable away from open flames
and hot surfaces.
- Make sure that the power cable does not present a trip
hazard.
- Do not bend the power cable or position it over sharp edges.
- Never operate the device in damp rooms or at a relative
humidity of over 75%.
- Never reach for the device if it has fallen into water.
Immediately disconnect the device from the power supply.
-In case of a malfunction, immediately disconnect the device
from the power cable or power supply.
- Do not operate the device with an external timer or a separate
remote control system.
Safety
10
